  • Page 4: Introduction

    I N T R O D U C T I O N Introduction: The ADJ PinPoint Gobo is part of a continuing pursuit to create high quality intelligent lighting. This device is a battery powered GOBO projector powered by a 10-Watt cool white LED, and features 4 standard removable GOBOs, 4 color gels, and a frost filter to diffuse the beam for wider washes of light.

  • Page 5: Limited Warranty (Usa Only)

    All shipping charges must be pre-paid. If the requested repairs or service (including parts replacement) are within the terms of this warranty, ADJ Products, LLC will pay return shipping charges only to a designated point within the United States. If the entire instrument is sent, it must be shipped in its original package. No accessories should be shipped with the product.

  • Page 6: Warranty Registration | General Instructions | Features

    F E A T U R E S • Capable of Running on DC or Battery Power • Dimming 0-100% • Fast Fade and Slow Fade • UC IR Remote Compatible (Not Included) • ADJ LED RC3 Compatible (Not Included)

  • Page 7: Safety Precautions

    S A F E T Y P R E C A U T I O N S • To reduce the risk of electrical shock or fire, do not expose this unit rain or moisture • Do not spill water or other liquids into or on to your unit. •...

  • Page 8: Battery Precautions

    Never soak or drop the batteries in liquids such as water, seawater, beverages, juices, coffee or any other liquids. 2.6 Battery Replacement For battery replacement, please contact ADJ customer support (800) 322-6337. 2.7 Do Not Use a Damaged Battery Should the battery be found to be damaged (including damage to the plastic casing, deformation of the battery package, odor of an electrolyte or other chemical, or leakage of the electrolyte gel, among other damages) DO NOT use the battery.
  • Page 9 B A T T E R Y P R E C A U T I O N S 3. BATTERY STORAGE Store the battery at room temperature, with a charge of at least 50%. During long periods of storage, it is recommended that the battery be charged every 6 months. Doing so will prolong the life of the battery and will also make sure that the battery charge does not fall below the 30% mark.

  • Page 10: Installation | Color Filter Installation

    C O L O R F I L T E R I N S T A L L A T I O N The PinPoint Gobo comes with 4 color filters and a frost filter. To install any of the filters, follow the steps below: 1.

  • Page 11: Gobo Installation | Focus And Zoom Adjustment

    G O B O I N S T A L L A T I O N The PinPoint Gobo comes with 4 replaceable gobos (see below). To install a gobo, follow the direc- tions below: 1. Remove the gobo holder by unscrewing the thumb screw that is located at the top of the fixture.

  • Page 12: Uc Ir Remote

    U C I R R E M O T E The UC IR (sold separately) infrared remote gives you control of various functions (See below). To control the fixture you must aim the remote at the front of the fixture and be no more than 30 feet away.

  • Page 13: Adj Led Rc3 Remote

    The ADJ LED RC3 infrared remote (sold separately) has many different functions and gives you complete control of your PinPoint Gobo. For best results, aim the controller at the front of the fixture. Maximum range is 30 feet. Please note that the ADJ LED RC3 remote can only be used when the fixture is in primary mode.

  • Page 14: Photometric Chart | Battery Charging | Cleaning

    P H O T O M E T R I C C H A R T B A T T E R Y C H A R G I N G To recharge the battery, simply plug the included power supply into the socket on the side of the unit, and connect the other end to a power source whose voltage matches the unit’s requirements.

  • Page 15: Specifications

    Light Output: 876 LUX @2M; 203 LUX @4M (17-degree beam) • Refresh Rate: 1KHz • ADJ UC IR Remote Control & ADJ LED RC3 Control (Sold Separately) • Dimensions (LxWxH): 9.75” x 4” x 2.75” / 245 x 102 x 70mm •...
