Summary of Contents for MClimate MC-LW-BTN-01
- Page 1 MClimate Multipurpose Button LoRaWAN® User manual...
- Page 2 Scan the QR Code to access MClimate Multipurpose Button LoRaWAN® extended documentation Need some help? For more product information and issues related to it, visit: mclimate.eu/lorawan-resources or write us to: lorawan-support@mclimate.eu Sofia, Bulgaria 00359 800 3 1010 Sofia Tech Park, Monday-Friday labs building, floor 1...
- Page 3 сканирайте QR кода prohlédněte si kód или посетете линка QR nebo navštivte до него. odkaz vedle něj. Italian Polish Per installare MClimate Aby dowiedzieć się, jak Multipurpose Button zainstalować MClimate LoRaWAN® Multipurpose Button scannerizzare il codice LoRaWAN®, zeskanuj QR oppure aprire il kod QR lub odwiedź...
- Page 4 German French Um herauszufinden, Pour savoir wie man MClimate comment installer Multipurpose Button MClimate LoRaWAN® installiert, Multipurpose scannen Sie den Button LoRaWAN®, QR-Code oder scannez le code QR besuchen Sie den Link ou visitez le lien à daneben. côté de celui-ci.
-
Page 5: Table Of Contents
Table of content What is in the box? Technical details, Safety instructions, Legal Notices & Compatibility Device Parts, Mechanical dimensions LEDs, button press types and behaviour 10-11 Commissioning 14-16 Installation 17-18... -
Page 6: What Is In The Box
What’s inside the box? MClimate Multipurpose ER10280 3VDC Button LoRaWAN® battery... -
Page 7: Technical Specifications
Failure to follow the recommended instructions in this manual may be dangerous or in violation of the law. The manufacturer MClimate Jsc., is not responsible for any loss or damage caused by failure to follow the instructions in the operating manual. -
Page 8: Legal Notices & Compatibility
All information, including but not limited to, features, functionality, and / or other product specifications are subject to change without notice. MClimate retains all rights to review or update its products, software or documentation without being required to notify any natural or legal person. -
Page 9: Device Parts
Device parts Button status Assembled MClimate Multipurpose Button LoRaWAN®, top view... - Page 10 Battery holder Disassembled MClimate Multipurpose Button LoRaWAN®, bottom view...
-
Page 11: And Behaviour
LED, Buttons and behaviour There are three separate types of clicks supported by the button. After each click the button waits for 600ms to check if another click is coming. Once the click type has been determined, the device sends a confirmed uplink with the temperature data and the click type information. -
Page 12: Leds Indications
Green LED Side Side (left) (right) Button Red LED LEDs indications: - The GREEN LED is activated while the button is pressed - The side LEDs alternate when the LoRaWAN message is being sent - The GREEN LED lights up when the uplink is sent and acknowledged by the gateway and LNS - If the message has not been successfully acknowledged, the RED LED activates... -
Page 13: Commissioning
Commissioning Before you install the device, we highly recommend that you first commission it on your LNS. Once the battery paper isolator is removed, the device will initiate a LoRaWAN Join Procedure on SF9. Please, make sure you enable ADR in your LNS and/or mark the device as static. - Page 14 Continue the Installation with the instructions of your LoRaWAN® Network provider. You can get DevEUI, AppEUI (JoinEUI) & AppKey information from the LoRaWAN® credentials .csv file we sent you with the fulfillment confirmation.
- Page 15 Commissioning Remove the battery paper isolator from the device.
- Page 16 Open the device If you need to open the device to replace the battery, use the slot indicated in the picture to open the device. Insert the new battery following the direction indicated on the PCB.
- Page 17 Batteries holder Disassembled MClimate Multipurpose Button LoRaWAN®, top view...
-
Page 18: Installation
Installation We recommend installing the device in an open environment (e.g. not in a recess) at 1.5m height. Do not install the device near big metal items as it will worsen the RF performance. Use double-sided tape to attach it to the surface. Double-sided tape... - Page 19 1.5m...
- Page 20 Designed & Manufactured by MClimate in Europe. last update: 07.06.2024...
