Summary of Contents for Pfeiffer Vacuum IMR 420
- Page 1 OPERATING INSTRUCTIONS Translation of the Original IMR 420 ∣ IMR 430 Bayard-Alpert and extractor gauges with bakeable measurement cables...
-
Page 2: Disclaimer Of Liability
Dear Customer, Thank you for choosing a Pfeiffer Vacuum product. Your new gauge is designed to support you in your individual applications with maximum performance and without malfunctions. The name Pfeiffer Vacuum represents high-quality vacuum technology, a comprehensive and complete range of top-quality products and first-class service. From this extensive, practical experience we have gained a large volume of information that can contribute to efficient deployment and to your personal safety. -
Page 3: Table Of Contents
Limits of use of product Proper use Foreseeable improper use Personnel qualification 2.7.1 Ensuring personnel qualification 2.7.2 Personnel qualification for maintenance and repair 2.7.3 Advanced training with Pfeiffer Vacuum Product description Function Status display Identifying the product Scope of delivery... - Page 4 Table of contents 12.2 Ordering accessories Technical data and dimensions 13.1 General 13.2 Technical data 13.3 Dimensions EC Declaration of Conformity UK Declaration of Conformity 4/36...
-
Page 5: List Of Tables
List of tables List of tables Tbl. 1: Applicable documents Tbl. 2: Gauges Tbl. 3: Abbreviations used Tbl. 4: Permissible ambient conditions Tbl. 5: Contact colors Tbl. 6: Replacement cathodes Tbl. 7: Measurement cable Tbl. 8: Conversion table: Pressure units Tbl. -
Page 6: List Of Figures
Fig. 1: Individual parts of the gauge Fig. 2: Connecting bakeable measurement cable to gauge flange Fig. 3: Contact assignments in view of built-in measurement system Fig. 4: Replacing cathode Fig. 5: Dimensions IMR 420 Fig. 6: Dimensions IMR 430 6/36... -
Page 7: About This Manual
Pfeiffer Vacuum reserves the right to make technical changes without prior notification. Information that relates to only one of the products is indicated accordingly. Unlabeled illustrations correspond to the IMR 420 gauge and also apply likewise to the IMR 430 gauge. The figures in this document are not to scale. -
Page 8: Conventions
About this manual 1.3 Conventions 1.3.1 Instructions in the text Usage instructions in the document follow a general structure that is complete in itself. The required ac- tion is indicated by an individual step or multi-part action steps. Individual action step A horizontal, solid triangle indicates the only step in an action. ►... -
Page 9: Tbl. 3: Abbreviations Used
About this manual Abbreviation Explanation Mean sea level Pressure Protective earth (earthed conductor) PEEK High temperature resistant plastic (polyetheretherketone) PTFE Polymer of fluorine and carbon (polytetrafluorethylene) Earthed conductor Measuring signal [V] (output voltage) Tbl. 3: Abbreviations used 9/36... -
Page 10: Safety
Once the emission is switched on, the active voltages at the two sockets of the IMG 400 are danger- ous to touch, even if only one measurement system is connected. In case of error during operation with the IMR 420 and IMR 430 gauges, a dangerous voltage is active at the measurement cable con- nection. - Page 11 Once the emission is switched on, the active voltages at the two sockets of the IMG 400 are danger- ous to touch, even if only one measurement system is connected. In case of error during operation with the IMR 420 and IMR 430 gauges, a dangerous voltage is active at the measurement cable con- nection.
-
Page 12: Safety Precautions
Safety WARNING Health hazard through poisoning from toxic contaminated components or devices Toxic process media result in contamination of devices or parts of them. During maintenance work, there is a risk to health from contact with these poisonous substances. Illegal disposal of toxic sub- stances causes environmental damage. -
Page 13: Limits Of Use Of Product
Tbl. 4: Permissible ambient conditions 2.5 Proper use The gauges are used for vacuum measurement of gases in vacuum systems with a Pfeiffer Vacuum ionization measurement instrument IMG 400. Use the product according to its intended purpose ► Install, operate and maintain the product only in accordance with these operating instructions. -
Page 14: Ensuring Personnel Qualification
─ Customer with Pfeiffer Vacuum service training ─ Pfeiffer Vacuum service technician 2.7.3 Advanced training with Pfeiffer Vacuum For optimal and trouble-free use of this product, Pfeiffer Vacuum offers a comprehensive range of courses and technical trainings. For more information, please contact Pfeiffer Vacuum technical training. -
Page 15: Product Description
3 Product description 3.1 Function The IMR 420 gauge is a Bayard-Alpert measurement system for connecting to an IMG 400 ionization measurement instrument. The IMR 430 gauge is an extractor measurement system for connecting to an IMG 400 ionization measurement instrument. The functional principle of this passive gauge relies on the hot cathode ionization effect. -
Page 16: Transport And Storage
Transport and storage 4 Transport and storage 4.1 Transporting the product NOTICE Damage caused by incorrect transport Transport in unsuitable packaging or failure to install all transport locks can result in damage to the product. ► Comply with the instructions for safe transport. Packing We recommend keeping the transport packaging and original protective cover. -
Page 17: Installation
Measurement systems can influence each other and deliver faulty results. Procedure 1. Remove the protective cap and store in a safe place. 2. Install the gauge on the vacuum system with vacuum components from the Pfeiffer Vacuum Com- ponents Shop. 17/36... -
Page 18: Establishing Electric Connection
Once the emission is switched on, the active voltages at the two sockets of the IMG 400 are danger- ous to touch, even if only one measurement system is connected. In case of error during operation with the IMR 420 and IMR 430 gauges, a dangerous voltage is active at the measurement cable con- nection. -
Page 19: Connecting Bakeable Measurement Cable To Gauge Flange
The distance between the flange of the built-in measurement system and the connector guide is greater in the case of the built-in measurement system for the IMR 420 gauges. This is why 3 spacers are inserted between the flange of the built-in measurement and the connector guide. -
Page 20: Connecting Gauge With Bakeable Measurement Cable To Img 400
Longest pin = earthed conductor. For orientation purposes during installation. Longest pin = earthed conductor. For orientation purposes during installation. This function is not available with the IMR 420, however, the contact is required. This function is not available with the IMR 420, however, the contact is required... -
Page 21: Operation
Operation 6 Operation Halogen gases in the process If halogen gases such as fluorine, chlorine, bromine, and iodine or their compounds occur, the yttrium oxide layer of the iridium cathode will be removed within a very short time. As a result, the cathodes will burn out. Incorrect measurements due to stray currents Moisture on the insulators, e.g., condensate, can lead to incorrect measurements due to stray currents. -
Page 22: Maintenance
Read the section with the work instructions through completely first before you commence with work. 7.1 Calibrating the gauge Pfeiffer Vacuum has calibrated the gauge at the factory. You will find the gauge calibration factor on the rating plate. Adjusting sensitivity ►... -
Page 23: Fig. 4: Replacing Cathode
Maintenance IMR 420 IMR 430 Fig. 4: Replacing cathode 1 Anode Terminal 2 Cathode Hexagon socket screw Procedure 1. Replace the cathode in a dust-free room. 2. Switch the IMG 400 off. 3. Disconnect the measurement cable from the built-in measuring system of the gauge. -
Page 24: Shipping
► Comply with the instructions for safe distribution. Decontamination subject to charge Pfeiffer Vacuum decontaminates products not clearly declared "Free of contamination" at your expense. Ship product safely ► Do not ship microbiological, explosive or radioactively contaminated products. -
Page 25: Recycling And Disposal
● Help to reduce the wastage of natural resources. ● Prevent contamination. 9.1 General disposal information Pfeiffer Vacuum products contain materials that you must recycle. ► Dispose of our products according to the following: – Iron – Aluminium –... -
Page 26: Service Solutions By Pfeiffer Vacuum
We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality. - Page 27 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 28: Spare Parts
► Install original spare parts only. Order number Selection field PT 120 020 -T Replacement cathode for IMR 420 (incl. 0.89 mm screwdriver) PT 120 021 -T Replacement cathode for IMR 430 (incl. 0.89 mm screwdriver) Tbl. 6: Replacement cathodes... -
Page 29: Accessories
View the range of accessories for ModulLine on our website. 12.1 Accessory information Measurement cable Measurement cables of different lengths, for connecting to a Pfeiffer Vacuum IMG 400 ionization meas- urement instrument 12.2 Ordering accessories Part number Selection field PT 548 332 -T... -
Page 30: Technical Data And Dimensions
1.01 0.101 59.8 0.76 atm cm Tbl. 9: Conversion table: Units for gas throughput 13.2 Technical data Parameter IMR 420 IMR 430 Measuring range 1 × 10 – 2 × 10 1 × 10 – 2 × 10 Measuring principle Bayard-Alpert... -
Page 31: Tbl. 12: Ambient Conditions
Max. flange temperature with bakeable measurement cable 250 ℃ Max. ambient temperature without electric connection 400 ℃ Storage +20 – +50 °C Tbl. 13: Temperatures Component IMR 420 IMR 430 Feedthrough pins Nickel-iron (NiFe) alloy Nickel-iron (NiFe) alloy Insulator Ceramic (Al Ceramic (Al Feedthrough plate... -
Page 32: Dimensions
Technical data and dimensions 13.3 Dimensions Ø69.4 Ø33 DN 40 CF Diameter of power feedthrough on vacuum side Fig. 5: Dimensions IMR 420 Dimensions in mm Ø69.4 Ø33 DN 40 CF Diameter of power feedthrough on vacuum side Fig. 6: Dimensions IMR 430... -
Page 33: Ec Declaration Of Conformity
This declaration of conformity has been issued under the sole responsibility of the manufac- turer. Declaration for product(s) of the type: Gauges IMR 420 in operation with IMG 400 IMR 430 in operation with IMG 400 We hereby declare that the listed product satisfies all relevant provisions of the following European Directives. -
Page 34: Declaration Of Conformity
EN IEC 61326-1:2021 EN IEC 63000:2018 The manufacturer's authorized representative in the United Kingdom and the authorized agent for compiling the technical documentation is Pfeiffer Vacuum Ltd, 16 Plover Close, In- terchange Park, MK169PS Newport Pagnell. Signature: Pfeiffer Vacuum GmbH Berliner Straße 43... - Page 35 35/36...
