- Page 1 User Manual...
-
Page 2: Edition Notes
Edition Notes The SlimPAR T6BT ILS User Manual includes a description, safety precautions, installation, programming, operation, and maintenance instructions for the SlimPAR T6BT ILS as of the release date of this edition. Trademarks Chauvet, Chauvet DJ, the Chauvet logo, and SlimPAR are registered trademarks or trademarks of Chauvet &... -
Page 3: Table Of Contents
D-Fi USB DIP Switch Channels................10 IRC-6 Infrared Remote Control ..............Wired Master/Slave Mode................D-Fi USB Master/Slave Mode ............... ILS Mode....................... 5. Maintenance..................Product Maintenance ..................6. Technical Specifications..............Contact Us....................Warranty & Returns..................SlimPAR T6BT ILS User Manual Rev. 1... -
Page 4: Before You Begin
Important installation or configuration information. The product may not function correctly if this information is not used. Useful information. SlimPAR T6BT ILS User Manual Rev. 1... -
Page 5: Safety Notes
♦ Consult the dealer or an experienced radio/TV technician for help. Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. SlimPAR T6BT ILS User Manual Rev. 1... -
Page 6: Introduction
WARNING! DO NOT plug anything other than a D-Fi USB into the USB type B port. Doing so may cause damage to the product. Product Dimensions 10.4 in 265 mm 7.6 in 3 in 218 mm 76 mm SlimPAR T6BT ILS User Manual Rev. 1... -
Page 7: Setup
3. Setup AC Power The SlimPAR T6BT ILS has an auto-ranging power supply and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 8: Power Linking
Additional product products It is possible to link up to 25 SlimPAR T6BT ILS products on 120 VAC or up to 38 products on 230 VAC. The power linking diagram shown above corresponds to the North American version of the product ONLY! If using the product in other markets, consult with the local Chauvet distributor as power linking connectors and requirements may differ by country or region. -
Page 9: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The SlimPAR T6BT ILS may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming. -
Page 10: Operation
If the starting address is set too high, access to some of the product’s channels could be restricted. The SlimPAR T6BT ILS uses up to 7 DMX channels in an 7-Ch DMX mode, which defines the highest configurable address to 506. For information about the DMX protocol, download the DMX Primer from www.chauvetdj.com. -
Page 11: Dmx Charts
DMX controller. Products in standalone mode may transmit DMX signals that could interfere with the DMX signals from the controller. Static Colors To run the SlimPAR T6BT ILS in Preset Color mode, follow the instructions below: 1. Press <MENU> repeatedly until C-- shows on the display. 2. Press <ENTER>. -
Page 12: Custom Color Mixing
Press <ENTER>. Bluetooth Configuration The SlimPAR T6BT ILS can be operated with the BT Air application over a Bluetooth connection. Download and install the BT Air app from your preferred app store. Press <MENU> repeatedly until bLE shows on the display. -
Page 13: D-Fi Usb Connectivity
Operation D-Fi USB Connectivity The SlimPAR T6BT ILS is able to become a D-Fi wireless receiver/transmitter with the use of the D-Fi USB from Chauvet DJ. Simply set the product's DMX Personality and DMX Address, set the DIP switch D-Fi receiving/transmitting channel, then plug it into the D-Fi USB port. -
Page 14: Irc-6 Infrared Remote Control
Operation IRC-6 Infrared Remote Control The SlimPAR T6BT ILS is compatible with the IRC-6 infrared remote control from Chauvet. To enable or disable IRC-6 functionality, do the following: 1. Press <MENU> repeatedly until SEt shows on the display. 2. Press <ENTER>. -
Page 15: Wired Master/Slave Mode
D-Fi USB Master/Slave Mode The D-Fi USB allows a single SlimPAR T6BT ILS product (the “master”) to control the actions of one or more SlimPAR T6BT ILS products (the “slaves”) without the need of a DMX controller or DMX cables. The master (transmitter) product will be set to operate in standalone mode, while the slave (receiver) products will be set to operate in slave mode. -
Page 16: Ils Mode
ILS mode. This product will synchronize with the par effect on the selected side of the GigBAR MOVE+ILS. To set the SlimPAR T6BT ILS to respond to an ILS signal: 1. Press <MENU> repeatedly until iLS_ shows on the display. -
Page 17: Maintenance
6. Softly drag any dirt or grime to the outside of the transparent surface. 7. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. SlimPAR T6BT ILS User Manual Rev. 1... -
Page 18: Technical Specifications
1,754 lux Thermal Maximum External Temperature Cooling System 104 °F (40 °C) Convection I/O Connector Channel Range 3-pin XLR 3 or 7 Ordering Product Name Item Code UPC Number SlimPAR T6BT ILS 10032297 781462226459 SlimPAR T6BT ILS User Manual Rev. 1... -
Page 19: Contact Us
For warranty terms and conditions and return information, please visit our website. For customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration. For customers in the United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, and Germany: www.chauvetlighting.eu/warranty-registration. SlimPAR T6BT ILS User Manual Rev. 1...
