Summary of Contents for Chauvet DJ SlimPAR H6 ILS
- Page 1 User Manual...
-
Page 2: Table Of Contents
Dimmer Curve ........................ 11 IRC-6 Infrared Remote Control ..............IRC-6 Operation ......................12 Master/Slave Mode ..................Master/Slave Mode (D-Fi USB)..............ILS Mode....................... 5. Maintenance................Product Maintenance ..................6. Technical Specifications ............Returns.................... Contact Us ..................SlimPAR H6 ILS User Manual Rev. 1... -
Page 3: Warranty
United States, United Kingdom, Republic of Ireland, Belgium, the Netherlands, Luxembourg, France, Germany and Mexico. For warranty terms in other countries, please consult your local distributor. SlimPAR H6 ILS User Manual Rev. 1 Page 1 of 17... -
Page 4: Before You Begin
Electronically published by Chauvet in the United States of America. CHAUVET, the Chauvet logo, and SlimPAR H6 ILS are registered trademarks or trademarks of Chauvet & Sons LLC. (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company and product names and logos referred to herein may be trademarks of their respective companies. -
Page 5: Safety Notes
Set this product on a flammable surface. Keep this User Manual for future use. If you sell the product to someone else, be sure that they also receive this document. SlimPAR H6 ILS User Manual Rev. 1 Page 3 of 17... -
Page 6: Introduction
Introduction 2. Introduction Product Overview Display screen Menu buttons Safety loop Power in/ out 3-pin DMX in/ out Bracket adjustment knob (2x) D-Fi USB Port Mounting bracket Page 4 of 17 SlimPAR H6 ILS User Manual Rev. 1... -
Page 7: Product Dimensions
Introduction Product Dimensions 7.5 in 191.5 mm 8.8 in 224.5 mm 3 in 75 mm 3.3 in 84 mm SlimPAR H6 ILS User Manual Rev. 1 Page 5 of 17... -
Page 8: Setup
3. Setup AC Power The SlimPAR H6 ILS has an auto-ranging power supply, and it can work with an input voltage range of 100 to 240 VAC, 50/60 Hz. To determine the product’s power requirements (circuit breaker, power outlet, and wiring), use the current value listed on the label affixed to the product’s back panel, or refer to the product’s specifications chart. -
Page 9: Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes. Orientation The SlimPAR H6 ILS may be mounted in any position; however, make sure adequate ventilation is provided around the product. Rigging • Before deciding on a location for the product, always make sure there is easy access to the product for maintenance and programming purposes. -
Page 10: Operation
Enables the currently displayed menu or sets the currently selected value into the selected <ENTER> function Menu Map Refer to the SlimPAR H6 ILS product page on www.chauvetdj.com for the latest menu map. Main Level Programming Levels Description 6-Ch d 1–507... -
Page 11: Configuration (Dmx)
If you choose a starting address that is too high, you could restrict the access to some of the product’s channels. The SlimPAR H6 ILS uses up to 9 DMX channels in a 9Ch DMX mode, which defines the highest configurable address to 501. -
Page 12: Dmx Values
052 101 Dimmer speed mode off – – Dimmer speed 102 152 Dimmer speed mode 1 (fast) 153 203 Dimmer speed mode 2 (medium) 204 255 Dimmer speed mode 3 (slow) Page 10 of 17 SlimPAR H6 ILS User Manual Rev. 1... -
Page 13: Configuration (Standalone)
DMX controller. Products in standalone mode may transmit DMX signals that could interfere with the DMX signals from the controller. Preset Color Mode To run the SlimPAR H6 ILS on a static color, follow the instructions below: Press <MENU> repeatedly until C-- shows on the display. Press <ENTER>. -
Page 14: Irc-6 Infrared Remote Control
Operation IRC-6 Infrared Remote Control The SlimPAR H6 ILS can be operated with the CHAUVET IRC-6. To enable IR wireless control, follow the instructions below. 1. Press <MENU> repeatedly until SEt shows on the display. 2. Press <ENTER>. 3. Press <UP> repeatedly until ON shows on the display. -
Page 15: Master/Slave Mode
Master/Slave Mode (D-Fi USB) The D-Fi USB allows a single SlimPAR H6 ILS product (the “master”) to control the actions of one or more SlimPAR H6 ILS products (the “slaves”) without the need of a DMX controller or DMX cables. The master (transmitter) product will be set to operate in standalone mode, while the slave (receiver) products will be set to operate in DMX mode. -
Page 16: Maintenance
Softly drag any dirt or grime to the outside of the transparent surface. Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Page 14 of 17 SlimPAR H6 ILS User Manual Rev. 1... -
Page 17: Technical Specifications
Maximum External Temperature Cooling System 104 °F (40 °C) Convection I/O Connector Channel Range 3-pin XLR 6,8, or 12 Ordering Product Name Item Code UPC Number SlimPAR H6 ILS 10031954 781462222444 SlimPAR H6 ILS User Manual Rev. 1 Page 15 of 17... -
Page 18: Returns
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Page 16 of 17 SlimPAR H6 ILS User Manual Rev. 1... -
Page 19: Contact Us
Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Benelux, France, Germany, or Mexico contact the dealer of record. SlimPAR H6 ILS User Manual Rev. 1 Page 17 of 17...
