Varytec bat.PAR V2 RGBWW User Manual

Led spotlight
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
bat.PAR V2 RGBWW
LED Spotlight

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the bat.PAR V2 RGBWW and is the answer not in the manual?

Questions and answers

Related Manuals for Varytec bat.PAR V2 RGBWW

Summary of Contents for Varytec bat.PAR V2 RGBWW

  • Page 1 V2 RGBWW LED Spotlight...
  • Page 2 Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 Internet: www.thomann.de 02.04.2024, ID: 580501...

  • Page 3: Table Of Contents

    7.3 DMX control............................26 7.4 Dimmer curve............................ 29 7.5 Slave mode............................31 7.6 Automatic programme........................32 7.7 Sound control............................ 34 7.8 Custom colours..........................36 7.9 Colour temperature......................... 37 7.10 W-DMX mode..........................37 7.11 Settings.............................. 40 bat.PAR V2 RGBWW LED Spotlight...
  • Page 4 7.18 Functions in 8-channel DMX mode..................50 7.19 Functions in 12-channel DMX mode..................51 7.20 Functions in 16-channel DMX mode..................53 Technical specifications........................55 Plug and connection assignments....................58 Troubleshooting............................59 Cleaning............................... 61 Protecting the environment......................62 bat.PAR V2 RGBWW LED Spotlight...

  • Page 5: General Information

    Please refer to the latest version of the documentation, which is ready for download under www.thomann.de. 1.1 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this document. bat.PAR V2 RGBWW LED Spotlight...
  • Page 6 This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – dangers due to batteries. Warning – high-voltage. Warning – hot surface. bat.PAR V2 RGBWW LED Spotlight...
  • Page 7 General information Warning signs Type of danger Warning – dangerous optical radiation. Warning – suspended load. Warning – danger zone. bat.PAR V2 RGBWW LED Spotlight...

  • Page 8: Safety Instructions

    Always dispose of packaging material properly when it is not in use. Never allow children to use the device without supervi‐ sion. Keep small parts away from children and make sure that the device does not shed any small parts (such knobs) that children could play with. bat.PAR V2 RGBWW LED Spotlight...
  • Page 9 Remove the lithium batteries before disposing of the device. Cover the poles of used lithium batteries with adhesive tape to prevent short circuits. Electrolyte can escape from damaged lithium batteries. Put the damaged lithium battery in air-tight pack‐ aging. Collect the electrolyte with absorbent paper. Wear rubber gloves while doing so. bat.PAR V2 RGBWW LED Spotlight...
  • Page 10 Never cover the device or the vents. Do not install the device in the immediate vicinity of other heat sources. Never operate the device in the immediate vicinity of naked flames. bat.PAR V2 RGBWW LED Spotlight...
  • Page 11 Risk of fire due to incorrect polarity! Incorrectly inserted batteries may cause fires and destroy the device and the batteries. Observe the markings on the batteries and on the device. Ensure that proper polarity is observed when inserting batteries. bat.PAR V2 RGBWW LED Spotlight...
  • Page 12 The plasticiser contained in the rubber feet of this product may react with the coating of the floor and cause permanent dark stains after some time. If necessary, use a suitable mat or felt slide to prevent direct contact between the device’s rubber feet and the floor. bat.PAR V2 RGBWW LED Spotlight...

  • Page 13: Features

    For technological reasons, the light output of LEDs decreases over their lifetime. This effect increases with higher operating temperature. You can extend the service life of the illuminants by providing adequate ventilation and operating the LEDs with the lowest possible brightness. bat.PAR V2 RGBWW LED Spotlight...

  • Page 14: Installation

    When installing and operating, make sure to follow the standards and regulations that apply in your country. Always secure the device with a secondary safety attachment, such as a safety cable or a safety chain. bat.PAR V2 RGBWW LED Spotlight...

  • Page 15: Mounting Options

    Use the openings provided on the two-piece bracket for attaching. Always work from a stable platform whenever installing, moving or servicing the device. While you do this, the area underneath the device must be cordoned off. bat.PAR V2 RGBWW LED Spotlight...
  • Page 16 Installation The safety cable must be attached to the bracket. Please note that this device must not be connected to a dimmer. bat.PAR V2 RGBWW LED Spotlight...
  • Page 17 Possible damage due to leaking batteries! Batteries can leak and cause permanent damage to the device. Take the batteries out of the device if it is not going to be used for an extended period of time. bat.PAR V2 RGBWW LED Spotlight...

  • Page 18: Starting Up

    If the DMX connections are wired incorrectly, this can cause errors during the data transfer. Do not connect the DMX input and output to audio devices, e.g. mixers or ampli‐ fiers. Use special DMX cables for the wiring instead of normal microphone cables. bat.PAR V2 RGBWW LED Spotlight...
  • Page 19 Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). bat.PAR V2 RGBWW LED Spotlight...

  • Page 20: Connections And Controls

    Connections and controls Connections and controls ö PUSH 20 40 60 80 120 BATTERY INDICATOR DMX IN DMX OUT SWITCH & ' bat.PAR V2 RGBWW LED Spotlight...
  • Page 21 7 [SWITCH] | Main switch. Turns the device on and off. 8 [DMX IN] | DMX input, designed as XLR panel plug, 3-pin 9 [DMX OUT] | DMX output, designed as XLR panel socket, 3-pin bat.PAR V2 RGBWW LED Spotlight...
  • Page 22 If the indicator shows ‘Error’ , there is a problem with the device. Turn off the device and wait until it has cooled off before switching it on again. 6 Shows the currently selected menu. bat.PAR V2 RGBWW LED Spotlight...
  • Page 23 Connections and controls Infrared remote control ö SLAVE AUTO AUTO SPEED & SOUND SOUND DOWN STROBE bat.PAR V2 RGBWW LED Spotlight...
  • Page 24 7 [STROBE] | Activates the strobe effect. 8 [0 … 9] | Number buttons for the direct input of values 9 Buttons for colour selection [W] for white light [R], [G] and [B] for primary colours red, green and blue bat.PAR V2 RGBWW LED Spotlight...

  • Page 25: Operating

    Press [MENU] to activate the main menu. Press [UP] or [DOWN] to change the currently displayed value. When the display shows the desired value, confirm with [ENTER]. Press [MENU] to return to the main menu. bat.PAR V2 RGBWW LED Spotlight...

  • Page 26: Dmx Control

    DMX controller. The following table shows the highest pos‐ sible DMX address for the various DMX modes. Mode Display Highest possible DMX address 2-channel ‘Channel 02’ 3-channel ‘Channel 03’ 5-channel ‘Channel 05’ 8-channel ‘Channel 08’ bat.PAR V2 RGBWW LED Spotlight...
  • Page 27 This setting is only relevant when the device is controlled via DMX. Behaviour if the DMX signal fails Press [MENU] to activate the main menu. Press [UP] or [DOWN] repeatedly until the display shows ‘DMX’ . Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...
  • Page 28 Menu level 3 Menu level 4 Function ‘STATE’ ‘Hold’ If the DMX control fails, the last setting is retained. ‘Black’ If the DMX control fails, the device is blacked out. Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...

  • Page 29: Dimmer Curve

    Inverted square curve with a steep course at the beginning and a flat course at the end (inverse square law) ‘4’ Non-linear curve with a distinctive flat profile at the beginning and end (S-Curve) Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...
  • Page 30 100 % 100 % ö ö ö ö The figure schematically shows the adjustable dimmer curves. Depending on the selected DMX value (1) the device lights up with a brightness (2) between 0% and 100%. bat.PAR V2 RGBWW LED Spotlight...

  • Page 31: Slave Mode

    To deactivate slave mode, activate DMX mode as described under Ä Chapter 7.3 ‘DMX control’ on page 26. This setting is only relevant if the device is not controlled via DMX. bat.PAR V2 RGBWW LED Spotlight...

  • Page 32: Automatic Programme

    This setting is only relevant if the device is not controlled via DMX. The device can operate in stand-alone mode or control connected devices of the same type, that must be configured as slaves. The automatic show can only be activated on the master device. bat.PAR V2 RGBWW LED Spotlight...
  • Page 33 Press [UP] or [DOWN] repeatedly until the display shows ‘SPEED’ . Confirm with [ENTER]. Use [UP] or [DOWN] to select the desired running speed of the automatic programme from ‘Speed1’ (slow) to ‘Speed20’ (fast). Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...

  • Page 34: Sound Control

    This setting is only relevant if the device is not controlled via DMX. The device can operate in stand-alone mode or control connected devices of the same type, that must be configured as slaves. The automatic show can only be activated on the master device. bat.PAR V2 RGBWW LED Spotlight...
  • Page 35 [ENTER]. Press [UP] or [DOWN] repeatedly until the display shows ‘SENS’ . Confirm with [ENTER]. Use [UP] or [DOWN] to select a microphone sensitivity between ‘Sens1’ (low sensitivity) and ‘Sens31’ (high sensitivity). Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...

  • Page 36: Custom Colours

    ‘Red’ ‘0’ … ‘255’ Red intensity ‘Green’ ‘0’ … ‘255’ Green intensity ‘Blue’ ‘0’ … ‘255’ Blue intensity ‘White’ ‘0’ … ‘255’ White intensity ‘Strobe’ ‘0’ … ‘20’ Strobe ‘Color’ ‘1’ … ‘51’ Colour macros bat.PAR V2 RGBWW LED Spotlight...

  • Page 37: Colour Temperature

    Use [UP] or [DOWN] to select either ‘ON’ (device operates as a transmitter) and ‘OFF’ (device does not operate as a transmitter). Confirm with [ENTER]. ð If the connection with the receiver is successful, the indicator on the display lights up green. bat.PAR V2 RGBWW LED Spotlight...
  • Page 38 Use [UP] or [DOWN] to select either ‘ON’ (device operates as a receiver) and ‘OFF’ (device does not operate as a receiver). Confirm with [ENTER]. ð If the connection with the transmitter is successful, the indicator on the display lights up green. bat.PAR V2 RGBWW LED Spotlight...
  • Page 39 Confirm with [ENTER] to cancel an existing connection between the device and a trans‐ mitter or receiver. ð If the connection with a receiver or transmitter is broken, the indicator on the dis‐ play lights up red. bat.PAR V2 RGBWW LED Spotlight...

  • Page 40: Settings

    Press [UP] or [DOWN] repeatedly until the display shows ‘SET UP’ . Confirm with [ENTER]. Press [UP] or [DOWN] repeatedly until the display shows ‘REMOTE’ . Confirm with [ENTER]. Use [UP] or [DOWN] to select either ‘ON’ (remote control active) and ‘OFF’ (remote con‐ trol inactive). Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...

  • Page 41: Display Lighting

    Press [UP] or [DOWN] repeatedly until the display shows ‘BAT USAGE’ . Confirm with [ENTER]. Use [UP] or [DOWN] to choose between ‘6H’ (battery life six hours), ‘8H’ (battery life eight hours) and ‘12H’ (battery life twelve hours) Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...
  • Page 42 Press [UP] or [DOWN] repeatedly until the display shows ‘DIMMER ALL’ . Confirm with [ENTER]. Use [UP] or [DOWN] to select a value between ‘0’ and ‘255’ to adjust the brightness of the LEDs. Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...
  • Page 43 Use [UP] or [DOWN] to choose between ‘Red’ , ‘Green’ and ‘Blue’ . Confirm with [ENTER]. Use [UP] or [DOWN] to select a value between ‘0’ and ‘255’ to adjust the brightness of the selected colour. Confirm with [ENTER]. bat.PAR V2 RGBWW LED Spotlight...

  • Page 44: Device Information

    The device shows the software version. ‘Current Time’ The device displays the current running time of the device. ‘Total Time’ The device shows the total runtime of the device. ‘RDM:UID’ The device displays the UID code. bat.PAR V2 RGBWW LED Spotlight...

  • Page 45: Resetting The Device To Factory Defaults

    Press [UP] or [DOWN] repeatedly until the display shows ‘FACTORY RESET’ . Confirm with [ENTER]. Press [UP], then [DOWN], then [UP], and then [DOWN]. Confirm with [ENTER] to reset the device to the factory defaults. bat.PAR V2 RGBWW LED Spotlight...

  • Page 46: Menu Overview

    ADDRESS PROGRAM MODE SOUND Auto1 Sound1 Green Blue Auto12 Sound10 White CHANNEL SPEED SENS Channel 02 Speed1 Sens1 Channel 03 Speed20 Sens31 Channel 05 Strobe Channel 08 Channel 12 Channel 16 Color STATE Hold Black bat.PAR V2 RGBWW LED Spotlight...
  • Page 47 TRANSMITTER KEY LOCK DIMMER ALL Hardware 3500K Software 4000K Current Time 4500K RECEIVER REMOTE Total Time BALANCE 5000K RDM:UID 6000K Green 7000K RELEASE DISPLAY Blue 8000K Release? 9000K 10000K BAT USAGE MAX TEMP 30°C 70°C bat.PAR V2 RGBWW LED Spotlight...

  • Page 48: Functions In 2-Channel Dmx Mode

    Functions in 3-channel DMX mode Channel Value Function 0…255 Selection of white macros 3000 K to 10000 K 0…255 Fine adjustment, selection of white macros 3000 K to 10000 K 0…255 Master dimmer (0% to 100%) bat.PAR V2 RGBWW LED Spotlight...

  • Page 49: Functions In 5-Channel Dmx Mode

    Functions in 5-channel DMX mode Channel Value Function 0…255 Red intensity (0% to 100%) 0…255 Green intensity (0% to 100%) 0…255 Blue intensity (0% to 100%) 0…255 White intensity (0% to 100%) 0…255 Strobe effect (increasing speed) bat.PAR V2 RGBWW LED Spotlight...

  • Page 50: Functions In 8-Channel Dmx Mode

    0…255 Blue intensity (0% to 100%) 0…255 White intensity (0% to 100%) 0…255 Selection of colour macros 1 to 51 0…255 Selection of white macros 3000 K to 10000 K 0…255 Strobe effect (increasing speed) bat.PAR V2 RGBWW LED Spotlight...

  • Page 51: Functions In 12-Channel Dmx Mode

    Automatic programme 1 to 12 0…255 Running speed of automatic programme (increasing speed) 0…9 No function 10…29 Response behaviour of master dimmer 1 (fast) 30…69 Response behaviour of master dimmer 2 70…129 Response behaviour of master dimmer 3 bat.PAR V2 RGBWW LED Spotlight...
  • Page 52 Function 130…189 Response behaviour of master dimmer 4 190…255 Response behaviour of master dimmer 5 (slow) 0…14 No function 15…59 Dimmer curve 1 60…119 Dimmer curve 2 120…179 Dimmer curve 3 180…255 Dimmer curve 4 bat.PAR V2 RGBWW LED Spotlight...

  • Page 53: Functions In 16-Channel Dmx Mode

    Selection of colour macros 1 to 51 0…255 Selection of white macros 3000 K to 10000 K 0…255 Strobe effect (increasing speed) 0…255 Automatic programme 1 to 12 0…255 Running speed of automatic programme (increasing speed) bat.PAR V2 RGBWW LED Spotlight...
  • Page 54 Response behaviour of master dimmer 3 130…189 Response behaviour of master dimmer 4 190…255 Response behaviour of master dimmer 5 (slow) 0…14 No function 15…59 Dimmer curve 1 60…119 Dimmer curve 2 120…179 Dimmer curve 3 180…255 Dimmer curve 4 bat.PAR V2 RGBWW LED Spotlight...

  • Page 55: Technical Specifications

    1 × XLR panel socket, 3-pin Power supply External power adapter, 100 - 240 V 50/60 Hz Operating voltage 15 V / 5 A, centre positive Battery Battery type Replaceable lithium-ion bat‐ tery pack (item no. 580503) bat.PAR V2 RGBWW LED Spotlight...
  • Page 56 Rating Mounting options standing, hanging Dimensions (W × H × D) 254 mm × 250 mm × 130 mm Weight 2 kg Ambient conditions Temperature range 0 °C - 40 °C Relative humidity 20%…80% (non-condensing) bat.PAR V2 RGBWW LED Spotlight...

  • Page 57: Further Information

    Technical specifications Further information Design Flat Par LED type x-in-1 Floor housing Fanless Remote control Included Housing colour Black Wireless DMX bat.PAR V2 RGBWW LED Spotlight...

  • Page 58: Plug And Connection Assignments

    The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) bat.PAR V2 RGBWW LED Spotlight...

  • Page 59: Troubleshooting

    Use special DMX cables for the wiring instead of normal microphone cables. In the following we list a few common problems that may occur during operation. We give you some suggestions for easy troubleshooting: bat.PAR V2 RGBWW LED Spotlight...
  • Page 60 DMX interface circuit. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. bat.PAR V2 RGBWW LED Spotlight...

  • Page 61: Cleaning

    The fan grids of the device must be cleaned of any contamination, such as dust, etc. on a reg‐ ular basis. Before cleaning, switch off the device and disconnect mains-operated devices from the mains. Only use pH-neutral, solvent-free and non-abrasive cleaning agents. Clean the unit with a slightly damp lint-free cloth. bat.PAR V2 RGBWW LED Spotlight...

  • Page 62: Protecting The Environment

    Dispose the built-in lithium batteries together with the device. Check for an appropriate collection facility. Dispose of the batteries and rechargeable batteries at relevant collection points or through your local waste facility. bat.PAR V2 RGBWW LED Spotlight...
  • Page 63 Also note that waste avoidance is a valuable contribution to environmental protection. Repairing a device or passing it on to another user is an ecologically valuable alternative to disposal. If your old device contains personal data, delete those data before disposing of it. bat.PAR V2 RGBWW LED Spotlight...
  • Page 64 Notes bat.PAR V2 RGBWW LED Spotlight...
  • Page 65 Notes bat.PAR V2 RGBWW LED Spotlight...
  • Page 66 Notes bat.PAR V2 RGBWW LED Spotlight...
  • Page 68 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
