Starkey QUICKTIP Quick Start Manual

QUICKTIP
2.4 GHz Mini
Remote Microphone
Pairing
The Mini Remote Microphone must be paired to interact with compatible 2.4 GHz hearing aids on the Thrive platform.
Pairing occurs once, then the hearing aids and Mini Remote Microphone will automatically recognize each other.
The Mini Remote Microphone can be paired within Inspire X or outside of Inspire X.
Pairing within Inspire X
Launch Inspire X, connect and detect hearing aids.
1
Select Accessories on the left navigation bar.
2
Ensure the Mini Remote Microphone is powered on.
3
Place the hearing aids within six inches of the
4
Mini Remote Microphone.
Place the Mini Remote Microphone in pairing mode by
5
double clicking the power button. The LED status
indicator will alternately blink blue and red.
Select Pair to put the hearing aids into pairing mode.
6
Pairing is successful when the Mini Remote Microphone
7
image displays on the accessory screen.
Use the drop-down menu below the Streaming
8
Accessories box to set "Hearing Aid Mic While
Streaming." Mic Reduced (50%) is the default.
Select the Information icon for pairing instructions,
9
if needed.
D
Microphone
MicroUSB Jack
A
B
C
Power On
Press the power button for three seconds
and release when the LED illuminates.
Power Off
Press the power button for two seconds
and release when the LED turns off.
A
B
D
C
Power Button
Status
Indicator LED
Clip
