Summary of Contents for MClimate MC-LW-BTN-01
- Page 1 MClimate Multipurpose Button LoRaWAN® User manual...
- Page 2 него. Multipurpose Button Slovak Polish Czech Hungarian LoRaWAN® extended Chcete-li zjistit, jak A MClimate Multipurpose Button Ak chcete zistiť, ako Aby dowiedzieć się, jak nainstalovat MClimate LoRaWAN® telepítésének nainštalovať MClimate zainstalować MClimate Multipurpose Button kiderítéséhez keresse meg a Multipurpose Button Multipurpose Button LoRaWAN®,...
- Page 3 Table of content What’s inside the box? What is in the box? Technical details, Safety instructions, Legal Notices & Compatibility Device parts LEDs, button press types and behaviour Commissioning Installation MClimate Multipurpose Button LoRaWAN®...
- Page 4 All information, including but not limited to, features, functionality, and / or other product specifications are Environmental conditions, in which the device is intended to operate: subject to change without notice. MClimate retains all rights - Indoor using; to review or update its products, software or documenta- - for altitude up to 2000m;...
- Page 5 Device parts Button Batteries holder LED status Assembled MClimate Multipurpose Button LoRaWAN®, top view Disassembled MClimate Multipurpose Button LoRaWAN®, bottom view...
- Page 6 LED, Buttons and behaviour Green LED There are three separate types of clicks supported by the button. After each click the button waits for 600ms to check if another click is coming. Once the click type has been determined, the device sends a confirmed uplink with the temperature data and the click type information.
- Page 7 Commissioning Open your LoRaWAN® Network provider access panel and add the Continue the Installation with the instructions of your device using the supplied Serial Number, DevEUI, AppEUI LoRaWAN® Network provider. (JoinEUI) and AppKey. Device ID: 9X7621HS DevEUI: 70B3D25DD30009E1 AppEUI: 70B3D25DD3000000 You can get DevEUI, AppEUI (JoinEUI) &...
- Page 8 If you need to open the device to replace the battery, use the slot indicated in the picture to open the device. Insert the new battery following the direction indicated on the PCB. Batteries holder Disassembled MClimate Multipurpose Button LoRaWAN®, top view...
- Page 9 Installation We recommend installing the device in an open environment (e.g. not in a recess) at 1.5m height. Do not install the device near big metal items as it will worsen the RF performance. Use double-sided tape to attach it to the surface. 1.5m Double-sided tape...
- Page 10 Designed & Manufactured by MClimate in Europe. last update: 20.01.2022...
