Starkey 2.4 GHz Table Microphone Manual

2.4 GHz
Table
Microphone

Pairing

The 2.4 GHz Table Microphone must be paired to interact with compatible 2.4 GHz hearing aids on the Thrive platform.
Pairing occurs once, then the hearing aids and Table Microphone will automatically recognize each other. The Table
Microphone can be paired within Inspire X, or outside of Inspire X.
Pairing within Inspire X
1 Launch Inspire X, connect and detect hearing aids.
2
Select Accessories on the left navigation bar.
3 Ensure the Table Microphone is powered on
by holding the power button for 2–3 seconds
until the brackets light up green.
Place the hearing aids within 6 inches of the
4
Table Microphone.
5
Place the Table Microphone in pairing mode by
pressing the Hearing Aid Pairing button
bottom of the device for 2 seconds. The blinking
blue brackets on the top of the device indicate
the Table Microphone is in pairing mode.
6
Select Pair to put the hearing aids in pairing mode.
7
Pairing is successful when the Table Microphone
displays on the Accessories screen.
8 Use the drop-down menu below the Table Mic to set
Hearing Aid Mic while Streaming. The default is
Mic Off while streaming.
9
Select the information icon for pairing instructions if needed.
Microphones
Automatic
Mode
Indicator
Segments
Magnetic Interface
For Hanger
Hearing Aid
Pairing Button
on the
6
7
8
Volume Buttons
Directional
Touch Keys
Mode
Switching
Button
MicroUSB Jack
9
Power
Button
