QUICKTIP
StarLink Table
Microphone
Pairing
The 2.4 GHz Table Microphone must be paired to interact with compatible 2.4 GHz hearing aids on the Neuro Processor and
Thrive platforms. Pairing occurs once, then the hearing aids and Table Microphone will automatically recognize each other.
The Table Microphone can be paired within the fitting software or outside of the fitting software.
Pairing within Pro Fit
1
Launch Pro Fit and connect hearing aids.
2
Select Accessories from the Preparation Session in Pro Fit or from the Flyout Menu
3
Ensure the Table Microphone is powered on by holding the power button for 2–3 seconds
until the brackets light up green.
4
Place the hearing aids within six inches of the Table Microphone.
5
Place the Table Microphone in pairing mode by pressing the Hearing Aid Pairing button
for two seconds. The blinking blue brackets on the top of the device indicate the Table Microphone is in pairing mode.
6
Select
to put the hearing aids in pairing mode.
7
Pairing is successful when the Table Microphone
displays on the Accessories screen.
Use the dropdown menu above the Table Microphone
8
to set Hearing Aid Mic while Streaming.
9
Use the dropdown menu below the Table Mic to optimize
streaming sound. Options are Equalized (default),
Treble Boost, Bass Boost, and Overall Boost.
10
Select pairing information for pairing instructions if needed.
3.5mm Audio Output Jack
Microphones
Automatic
Mode
Indicator
Segments
Magnetic Interface
For Hanger
Hearing Aid
Pairing Button
7
9
Neuro + Thrive Platforms
Volume Buttons
Directional
Touch Keys
Mode
Switching
Button
MicroUSB Jack
.
on the bottom of the device
10
8
6
Power
Button
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Starkey StarLink Table Microphone
Summary of Contents for Starkey StarLink Table Microphone
- Page 1 Neuro + Thrive Platforms QUICKTIP 3.5mm Audio Output Jack StarLink Table Volume Buttons Microphones Directional Microphone Touch Keys Mode Automatic Switching Mode Button Indicator Power Button Segments Magnetic Interface For Hanger Hearing Aid Pairing Button MicroUSB Jack Pairing The 2.4 GHz Table Microphone must be paired to interact with compatible 2.4 GHz hearing aids on the Neuro Processor and Thrive platforms.
- Page 2 Pairing (Continued) Pairing within Inspire X Launch Inspire X, connect and detect hearing aids. Select Accessories on the left navigation bar. Ensure the Table Microphone is powered on by holding the power button for 2–3 seconds until the brackets light up green. Place the hearing aids within six inches of the Table Microphone.
- Page 3 How it Works The Table Microphone is designed to improve listening in noise by allowing the user to focus on the primary speaker in a multiple-speaker environment such as a meeting. The Table Microphone also functions as a body-worn remote microphone, or as a TV streamer. The Table Microphone can also be used to provide listening in noise benefit for unaided or normal hearing listeners when coupled with wired headphones.
- Page 4 (e.g., TV audio). White bottom segment blink indicates line-out connection (e.g., wired earphones). The Starkey logo, Thrive, Pro Fit, Neuro Processor and Inspire are trademarks of Starkey Laboratories, Inc. ©2023 Starkey Laboratories, Inc. All Rights Reserved. 6/23 FLYR3655-04-EN-SC...
