Raymarine AIS700 Installation Instructions Manual
Class b ais transceiver & splitter
Hide thumbs
Also See for AIS700:
- Installation instructions manual (86 pages) ,
- Troubleshooting manual (34 pages) ,
- Quick start manual (2 pages)
Subscribe to Our Youtube Channel
Related Manuals for Raymarine AIS700
Summary of Contents for Raymarine AIS700
- Page 1 AIS700 CLASS B AIS TRANSCEIVER & SPLITTER INSTALLATION INSTRUCTIONS English (en-US) Date: 09-2023 Document number: 87326 (Rev 6) © 2023 Raymarine UK Limited...
- Page 3 Trademark and patents notice Raymarine, Tacktick, Pathfinder, ClearPulse, Truzoom, SeaTalk , SeaTalk , SeaTalkng , and Micronet, are registered or claimed trademarks of Raymarine Belgium. FLIR, Fishidy, Fishing Hot Spots, YachtSense , DockSense, LightHouse, RangeFusion, DownVision, SideVision, RealVision, HyperVision, Dragonfly, Element, Quantum, Axiom, Instalert, Infrared Everywhere, The World’s Sixth Sense and ClearCruise are registered or claimed trademarks of FLIR...
-
Page 5: Table Of Contents
CONTENTS CHAPTER 1 IMPORTANT INFORMATION ......8 CHAPTER 3 PRODUCT AND SYSTEM OVERVIEW... 14 Safety warnings AIS overview ................8 ................ 15 Product warnings Compatible Raymarine® displays ...............8 ........ 16 Regulatory notices ..............9 Axiom 2 multifunction displays ........16 RF safety notice ..............9... - Page 6 USB connection troubleshooting 13.6 ......59 CHAPTER 10 POWER CONNECTIONS......... 41 CHAPTER 14 TECHNICAL SUPPORT ........60 Power connection 10.1 ............42 Product returns process 14.1 ..........61 Raymarine product support and servicing 14.2 .... 62 In-line fuse and thermal breaker ratings ....42...
- Page 7 Learning resources 14.3 ............63 CHAPTER 15 TECHNICAL SPECIFICATION ....... 64 Power specification 15.1 ............65 Environmental specification 15.2 ........65 AIS specification 15.3 .............. 65 GNSS receiver specification 15.4 ........65 External connections 15.5 ............. 65 VHF antenna requirements 15.6 ........
-
Page 8: Chapter 1 Important Information
Warning: FCC Warning (Part 15.21) Safety warnings Changes or modifications to this equipment not expressly approved in writing by Raymarine Incorporated could violate compliance with FCC rules and void the user’s authority to Warning: Product installation and operation operate the equipment. -
Page 9: Regulatory Notices
4. Consult the dealer or an experienced radio / TV technician for help. This product contains no user serviceable components. Please refer all maintenance and repair to authorized Raymarine dealers. Unauthorized repair may affect your warranty. Innovation, Science and Economic Development Canada... -
Page 10: Innovation, Sciences Et Développement Économique Canada (Français)
(used for a VHF DSC radio, for example), then the same MMSI number must be used to program your AIS equipment. AIS disclaimer All information presented by the AIS700 is advisory only, as there is a risk of Important: incomplete and erroneous information. By placing this product into service... -
Page 11: Disclaimer
Equipment marked with the crossed-out wheeled bin symbol indicates that the equipment should not be Raymarine does not warrant that this product is error-free or that it is disposed of in unsorted household waste. compatible with products manufactured by any person or entity other than Local authorities in many regions have established Raymarine. -
Page 12: Chapter 2 Document Information
CHAPTER 2: DOCUMENT INFORMATION CHAPTER CONTENTS • 2.1 Applicable products — page 13 • 2.2 Product documentation — page 13 • 2.3 Document illustrations — page 13... -
Page 13: Applicable Products
Part number Description date of manufacture. The AIS700 is a Class B AIS transceiver with a E70476 All images are provided for illustration purposes only. built-in VHF splitter, used to display real-time... -
Page 14: Chapter 3 Product And System Overview
CHAPTER 3: PRODUCT AND SYSTEM OVERVIEW CHAPTER CONTENTS • 3.1 AIS overview — page 15 • 3.2 Compatible Raymarine® displays — page 16... -
Page 15: Ais Overview
Class B AIS transponders are often not received by the AIS satellites that provide global vessel tracking. (Please note, however, the AIS700 uses SOTDMA technology with a 5 W power output, providing an increased transmission range of approximately 10-12 nautical miles.) AIS should be used only to augment Radar information, not to substitute it. -
Page 16: Compatible Raymarine® Displays
Axiom multifunction displays seconds, meaning that your AIS position would be transmitted every 60 meters travelled. 3.2 Compatible Raymarine® displays The AIS receiver/transceiver is compatible with the MFDs shown below. displays can be connected using either a SeaTalkng ® backbone or NMEA 0183 connection set to 38,400 baud rate. -
Page 17: Gs / Es / Aseries / Eseries / Cseries Multifunction Displays
gS / eS / aSeries / eSeries / cSeries multifunction displays I70 / i70s instrument displays Compatible instrument displays can be connected to the same SeaTalkng ® network. 2. i70s Legacy multifunction displays Note: gS Series E Series Classic and C Series Classic MFDs can only be connected using 2. -
Page 18: Compatible Third-Party Displays
5. C Series Classic MFDs (Connection via NMEA 0183 only) 6. E Series Classic MFDs (Connection via NMEA 0183 only) Compatible third-party displays The AIS receiver/transceiver can be connected to displays manufactured by third-parties. Third-party displays can be connected using either a NMEA 2000 or a NMEA 0183 connection set to 38,400 baud rate. -
Page 19: Chapter 4 Parts Supplied
CHAPTER 4: PARTS SUPPLIED CHAPTER CONTENTS • 4.1 Parts supplied — page 20 • 4.2 Inline fuse requirement — page 20 Parts supplied... -
Page 20: Parts Supplied
This fuse and its fuse holder are NOT supplied with your product, and must be obtained separately, from a marine or electrical retailer. AIS700 unit. For an explanation of the warning symbol shown, refer to the Important Note below. Waterproof fuse holder. - Page 21 • The suitable fuse rating for the thermal breaker is dependent on the number of devices you are connecting. If in doubt consult an authorized Raymarine dealer. • Your product’s power cable may have an in-line fuse fitted, if not then you must add an in-line fuse / breaker to the positive wire of your product’s power connection.
-
Page 22: Chapter 5 Product Dimensions
CHAPTER 5: PRODUCT DIMENSIONS CHAPTER CONTENTS • 5.1 Product dimensions — page 23... -
Page 23: Product Dimensions
5.1 Product dimensions Item Dimension 122.29 mm (4.81 in) 171.65 mm (6.76 in) 113.04 mm (4.45 in) 132.55 mm (5.22 in) 57 mm (2.24 in) 100 mm (3.94 in) Product dimensions... -
Page 24: Chapter 6 Location Requirements
CHAPTER 6: LOCATION REQUIREMENTS CHAPTER CONTENTS • 6.1 Selecting a location — page 25... -
Page 25: Selecting A Location
• Cabling — Ensure the unit is mounted in a location which allows proper EMC installation guidelines routing, support and connection of cables: Raymarine® equipment and accessories conform to the appropriate – Minimum bend radius of 100 mm (3.94 in) unless otherwise stated. Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic –... -
Page 26: Rf Interference
For smaller vessels it may not be possible to achieve this distance. In this product is used. situation ensure that the compass is not affected by the product when it is • Use only ferrites of the correct type, supplied by Raymarine or its powered on. authorized dealers. -
Page 27: Chapter 7 Cables And Connections - General Information
CHAPTER 7: CABLES AND CONNECTIONS — GENERAL INFORMATION CHAPTER CONTENTS • 7.1 General cabling guidance — page 28 • 7.2 Connections overview — page 29 • 7.3 VHF antenna requirements — page 29 Cables and connections — General information... -
Page 28: General Cabling Guidance
• Unless otherwise stated only use cables supplied by Raymarine. • Where it is necessary to use non-Raymarine cables, ensure that they are of Circuit isolation correct quality and gauge for their intended purpose. (e.g.: longer power... -
Page 29: Connections Overview
7.2 Connections overview Connections Suitable cables VHF antenna cable. 3) Antenna connection Connects to VHF antenna. 4) VHF connection VHF radio cable (supplied). Connects to VHF Radio. 5) NMEA 2000 / SeaTalkng Either: connection • A DeviceNet to SeaTalkng Connects to NMEA 2000 or adaptor cable (supplied), or;... - Page 30 • Using a VHF antenna optimized for only AIS frequency operation may permanently damage the AIS700, as VHF radio transmissions are reflected back into the AIS700 due to the poor impedance match of the VHF antenna operating at VHF radio frequencies.
-
Page 31: Chapter 8 Mounting
CHAPTER 8: MOUNTING CHAPTER CONTENTS • 8.1 Mounting the unit — page 32 • 8.2 Mounting the GNSS (GPS) antenna — page 32 Mounting... -
Page 32: Mounting The Unit
Important: If you are replacing a GPS antenna supplied with an older AIS receiver or an AIS700 with an early (low) serial number, please be aware that the mounting diameter (cutout) of the GPS receiver has changed, from Ø44 mm to Ø60 mm. -
Page 33: Chapter 9 Network Connections
CHAPTER 9: NETWORK CONNECTIONS CHAPTER CONTENTS • 9.1 Data connections overview — page 34 • 9.2 USB connection — page 36 • 9.3 NMEA 2000 / SeaTalkng ® connection — page 36 • 9.4 NMEA 0183 connection — page 37 •... -
Page 34: Data Connections Overview
AIS unit’s internal GPS receiver is intended to provide GPS data to the AIS unit only. Therefore, the AIS unit’s GNSS (GPS) receiver should NOT be used to provide GNSS (GPS) data to multifunction displays or any other external device. Raymarine recommends that an additional external NMEA 0183 or SeaTalk GNSS (GPS) receiver is used to provide GNSS (GPS) data to your external... - Page 35 • It is possible to configure the baud rate for each NMEA 0183 port in the ProAIS software. However, this feature is intended for diagnostic and troubleshooting purposes only. The ProAIS2 software can be downloaded from the Raymarine website: www.raymarine.com/software •...
-
Page 36: Usb Connection
Warning: USB device power device. The MMSI and Static Data must be entered only by a Raymarine dealer or other appropriately qualified installer of marine communications Do NOT connect any device to the product’s USB connection... -
Page 37: Nmea 0183 Connection
• When data (e.g. GNSS) is sent to the AIS unit’s NMEA 0183 input set to a low speed Baud Rate (4,800), it cannot be output on the AIS unit’s The AIS700 can transmit and receive NMEA 0183 data, using the NMEA 0183 NMEA 0183 connection at the same Baud Rate. -
Page 38: Gps (Gnss) Antenna Connection
Do NOT connect any other antenna than the one supplied with your AIS700. If the antenna is not connected or connected incorrectly, your AIS700 will operate in Silent mode. In this mode, the AIS700 will not transmit but will still receive. Important:... -
Page 39: Vhf Antenna Connection
9.6 VHF antenna connection reflected back into the AIS700, due to the poor impedance match of the antenna and AIS transceiver frequencies. Although this will not damage the AIS700 (because AIS class B transmissions are of substantially lower Connect a VHF antenna (not supplied) to your AIS700 using the VHF antenna power than VHF transmissions), it could result in the AIS700 triggering a connection. -
Page 40: Vhf Radio Connection
For systems that include a VHF DSC radio, you can share the VHF antenna by connecting your Radio’s VHF antenna connection to the VHF Radio connection on your AIS700. Connect your VHF antenna to the AIS700’s VHF antenna connection. Power/data cable (supplied) 2. -
Page 41: Chapter 10 Power Connections
CHAPTER 10: POWER CONNECTIONS CHAPTER CONTENTS • 10.1 Power connection — page 42 • 10.2 Power distribution — page 42 • 10.3 Grounding — page 44 • 10.4 Power cable extension (12 / 24 V systems) — page 44 Power connections... -
Page 42: Power Connection
• The suitable fuse rating for the thermal breaker is dependent on the number of devices you are connecting. If in doubt consult an authorized Raymarine dealer. • Your product’s power cable may have an in-line fuse fitted, if not then you must add an in-line fuse / breaker to the positive wire of your product’s power connection. - Page 43 Item Item Description Description Waterproof fuse holder containing a suitably-rated inline fuse Circuit breaker must be fitted. For suitable fuse rating, refer to: Inline fuse and Waterproof fuse holder containing a suitably-rated inline fuse thermal breaker ratings. must be fitted. For suitable fuse rating, refer to: Inline fuse and Product power cable.
-
Page 44: Grounding
Item Description Waterproof fuse holder containing a suitably-rated inline fuse must be fitted. For suitable fuse rating, refer to: Inline fuse and thermal breaker ratings. Product power cable. More information It is recommended that best practice is observed in all vessel electrical installations, as detailed in the following standards: •... - Page 45 Cable length in meters Wire gauge in AWG Wire gauge in AWG (feet) ) for 12 V supply ) for 24 V supply <8 (<25) 16 (1.31 mm 18 (0.82 mm 16 (50) 14 (2.08 mm 18 (0.82 mm 24 (75) 14 (2.08 mm 16 (1.31 mm >32 (>100)
-
Page 46: Chapter 11 Set Up And Configuration
CHAPTER 11: SET UP AND CONFIGURATION CHAPTER CONTENTS • 11.1 IMPORTANT — Configure before use — page 47 • 11.2 AIS licensing and MMSI — page 47 • 11.3 Licensing and MMSI issuing authorities — page 47 • 11.4 Configuration — page 50 •... -
Page 47: Important - Configure Before Use
In the United States of America (USA), the MMSI and Static Data must be • Once the MMSI number has been entered using the ProAIS2 software and entered only by a Raymarine® dealer or other appropriately qualified installer the configuration saved (via the “Write Configuration” option), the MMSI of marine communications equipment for marine vessels. - Page 48 Country & regulatory authority Website Country & regulatory authority Website Austria (AT): http://www.rtr.at Denmark (DK): https://ens.dk/en Austrian Regulatory Authority Danish Energy Agency for Broadcasting and Estonia (EE): http://www.konkurentsi- Telecommunications amet.ee/?lang=en Estonian Competition Authority Belgium (BE): http://www.bipt.be Finland (FI): http://www.ficora.fi/en Belgian Institute for Postal services Finnish Communications Regulatory and Telecommunications (BIPT) Authority...
- Page 49 Country & regulatory authority Website Country & regulatory authority Website Ireland (IE): http://www.comreg.ie Malta (MT): http://www.mca.org.mt Commission for Communications Malta Communications Authority Regulation Mexico (MX): http://www.ift.org.mx Isle of Man (IM): http://www.gov.im/govern- Instituto Federal de Telecomunica- ment/boards/cc.xml Communications Commission ciones Italy (IT): http://www.agcom.it New Zealand (NZ): http://www.comcom.govt.nz...
-
Page 50: Configuration
Telecommunications Regulatory Authority of the Slovak Republic 11.4 Configuration South Africa (ZA): http://www.icasa.org.za Independent Communications The AIS700 should be configured prior to installation, using a PC/laptop, USB Authority of South Africa Micro-B cable, and the proAIS2 software. Spain (ES): https://www.cnmc.es/en Note: Comisión Nacional de los Mercados... -
Page 51: Installing Proais2 Software And Usb Drivers
The following vessel-related static data should be configured: device. The MMSI and Static Data must be entered only by a Raymarine dealer or other appropriately qualified installer of marine communications •... -
Page 52: Viewing Ais Data On A Display
6. Ensure that the built-in GNSS receiver is not outputting NMEA sentences (i.e. ensure GBS, GGA, GLL and RMC boxes are not ticked). The GNSS receiver built-in to the AIS700 is intended to provide GNSS data to the AIS unit only, outputting this data can cause data conflicts. -
Page 53: Software Updates
The MFD used to perform the software update must be the designated Data master and be connected via SeaTalkng ® / NMEA 2000 to the product being updated. Please refer to Raymarine website for instructions on how to use your MFD to perform a software update: www.raymarine.com/software If in doubt as to the correct procedure for updating your product software, refer to your dealer or Raymarine technical support. -
Page 54: Chapter 12 Maintenance
CHAPTER 12: MAINTENANCE CHAPTER CONTENTS • 12.1 Routine equipment checks — page 55 • 12.2 Product cleaning — page 55... -
Page 55: Routine Equipment Checks
12.1 Routine equipment checks It is recommended that you perform the following routine checks, on a regular basis, to ensure the correct and reliable operation of your equipment: • Examine all cables for signs of damage or wear and tear. •... -
Page 56: Chapter 13 Troubleshooting
CHAPTER 13: TROUBLESHOOTING CHAPTER CONTENTS • 13.1 Power up troubleshooting — page 57 • 13.2 AIS data troubleshooting — page 57 • 13.3 VSWR Alarm troubleshooting — page 59 • 13.4 Data conflicts and data loops — page 59 • 13.5 LED Status indicator —... -
Page 57: Power Up Troubleshooting
Software corruption In the unlikely event that the product’s software Product does not turn on or keeps turning off: has become corrupted, please try re-flashing the product with the latest software from the Raymarine Possible causes Possible solutions website: www.raymarine.com/software... -
Page 58: Vhf Antenna Requirements
AIS700, as VHF radio transmissions are reflected AIS configuration, Disconnect all connections then connect only the back into the AIS700 due to the poor impedance match of the VHF static data is not USB cable to a PC and retry configuration. -
Page 59: Vswr Alarm Troubleshooting
13.3 VSWR Alarm troubleshooting Color Status Green Transceiver is powered up and operating normally. If you experience regular VSWR alarms try the troubleshooting guidance Amber Transceiver is not transmitting. below. • Wait at least 30 minutes to check that a ‘Quiet time’ has not Possible causes Possible solutions been requested by the local authority. -
Page 60: Chapter 14 Technical Support
CHAPTER 14: TECHNICAL SUPPORT CHAPTER CONTENTS • 14.1 Product returns process — page 61 • 14.2 Raymarine product support and servicing — page 62 • 14.3 Learning resources — page 63... -
Page 61: Product Returns Process
Many returned products are found to be not faulty. Before returning your product to Raymarine, please first conduct some basic troubleshooting to get up and running with your product. The Raymarine Product Support team is also available to take you step-by-step through any issues you might have. -
Page 62: Raymarine Product Support And Servicing
Italy (Raymarine subsidiary): Raymarine offers dedicated service departments for warranty, service, and repairs. • E-Mail: support.it@raymarine.com Don’t forget to visit the Raymarine website to register your product • Tel: +39 02 9945 1001 for extended warranty benefits: https://www.raymarine.com/en- Spain (Authorized Raymarine distributor): us/support/product-registration •... -
Page 63: Learning Resources
Russia (Authorized Raymarine distributor): • E-Mail: info@mikstmarine.ru • Tel: +7 495 788 0508 14.3 Learning resources Raymarine has produced a range of learning resources to help you get the most out of your products. Video tutorials Raymarine official channel on YouTube •... -
Page 64: Chapter 15 Technical Specification
CHAPTER 15: TECHNICAL SPECIFICATION CHAPTER CONTENTS • 15.1 Power specification — page 65 • 15.2 Environmental specification — page 65 • 15.3 AIS specification — page 65 • 15.4 GNSS receiver specification — page 65 • 15.5 External connections — page 65 •... -
Page 65: Power Specification
15.1 Power specification 15.4 GNSS receiver specification Specification Specification Supply voltage: 12 V dc / 24 V dc Channels: 9.6 V dc to 31.2 V dc Operating voltage range: Cold start acquisition: 26s (nominal) Peak current: • 2.5A @ 12 V dc Position source: •... -
Page 66: Vhf Antenna Requirements
• Using a VHF antenna optimized for only AIS frequency operation may permanently damage the AIS700, as VHF radio transmissions are reflected back into the AIS700 due to the poor impedance match of the VHF antenna operating at VHF radio frequencies. -
Page 67: Chapter 16 Spares And Accessories
CHAPTER 16: SPARES AND ACCESSORIES CHAPTER CONTENTS • 16.1 Spares and accessories — page 68 • 16.2 SeaTalkng ® cables and accessories — page 68 Spares and accessories... -
Page 68: Spares And Accessories
16.1 Spares and accessories The following spares are available: Part number Description R62241 GNSS passive antenna with 10 m (32.8 ft) coaxial cable (for AIS transceivers only) R32162 2 m (6.56 ft) Power/data cable 16.2 SeaTalkng ® cables and accessories SeaTalkng ®... - Page 69 2. 1 x Spur cable 1 m (3.3 ft) (part number: A06040). Used to connect device NMEA 0183 VHF 2 wire to SeaTalkng converter kit (part number: E70196) to the SeaTalkng backbone. consists of: 3. 1 x Power cable 2 m (6.6 ft) (part number: A06049). Used to provide 12 V dc power to the SeaTalkng backbone.
- Page 70 • Backbone cable 0.4 m (1.3 ft) (part number: A06033). • Backbone cable 1 m (3.3 ft) (part number: A06034). • Backbone cable 3 m (9.8 ft) (part number: A06035). • Backbone cable 5 m (16.4 ft) (part number: A06036). •...
- Page 71 5-Way connector (part number: A06064). Each connector block allows SeaTalkng backbone via the SeaTalk to SeaTalkng converter, or to connection of up to 3 SeaTalkng devices. Multiple connector blocks connect a SeaTalkng product directly to a SeaTalk network. can be ‘daisy chained’ together. 2.
- Page 72 10. DeviceNet (female) to stripped-end adaptor cable (0.4 m (1.3 ft) (part number: E05026). 11. DeviceNet (male) to stripped-end adaptor cable (0.4 m (1.3 ft) (part number: E05027).
-
Page 73: Appendix A Licensing And Mmsi Issuing Authorities
Appendix A Licensing and MMSI issuing authorities Country & regulatory authority Website Croatia (HR): http://www.hakom.hr/de- The following table lists the relevant issuing authority for licences and MMSI fault.aspx?id=7 numbers in each region, along with a link to the relevant website. Many Croatian Post and Electronic authorities allow you to apply for a license online. - Page 74 Country & regulatory authority Website Country & regulatory authority Website Hungary (HU): http://www.nmhh.hu Luxembourg (LU): http://www.ilr.public.lu National Media and Infocommunica- Institut luxembourgeois de tion Authority régulation Iceland (IS): http://www.pfs.is/de- Latvia (LV): https://www.vases.lv/lv/con- fault.aspx?cat_id=101 tent/juras-sakaru-atlaujas Post and Telecom Administration Elektronisko sakaru direkcija Indonesia (ID): http://www.brti.or.id Malaysia (MY):...
- Page 75 Country & regulatory authority Website Country & regulatory authority Website Romania (RO): http://www.ancom.org.ro/en Switzerland (CH): http://www.bakom.admin.ch/the- men/frequenzen/00689/01563/in- National Authority for Management Office fédéral de la communication dex.html?lang=fr and Regulation in Communications of Romania Taiwan (TW): http://www.ncc.gov.tw/english/in- dex.aspx Russia (RU): https://minsvyaz.ru/en National Communications Commission Ministry of Telecom and Mass...
-
Page 76: Appendix B Nmea 0183 Supported Sentences
Appendix B NMEA 0183 supported sentences Appendix C NMEA 2000 supported PGNs The AIS700 supports the following NMEA 0183 sentences The AIS700 supports the following PGNs. Sentence Description Description ABM/BBM acknowledgement (Transmit) 59392 ISO Acknowledgement (Transmit / Receive) Addressed binary message (Receive) -
Page 77: Appendix D Ais Limitation
Appendix D AIS limitation Description 129809 AIS class B CS static data report part A (Transmit) Never assume that your AIS is detecting all vessels in the area. Always exercise due prudence and do not use AIS as a substitute for sound 129810 AIS class B CS static data report part B (Transmit) navigational judgement. -
Page 78: Appendix E Classes Of Ais
Appendix E Classes of AIS Appendix F Data Summary Class A transceivers Receiver Transceiver Transceiver Data (receive) (transmit) (receive) Class A AIS transceivers transmit and receive AIS signals. AIS transceivers are currently mandatory on all commercial vessels exceeding 300 tons that Ship's name travel internationally (SOLAS vessels). - Page 79 Data reporting intervals Ship’s Dynamic Conditions Reporting rate (nominal) AIS information is classed as either static or dynamic. Static information is CSTDMA – 0 to 2 knots 3 Minutes broadcast, when data has been amended, or upon request, or by default, CSTDMA –...
- Page 81 Index GNSS antenna ..................38 GPS antenna ..................38 Ground....................29 Grounding.................... 44 Accessories Inputs / Outputs ................34, 37 SeaTalkng adaptor cables ..............71 NMEA....................29 SeaTalkng backbone cables ............... 70 NMEA 0183 ..................34, 37 SeaTalkng cables ................68 NMEA 2000 ..................
- Page 82 Baud rate ..................34, 37 Multiplexed ..................34, 37 Fuse rating..................20, 42 Ports....................34, 37 Fuse requirement ..................20 wire colors ................... 37 Grounding ....................44 Parts supplied..................20 Power Battery connection................43 Installation Cable extension ................... 44 Best practice ..................44 Distribution ..................
- Page 83 Technical specification ................64 AIS specification .................. 65 Environmental specification..............65 External connections ................65 GNSS receiver specification ..............65 Power specification................65 Technical support................62–63 Thermal breaker rating..............20, 42 Training courses ..................63 Troubleshooting ..................57 AIS data ....................57 Power....................
- Page 86 Raymarine (UK / EU) Marine House, Cartwright Drive, Fareham, Hampshire. PO15 5RJ. United Kingdom. Tel: (+44) (0)1329 246 700 www.raymarine.co.uk Raymarine (US) 110 Lowell Road, Hudson, NH 03051. United States of America. Tel: (+1) 603-324-7900 www.raymarine.com...
