Starkey Table Microphone Operation Manual

Hide thumbs Also See for Table Microphone:
Table of Contents

Advertisement

Quick Links

Table
Microphone
O P E R A T I O N S M A N U A L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Table Microphone and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Starkey Table Microphone

Summary of Contents for Starkey Table Microphone

  • Page 1 Table Microphone O P E R A T I O N S M A N U A L...

  • Page 3: Table Of Contents

    Wearing the Table Microphone . . . . . . . . . . . . . . . . . .

  • Page 4: Overview

    Starkey Table Microphone is an assistive listening device and TV streamer. It streams audio directly to your 2.4 GHz wireless hearing aids. Key use modes: • Table Microphone: streaming the target voice from a selected direction in the following modes: o Automatic o Manual –...
  • Page 5 Overview | 3 Package Contents • Table Microphone • Power adapter & USB-to-MicroUSB cable • North American power plug • Operations Manual • Pouch • TV streaming cable • Hanger with lanyard • Silicone case...
  • Page 6 4 | Overview 1 . MicroUSB jack 7 . Volume +/- buttons 2 . Directional touch keys 8 . Microphones 3 . Segments 4 . Automatic mode indicator 5 . Mode-switching button 6 . Power button...
  • Page 7 Overview | 5 9 . Hearing aid pairing button 10 . Magnetic interface for hanger...
  • Page 8 6 | Overview 1 . MicroUSB jack • Rechargeable via USB-to-MicroUSB cable • Streams audio via TV streaming cable 2 . Touch keys • Manual selection of a single or dual direction 3 . Segments: • Indicates the selected direction(s) •...
  • Page 9 Overview | 7 7 . Volume +/- buttons • Adjust stream volume 8 . Microphones • Pick up speaker’s voice 9 . Hearing aid pairing button • Pairs and connects to hearing aid(s) 10 . Magnetic interface for hanger • For Remote Microphone mode...

  • Page 10: Indicators

    8 | Indicators Indicators Operational Indicators Recharging Green segments indicate battery charge level. Each segment represents about 1 hour. The blinking green segment indicates the current level. If charging during use, all green segments will briefl y interrupt other indicators when the battery is fully charged.
  • Page 11 Indicators | 9 Product orientation For best performance, make sure the Table Microphone Volume and Power buttons are facing you. Line-in White top segment indicates line-in connection (e.g., TV audio). Volume + White top segment blinks when volume is increased.
  • Page 12 10 | Indicators Pairing Hearing Aid Indicators Blinking Searching for hearing blue aid(s). brackets Solid Hearing aid pairing green successful. brackets Solid red Hearing aid pairing brackets unsuccessful. See “Pairing” on page 13 for more details about pairing monaural or binaural hearing aids.
  • Page 13 Indicators | 11 Conversation Streaming Indicators Automatic Automatic mode indicator ( O ) solid blue. Blue segment indicates active listening direction. Manual single/dual One or two blue segments indicate selected listening direction(s). Surround All blue segments indicate listening in all directions.

  • Page 14: Basic Use

    12 | Basic Use Basic Use 1 . To turn on Table Microphone, press the power button. 2 . The green segments indicate the battery charge level. 3 . Ensure your hearing aids are powered on. Note: Prior to streaming audio...

  • Page 15: Pairing | 13

    Pairing | 13 Pairing For the Table Microphone to interact with your hearing aids, you must first pair it with each hearing aid. You only need to perform this action once, as the Table Microphone and hearing aids should automatically recognize each other when both are powered on and within wireless operating range.*...
  • Page 16 2 . Place your hearing aids within 15cm (6”) of the Table Microphone. 15cm (6”) 15cm (6”) 3 . Press the hearing aid pairing button for 2 seconds and place the Table Microphone face up on a surface. The blinking blue brackets indicate Bluetooth is ready to pair.
  • Page 17 Pairing | 15 4 . For a set of hearing aids: Left Right Pairing Result Next Step Bracket Bracket Both hearing aids Complete paired. Only left hearing Repeat steps aid paired. 1 – 3 Only right hearing Repeat steps aid paired. 1 –...

  • Page 18: Daily Use

    16 | Daily Use Daily Use Power On Press the Power button for 1 second and release. Power Off Press the Power button for 1 second. The green indicators will show the battery level, and the product will be turned off. Battery Low The active direction indicator(s) illuminate in red.
  • Page 19 Table Microphone can be worn by a distant speaker in noisy settings. Tabletop Place your Table Microphone in the middle of a table to listen to a group of people. For best speech understanding, always bring your Table Microphone as close to the conversation partner(s) as possible.
  • Page 20 18 | Daily Use Manual single speaker Tap any segment to focus on a specific speaker. Manual dual speaker Tap and hold (1 second) a second segment to focus on an additional speaker. Surround Tap the Automatic/Surround touch key to listen to multiple people in quiet settings.
  • Page 21 TV Audio Streaming (Line-in) Streaming audio from your TV to your hearing aids Insert the TV streaming cable Audio plug in the Table Microphone microUSB jack. Insert the 3.5mm audio plug of the TV streaming cable in the TV’s audio jack.
  • Page 22 (e.g., a Long Press on a user control) can start/stop streaming. Audio streaming will also stop when the Table Microphone is turned off. An audible indicator may play in your hearing aids to signal the start/stop of audio streaming.

  • Page 23: Wearing The Table Microphone | 21

    Wearing the Table Microphone | 21 Wearing the Table Microphone The Table Microphone can be worn on a lanyard. It should be within 20cm (8”) of the speaker’s mouth. Lanyard • Attach the magnetic hanger to the back of the Table Microphone.

  • Page 24: Assembling The Power Adapter

    22 | Assembling the Power Adapter Assembling the Power Adapter The Table Microphone may include a variety of plug confi gurations for use in different countries. If the power adapter requires assembly: 1 . Select the appropriate plug confi guration used in your country.

  • Page 25: Troubleshooting

    Streamed Bluetooth device Move Bluetooth device audio quality may be on the edge closer to Table Microphone. is inconsistent. of wireless range. Audio stream Volume streamed Press volume + or – button is too loud or from Table on Table Microphone.
  • Page 26 24 | Troubleshooting SYMPTOM POSSIBLE CAUSES SOLUTIONS Table Mic Table Microphone Move Table Microphone Mode: may be too far from closer to speaker’s mouth. Difficult to speaker. hear speaker in noisy environments. Remote Table Microphone Provide clear access from Mic Mode:...

  • Page 27: Safety Information | 25

    Electromagnetic Compatibility. However, it is still possible that you may experience interference caused by power line disturbances, airport metal detectors, electromagnetic fields from other medical devices, radio signals and electrostatic discharges. The Table Microphone is designed to be cleaned with a damp cloth moistened with soapy water.
  • Page 28 The Table Microphone should not be used during an MRI procedure or in a hyperbaric chamber. The Table Microphone is not formally certified to operate in explosive atmospheres such as may be found in coal mines or certain chemical factories.
  • Page 29 Safety Information | 27 The battery in your Table Microphone is not replaceable. Do not attempt to replace the battery. The Table Microphone does not contain any user-serviceable parts. Do not open or modify it. Do not connect the Table Microphone to any devices not described in this manual.

  • Page 30: Regulatory Notices

    Such modifications could void the user’s authority to operate the equipment. Hereby, Nuance Hearing declares that Starkey Hearing Technologies Table Microphone is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. A copy of the Declaration...
  • Page 31 Regulatory Notices | 29 Nuance Hearing 24 Raoul Wallenberg St. Tel Aviv 6971920 Israel Nuance Hearing Packhorse Lane Bibury Cirencester GL7 5NT England This device produces radio frequency energy. Interference may occur in the vicinity of equipment marked with the following symbol.
  • Page 32 Notes...
  • Page 33 Notes...
  • Page 34 Bluetooth SIG, Inc. ® and any use of such marks by Starkey is under license. Starkey logo and Thrive are registered trademarks of Starkey Laboratories, Inc. ©2020 Starkey. All Rights Reserved.
