User's Guide
TPS62050 and TPS62052 Buck Converter Evaluation
Module User's Guide
1
Introduction.............................................................................................................................................................................2
2 Evalulation with the TPS6205xEVM......................................................................................................................................
Jumper...........................................................................................................................................................3
2.2 Synchronization (SYNC) Jumper.......................................................................................................................................
(PG)...............................................................................................................................................................3
(LBO).......................................................................................................................................................3
Layout..............................................................................................................................................................................4
3.1 SLVP234 EVM Schematic and Bill of Materials.................................................................................................................
3.2 PCB Layout of the TPS62050EVM and TPS62052EVM...................................................................................................
History......................................................................................................................................................................6
Trademarks
All trademarks are the property of their respective owners.
SLVU081A - FEBRUARY 2003 - REVISED JULY 2021
Submit Document Feedback
Table of Contents
TPS62050 and TPS62052 Buck Converter Evaluation Module User's Guide
Copyright © 2021 Texas Instruments Incorporated
Table of Contents
3
3
4
5
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments TPS62050
Summary of Contents for Texas Instruments TPS62050
-
Page 1: Table Of Contents
3.2 PCB Layout of the TPS62050EVM and TPS62052EVM....................4 Revision History..................................6 Trademarks All trademarks are the property of their respective owners. SLVU081A – FEBRUARY 2003 – REVISED JULY 2021 TPS62050 and TPS62052 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... -
Page 2: Introduction
The EVMs make it possible to evaluate different modes of the devices as well as the device performance. The TPS6205xEVM is available as the TPS62050 adjustable version set to 3.3 V and the TPS62052 1.5-V fixed version. -
Page 3: Evalulation With The Tps6205Xevm
1.21 V. An external pullup resistor which is placed between LBO and Vout is required to use the LBO. SLVU081A – FEBRUARY 2003 – REVISED JULY 2021 TPS62050 and TPS62052 Buck Converter Evaluation Module User's Guide Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... -
Page 4: Pcb Layout
VOUT SYNC 1.00 M 1.00 M 22 μF 4.7 μF SYNC PWM/PFM 100 k Figure 3-1. TPS6205xEVM Schematic Table 3-1. TPS62050 and TPS62052 EVMs (SLVP234) Bill of Materials COUNT REF DES DESCRIPTION SIZE PART NUMBER TPS62050 TPS62052 Capacitor,Ceramic 1210 Murata... -
Page 5: Pcb Layout Of The Tps62050Evm And Tps62052Evm
PCB Layout Table 3-1. TPS62050 and TPS62052 EVMs (SLVP234) Bill of Materials (continued) COUNT REF DES DESCRIPTION SIZE PART NUMBER TPS62050 TPS62052 Inductor,SMT, 10 0.276sq SLF7032T– mH,1.4 A, 63.6 100M1R4 Resistor,chip, 130 kW,1/16 W, 1% Resistor,chip, 100 kW,1/16 W, 1%... -
Page 6: Revision History
Updated the numbering format for tables, figures, and cross-references throughout the document....2 • Updated user's guide title........................... TPS62050 and TPS62052 Buck Converter Evaluation Module User's Guide SLVU081A – FEBRUARY 2003 – REVISED JULY 2021 Submit Document Feedback Copyright © 2021 Texas Instruments Incorporated... - Page 7 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
