OPERATION MANUAL
EN
77-3152-2
IntelliFlow™ RF2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ransburg IntelliFlow RF2 and is the answer not in the manual?

Questions and answers

Related Manuals for Carlisle Fluid Technologies Ransburg IntelliFlow RF2

Summary of Contents for Carlisle Fluid Technologies Ransburg IntelliFlow RF2

  • Page 1 OPERATION MANUAL 77-3152-2 IntelliFlow™ RF2...
  • Page 2 ADDITIONAL RESOURCES For additional information or copies of your IntelliFlow Flow Meter manual, please visit us online at: https://carlisleft.com Or use this QR code with your mobile device: 77-3152-2 R1.0 (05/2024) www.carlisleft.com...
  • Page 3 Chapter 03. Safety–Safety, hazard, and warning rules. All current and applicable certifications shown in this Chapter 04. Getting Started–Generalized explanatory manual confirm Carlisle Fluid Technologies' adherence to overview of the operation devices and HMI touchscreen. the strict standards met to obtain the required regulatory compliances.
  • Page 4 INTRODUCTION RF2 RELATED MANUALS & PUBLICATIONS Part Number Description 77-3152-1 RF2 Installation Manual 77-3152-3 RF2 Service Guide 77-3152-4 RF2 Kit Instructions and Spare Parts 77-3152-5 RF2 Programming Manual 77-3154 Flow Meter Kit 77-3155 Remote Fluid Panel Kit-Barrier and F.O. Transceiver Box 77-3156 Flow Meter Sensor Battery Repladement Kit 77-3157...

  • Page 5: Table Of Contents

    02. TABLE OF CONTENTS 02 CONTENTS 03 SAFETY 03.1 SAFETY PRECAUTIONS AND HAZARDS ......................1 03.2 ADDITIONAL SAFETY INFORMATION ....................... 7 04 GETTING STARTED 9-16 04.1 OVERVIEW OF OPERATION DEVICES ....................... 9 04.2 HMI TOUCHSCREEN ............................9 04.3 EMERGENCY STOP (E-STOP) BUTTON ......................10 04.4 STACK LIGHT ...............................
  • Page 6 02. TABLE OF CONTENTS 05.6.3 ADD USER ............................54 05.6.4 DELETE USER ............................54 05.6.5 USER PERMISSIONS ..........................55 06 OPERATION 57-84 06.1 STARTUP GUIDE ............................57 06.1.1 STARTUP CHECKLIST ........................... 57 06.1.1.1 AIR CONNECTIONS ........................57 06.1.1.2 FLUID CONNECTIONS ......................... 57 06.2 OPERATION..............................

  • Page 7: Safety Precautions And Hazards

    Notice: Indicates information considered important but WARNING not hazard related. The hazards shown on the pages that follow can occur during the normal use of this Carlisle Fluid Technologies SAFETY equipment, but not all listed hazards will be applicable to your product model or equipment.

  • Page 8: Safety

    03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Spray Areas Fire Hazards Fire extinguishing equipment must be present in the spray area. Periodically run a test to make sure the Improper or unsatisfactory equipment stays usable.
  • Page 9 03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Spray Areas Explosion Hazard Prevent electrostatic arcing. Maintain spark-safe work distance between the parts that get coated and Improper or unsatisfactory the applicator. A span of one inch for every 10KV of operation and maintenance output voltage is necessary.
  • Page 10 03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Spray Area High Electrical Discharge Operators in the spray area and the parts to be sprayed must be sufficiently grounded. Voltage Equipment This equipment contains a All conductive objects inside the spray area must be high-voltage device that can grounded.
  • Page 11 03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Spray Areas Toxic Fluid or Fumes Read the Safety Data Sheet (SDS) for instructions to know and understand how to handle the specific Toxic fluids or fumes can hazards of the fluids used, and the effects of long- cause severe injury or death if term exposure.
  • Page 12 03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Equipment Skin and Clothing Burns Do not touch hot fluid or equipment during operation. and Fluids Equipment surfaces and fluids Do not let clothing touch the equipment during can become very hot during operation or immediately after the equipment is operation.
  • Page 13 03. SAFETY AREAS HAZARDS SAFEGUARDS Indicate possible Indicate possible hazards. Prevention of possible hazards. hazard occurrences. Spray Areas Do Not Touch Do not use a rag or gloved hand against the bell edge to stop or slow down a bell during rotation. The effect of paint flow rates Do not try to clean the bell edge during rotation.

  • Page 14: Additional Safety Information

    03. SAFETY CAUTION Only operate the equipment after you have read this section. 03.2 ADDITIONAL SAFETY INFORMATION The IntelliFlow has an emergency stop (E-Stop) pushbutton on the main operator panel. During an emergency, all operations for the IntelliFlow will halt when the E-Stop is engaged. The operator must disengage the E-Stop and reset the system to recover from this state.

  • Page 15: Getting Started

    04. GETTING STARTED 04 GETTING STARTED 04.1 OVERVIEW OF OPERATION DEVICES The controller enclosure at the top of the machine contains the primary devices that the operator will use to operate it. WARNING The machine uses high voltage. Servicing must be done only by qualified personnel to prevent accidental electrocution injury or equipment component damage.

  • Page 16: Emergency Stop (E-Stop) Button

    04. GETTING STARTED 04.3 EMERGENCY STOP (E-STOP) BUTTON The IntelliFlow panel incorporates an E-Stop button on the front panel, along with an additional unused set of normally open and normally closed contacts, for customer use to interlock other system functions. The emergency stop (E-Stop) button (b) is an electromechanical device that, when activated by human action, shuts down the machine.

  • Page 17: Power On-Main Supply Switch

    04. GETTING STARTED 04.5 MAIN DISCONNECT SWITCH The main disconnect switch (d) is a device used to control machine power. It turns the machine control panel on and off from the power source. It energizes for operation and de-energizes for shut-down or during maintenance.

  • Page 18: Navigation

    04. GETTING STARTED 04.7 NAVIGATION The main run screen is the primary screen for all machine operations. From this screen, the operator can start and stop operations, load materials, and flush the system. The screen also allows access to all system settings and configurations.

  • Page 19: Drop-Down Menu

    04. GETTING STARTED 04.8 DROP-DOWN MENU The touchscreen uses drop-down and fly-out menus to navigate to the different functions, settings, and adjustments. Access to specific functions is limited by the administrator for designated users. To access the main drop-down menu, click on the "MENU"...

  • Page 20: Languages

    04. GETTING STARTED 04.9 LANGUAGES The touchscreen displays a defined number of available languages to let the user operate the system in their native language. NOTICE Regardless of the operator-selected language, not all objects can be translated during run-time. Some of these include the user-defined fields of station, gun, channel, output names, and some of the internal touchscreen menus.

  • Page 21: Log In

    04. GETTING STARTED 04.10 LOG IN The log in screen lets users who are members of the "admin" group access functions that are not available to other users and to modify the access for other users. For more information on user options, refer to Chapter 05 Configuration, section 05.6 User Management.
  • Page 22 04. GETTING STARTED This page intentionally left blank. 77-3152-2 R1.0 (07/2024) 16 / 106 www.carlisleft.com...

  • Page 23: Configuration

    05. CONFIGURATION 05.1 CONFIGURATION 05.1.1 SYSTEM SETUP In addition to the multiple configurations of the RF2’s physical hardware, the flow control processes can vary greatly from one application to another. Before the system can be operated, it must be configured to match the machine's physical hardware and the user process.

  • Page 24: Setup Main

    05. CONFIGURATION 05.1.2 SETUP MAIN 1. When the "Exor Internal Menu" (a) button is pressed, it opens a pop-up screen to the internal settings so the Exor operator interface can be modified. 2. The "System Configuration" (b) button opens the system configuration screen, where the operator can adjust the system's operation.

  • Page 25: System Configuration

    05. CONFIGURATION 05.1.4 SYSTEM CONFIGURATION System configuration is a group of five screens that are used to define the hardware installed on the RF2. Once entered, these screens cannot be exited until all five screens have been completed, then the system will automatically reboot after the last screen is completed.

  • Page 26: Channels

    05. CONFIGURATION 05.1.4.2 Channels This screen lets the user configure channels that were previously selected in the previous screen for use by a Mixer. 1. Description (a). Each unit can be named. This name will be displayed on the main screens and will be used to reference the channel.

  • Page 27: Stations, Mixer Accesories, And External Communications

    05. CONFIGURATION 05.1.4.3 Stations, Mixer Accessories, and External Communications Station definitions include: 1. Station assignments (a): Each Mixer configured can be assigned to either station #1 or 2. 2. Description (b): Description of each station that is used to reference stations throughout the operator interface.

  • Page 28: Solenoid Manifolds, And Pressure/Regulators Output

    05. CONFIGURATION 05.1.4.4 Solenoid Manifolds and Pressure/ Regulator Outputs Solenoid Manifolds (a): Up to four solenoid manifolds may be used by the RF2 (each having up to 16 2-solenoid modules). Manifold #1 is always enabled and must be used. Pressure Outputs (b): The RF2 can control up to eight pressure regulators.

  • Page 29: Function Configuration

    05. CONFIGURATION 05.1.4.6 Station Accessories A station Solvent Flow meter can be installed to accurately track the amount of solvent used. Any unused channel inputs can be used as a station solvent flow meter. Options are assigned Channels 1-4. Only unassigned channels will be selectable as shown in the image.

  • Page 30: Output Setup

    05. CONFIGURATION 05.2 OUTPUT SETUP 05.2.1 OUTPUT CONFIGURATION Outputs define the description, type, and interlocks for each output of the solenoid manifold. To change these settings: 1. Click on the "MENU" button (a) to open the drop- down menu, then click on the "SETUP" button from the main drop-down menu.

  • Page 31: Default Configuration

    05. CONFIGURATION 05.2.2 DEFAULT CONFIGURATION The RF2 can control external air signals; these include gun trigger and dump signals. Every solenoid controlled by the RF2 is programmable, so the individual port location for any signal depends on the programmed location for that signal. The standard RF2 configuration will be programmed from the factory with a list of signals.

  • Page 32: Editing Outputs

    05. CONFIGURATION 05.2.3 EDITING OUTPUTS 1. When a manifold is selected, it causes the list of solenoids in the manifold (a) to be updated. Each output on the manifold (0-31) can be selected. Note that the outputs are arranged in two columns (Port 4 and Port 2), and their orientation represents the view of the back of the solenoid manifold, looking at the air connections.

  • Page 33: Configure Output

    05. CONFIGURATION 05.2.3.1 Configure Output Parameters to be modified in the "Configure Output" pop- up screen are: 1. Description (a): Label each output the same as any tubing labels connected to the solenoid valve. 2. Output Type Selection (b): The different output types in the section are: Unused ii.

  • Page 34: Swap Outputs

    05. CONFIGURATION 3. Output ID (c): Depending on the type selection, different values will be asked for: Station Number: For Sequence Output or Material CCV output types, this represents the station to which the output is assigned. ii. Mixer Number: For Trigger output types, this represents the gun or mixer to which the output is assigned.

  • Page 35: Sequences

    05. CONFIGURATION 05.3 SEQUENCES Sequences are user-programmable routines used when the system is loaded and flushed. Sequences can be called automatically when a recipe is loaded, changed, or flushed, or they can be called manually for flushing. The RF2 supports up to 16 sequences. The sequences consist of 12 timed steps with user-selectable step times.

  • Page 36: Sequence Definitions

    05. CONFIGURATION 05.3.1 SEQUENCE DEFINITIONS 1. Up to sixteen programmable sequences can be given user-specified names (a). 2. Programmable sequences can be enabled or disabled (b) depending on whether they are necessary for the user's process. If a sequence is disabled, it will not appear on the main run screen, sequence editor, or in the recipe editor.

  • Page 37: Function Configuration

    05. CONFIGURATION 05.3.2 FUNCTION CONFIGURATION To access this screen, press: "Function Configuration" (a) button on the Setup Main screen. www.carlisleft.com 31 / 106 77-3152-2 R1.0 (07/2024)

  • Page 38: Edit Selected Function

    05. CONFIGURATION 05.3.2.1 Edit Selected Function The functions can be selected along the left side of the screen. There are fifty functions available per station. When a function is selected, its configuration information is shown on the right-hand side of the screen. These parameters can be modified by changing the parameters.
  • Page 39 05. CONFIGURATION 05.3.2.2 Select Standard Outputs Any solenoid can be turned on during a sequence. To turn on a solenoid, assign it to a sequence function. The select output menu is used to select an output to assign to a function. If an output is not set up as a sequence output, it can still be activated when used as part of a sequence.

  • Page 40: Select Standards Outputs

    05. CONFIGURATION 05.3.2.3 Select Function Outputs System outputs are predefined outputs used internally to the system to activate certain features, etc. Just like configured outputs, these are called by function. Options available are: 1. Station "x" Load (a): Tells the system when the material is being loaded or when the system is being flushed.

  • Page 41: Fluid Sequences

    05. CONFIGURATION 05.3.3 FLUID SEQUENCES To access the Fluid Sequences screen, press the "Fluid Sequences" button (a) in the Setup Main screen. www.carlisleft.com 35 / 106 77-3152-2 R1.0 (07/2024)

  • Page 42: Fluid Sequence Definitions

    05. CONFIGURATION 05.3.3.1 Fluid Sequence Definitions Sequences define timing and which functions are active per step in each fluid sequence. To change a sequence: 1. Select the station by pressing the "Station 1" or "Station 2" (b) buttons. The selected station will be highlighted.
  • Page 43 05. CONFIGURATION 7. The list of functions (a) that are used in the selected sequence will be shown. 8. Each function represents a sequence row (b), and pressing the buttons in each column will enable or disable the function in the given step. Buttons are highlighted blue when selected and white when not.

  • Page 44: Edit Sequence Text

    05. CONFIGURATION 05.3.4 EDIT SEQUENCE TEXT The sequence description editor screen lets the user add user-defined text that is displayed for each step of a sequence. Each sequence has its own set of 12 user- defined strings. The default values are shown below. The text fields on the editor screen for the sequence description are the same as those on the sequence run screen.

  • Page 45: Other Setup Screens

    05. CONFIGURATION 05.4 OTHER SETUP SCREENS 05.4.1 GLOBAL CONFIGURATION Global Configurations (a) affect system behavior regardless of the recipe that is loaded. Within global configurations are three settings: Global Setup (b) • Alarm Masking (c)* • • Display Preferences (d) Date Time (e) •...

  • Page 46: Global Setup

    05. CONFIGURATION 05.4.2 GLOBAL SETUP Global parameters affect system behavior regardless of the recipe that is loaded; press "Global Setup" (a) on the Main Setup screen. Parameters that are not relevant based on the system configuration will not be shown. 1.

  • Page 47: Display Preferences

    05. CONFIGURATION 05.4.3 DISPLAY PREFERENCES The display preferences screen lets the various items to be changed that do not affect system performance, but affect the way that data is displayed to the user, to include language and unit of measure selections. 1.

  • Page 48: In-Booth Control-Remote Color Change Box Configuration

    05. CONFIGURATION 05.4.4 IN-BOOTH CONTROL–REMOTE COLOR CHANGE BOX CONFIGURATION The Remote Color Change Box is an optional purchased kit that is compatible with this system and available to select either seven or fourteen colors. The color-change controller is connected through an Intrinsic Barrier (Zener Barrier) located outside the hazardous area to the RF2 device.
  • Page 49 05. CONFIGURATION 2. The Remote Color Change Box configuration screen will open with fourteen (14) selections (b) shown in the left column. For users with a 7-color change box, selection 8-14 will not be used. NOTICE Selection 0 is for solvent to flush the system between colors and after use.
  • Page 50 05. CONFIGURATION 6. When an alarm is present, the alarm indicator light (h) will illuminate. Press and hold the button (g) to 7-Color Change Box clear and restart the station. When no alarm is present, press the button (g) to initiate a color change to the selected color.

  • Page 51: Recipes

    05. CONFIGURATION 05.5 RECIPES The RF2 software is configured through "recipe" parameters, which can be modified per the material in use. A recipe is a set of material-specific parameters used to govern station operations. Each Station has its own set of recipes and can store up to 250 of them.

  • Page 52: Materials-System As A Whole

    05. CONFIGURATION 05.5.1 MATERIALS–SYSTEM AS A WHOLE: There are 250 recipes available per station. Each Recipe in a station has its own set of parameters with adjustable settings. To access and change these settings: Edit Recipe: Press the field that shows the "Recipe to Edit"...
  • Page 53 05. CONFIGURATION 8. Edit Recipe: To change the description of the selected recipe, press the "Edit" (h) icon next to the current recipe description. A screen will open. Screens will show differently when the materials, mixers, or channels within a recipe are changed. 9.

  • Page 54: Mixers Used By The Selected Stations

    05. CONFIGURATION 05.5.2 MIXERS USED BY THE SELECTED STATION: Each Mixer in a station has its own set of recipe parameters with adjustable mix settings. To access and change these settings: 1. Edit Recipe: Select the Recipe To Edit (a). 2.
  • Page 55 05. CONFIGURATION 9. Disable Ratio Tracking: When the material ratio is out of specification, ratio tracking tries to correct ratio errors in automatic mixers by the increase or decrease of component B and C material flow. In manual mixers, this behavior cannot be disabled. When the "Disable Ratio Tracking"...

  • Page 56: Channel-Individual Fluid Channels Used By The Selected Mixer

    05. CONFIGURATION 05.5.3 CHANNEL–INDIVIDUAL FLUID CHANNELS USED BY THE SELECTED MIXER The Channel Edit (Channel A shown) screen is used to make changes to recipes and their related stations, channels, and flow controls. 1. Recipe To Edit: To select a recipe to change, press inside the field that shows the "Recipe To Edit"...
  • Page 57 05. CONFIGURATION Maximum Control Pressure: This is the highest • pressure at which an MVR pilot valve will operate. This can be used to limit material flow when triggering on. 5. Disable CCV When Trigger Off (e): When this box is checked, the CCV for this channel opens and closes with the trigger input.

  • Page 58: System Configuration

    05. CONFIGURATION 05.5.4 COPY RECIPES 1. Press the "Copy" icon (a) to open the "Recipe Copy" screen. 2. From this screen, choose the "Source" recipe (b) and the destination (c) locations (1-250) that represent the available 250 recipes. Multiple destinations can be chosen at the same time.

  • Page 59: User Management

    05. CONFIGURATION 05.6 USER MANAGEMENT Users who are members of the "admin" group can access functions not available to other users and modify access for other users. User options that the administrator can change are: Edit Users • Add User •...

  • Page 60: Add User

    05. CONFIGURATION 05.6.3 ADD USER The operator interface supports up to fifty individual users. To add a user: 1. Press the "Add User" (d) button as shown on the previous page. 2. Fill in the parameters (i) including user name, group assignment and initial password.

  • Page 61: User Permissions

    05. CONFIGURATION 05.6.5 USER PERMISSIONS Various functions within the operator interface can have their access controlled depending on their group assignment. To assign rights to different user groups, enter the "User Permissions" screen from the User Options screen, and select or deselect access for each function (l) by user level (m).
  • Page 62 05. CONFIGURATION This page intentionally left blank. 77-3152-2 R1.0 (07/2024) 56 / 106 www.carlisleft.com...

  • Page 63: Operation

    06. OPERATION 06.1 STARTUP GUIDE 7. "Air Cutoff" signals from the Gun flush box to the Atomizing Air Cutoff pilot signals. Use the pages that follow as a quick reference to make sure that all electrical, air, and fluid connections to the RF2 are 06.1.1.2 Fluid Connections complete and that the machine is ready to begin operation.

  • Page 64: Operation

    06. OPERATION 06.2 OPERATION To start up: On the right-hand side of the control enclosure, turn the main disconnect switch clockwise. The system will go through a boot-up sequence. When ready, the "Main Menu" button (a) will appear. 2. On the bottom of the startup screen, press the desired "flag"...
  • Page 65 06. OPERATION 4. When the "Main Menu" button is pressed, it will: a. Open the main "RUN" screen if the system has been configured and the user preference to "Show configuration summary on startup" is not set. b. Open the "System Configuration Summary" screen as shown in the image to the right if the system has been configured and the user preference is set to "Show configuration...
  • Page 66 06. OPERATION Though the RF2 will most commonly be put into a process that receives automatic commands, such as trigger, flow rates, and load recipes/materials, it can also be operated from the operator interface. To operate the RF2 from the main panel after the material has been loaded: 5.

  • Page 67: Station Selection

    06. OPERATION 06.2.1 STATION SELECTION If the RF2 is configured as a multi-station controller, the station summary screen will show the available selectable stations whenever the run screen is first opened. To open the station summary screen, navigate back to the run screen as described in the previous page.

  • Page 68: Main Run Tray

    06. OPERATION 06.2.2 MAIN RUN TRAY The operation tray controls the machine's basic functions. They are as follows: 1. Stop Button (a): Stops the machine operation of the current station. 2. Start Button (b): Starts the machine operation of the current station. The word "START"...

  • Page 69: Mixer Indicators

    06. OPERATION 06.2.3 MIXER INDICATORS 1. The mixer indicator (a) gives an overview of the run state of each mixer. When more than one mixer is configured to a station, an indicator will appear for each configured mixer. The indicator components are as follows: Mixer Actual Flow (b): Displays the numerical •...
  • Page 70 06. OPERATION 2. Press the mixer indicator (i) to open the mixer details screen. A pop-up screen will show the details of the selected gun or mixer. 3. The trend of flow rate and setpoint (j) is shown in this area. 4.

  • Page 71: Channel Indictators

    06. OPERATION 06.2.4 CHANNEL INDICATORS 1. The channel indicator (a) gives the run state of each channel. The features of the indicators are as follows: Channel Actual Flow (b): Numerically displays • the material flow rate for the channel in real-time during operation.
  • Page 72 06. OPERATION 2. Press the channel indicator (i) to open the channel details screen. A pop-up screen will show the details of the selected channel. Status information is shown throughout the display. The trend of flow rate, pilot psi, and inlet pressure (j) •...

  • Page 73: Load Materials

    06. OPERATION 06.3 LOAD MATERIALS 06.3.1 LOAD RECIPES Recipes can be loaded from the operator interface of the RF2. To load a recipe from the operator interface, follow the steps below in this order: 1. Navigate to the "RUN" screen through the drop-down menu.
  • Page 74 06. OPERATION 7. Select the appropriate recipe from the recipe screen. Once selected, the recipe screen will automatically close. 8. Press the "Download" button (d) to start the load sequence. When the load sequence starts, the station will determine if a flush is needed before it runs the load sequence. Once a flush has completed, then the system runs the appropriate sequences to load material.
  • Page 75 06. OPERATION To change colors, follow the same steps as loading a recipe from a flushed state. If the new recipe requires the same color numbers, no flush will be performed, and the system will go directly to the new recipe load sequence. If component A is different, the system will call the flush A only sequence from the last recipe.

  • Page 76: Sequence Select

    06. OPERATION 06.3.2 SEQUENCE SELECT The sequence select screen lets the user choose up to sixteen relevant sequences for machine operation. NOTICE The sequences shown in the image are examples only. Actual sequence selections are dependent on the user's configuration. If a sequence is initiated and the specified load sequence for the selected recipe is in the next recipe field, that recipe will be loaded.

  • Page 77: Shut Down System

    06. OPERATION 06.4 SHUT DOWN SYSTEM Before the system is shut down, purge any material that is in the tubing to prevent clogs in the fluid tubing and other fluid components. All recipes have a "Purge All" sequence designated, and when the supervisory controller calls a purge command, the system will run that sequence.
  • Page 78 06. OPERATION 3. The front panel E-Stop button does not remove AC power from the system. Only the red main disconnect switch on the right side of the controller shuts off power. After the purge sequence has been completed, you can proceed to shut down the system with the main disconnect switch (b) on the right of the system's enclosure.

  • Page 79: Flow Meter Calibration

    06. OPERATION 06.5 FLOW METER CALIBRATION Calibration of the flow meter is necessary for the best ratio performance of the RF2. Calibration is recommended for each material used because materials of different viscosities may cause the gears within a flow meter to turn more or less than others.

  • Page 80: Pulse Valve Adjustment

    06. OPERATION 06.6 PULSE VALVE ADJUSTMENT A pulse valve is a specially designed solenoid valve used to deliver extremely fast pulses. These valves operate using air pressure to open or close and utilize the same air supply that controls the system. The duration that the valve remains open determines the amount of material that will flow through it.
  • Page 81 06. OPERATION The correct pulse flow range is in the green zone indicated between the green arrows in the example shown to the right. The blue diamond (b) is to the left of the green zone and is considered below range. In this example, the flow must be decreased until the blue diamond is in the green zone.
  • Page 82 06. OPERATION In the example shown to the right, the blue diamond (c) is to the right of the green zone and is considered above range. In this example, the flow must be increased until the blue diamond is in the green zone. 1.

  • Page 83: Alarms

    06. OPERATION 06.7 ALARMS 06.7.1 ALARMS SCREEN On the main navigation bar, the "ALARM" icon (a) changes color and shows an alarm count if an alarm is present. Press the "ALARM" icon to open the main alarm screen. On the "Alarms" screen, the top list shows active alarms, and the bottom list shows historical alarms.

  • Page 84: Alarm Masking

    06. OPERATION 06.7.2 ALARM MASKING Alarm masking allows various alarms to be used as a "spray-shutdown" that halts the system or warnings only. Additionally, the system alarms can trigger the system to shut down the spray operation. If deselected, they will provide a warning while the system continues to run.

  • Page 85: Pot Life Alarms

    06. OPERATION 06.7.3 POT LIFE ALARMS The majority of alarms will shut down the system and can be cleared when the "RESET" button is pressed, but an expired pot life serves as a warning rather than an alarm and requires a system flush to reset system operation. When a pot life warning occurs, the system will remain in run mode, but the CCV valves will close and cause the material flow to stop.

  • Page 86: Manual Override/Local Fluid Control

    06. OPERATION 06.7.4 MANUAL OVERRIDE/LOCAL FLUID CONTROL-ACTIVE The manual override screen can be accessed from the main drop-down "MENU" (a). The Local Fluid Control screen lets individual functions and outputs operate for maintenance and troubleshooting purposes. 1. To operate functions manually, press the "Manual Override"...
  • Page 87 06. OPERATION 5. Press the "Pressure Regulators" button (f) on the Local Fluid Control screen to open the screen shown below. From this screen, manual override mode can be activated and deactivated, and all configured pressure regulators can be operated manually. The actual pressure output value for each regulator is shown at the bottom of the screen.
  • Page 88 06. OPERATION 6. Press the "Solenoid Forcing" button (h) from the Local Fluid Control screen to open the screen shown on the right. This screen is only available if a manual override is selected. 7. From this screen, each installed solenoid is forced on or off when the button (i) to the right of the output descriptions is pressed.
  • Page 89 06. OPERATION 8. From this screen, when the manual override is inactive, it is possible to run fluid sequences directly when their associated buttons (j) near the bottom of the screen are pressed. When active, functions and outputs will indicate their status and let a sequence be viewed in operation from this screen.
  • Page 90 06. OPERATION This page intentionally left blank. 77-3152-2 R1.0 (07/2024) 84 / 106 www.carlisleft.com...

  • Page 91: Additional Operations

    07. ADDITIONAL OPERATIONS 07.1 DATA LOG/REPORTING The RF2 stores flow total data. 1. Press the "REPORTS" button (a) on the lower left of the drop-down menu to access the main screen for data logging. After the button is pressed, the system will display the following screen.

  • Page 92: Flow Totals

    07. ADDITIONAL OPERATIONS 07.1.1 FLOW TOTALS The RF2 stores the basic material flow data for the users to view. Data is organized by Gun/Mix (a), Time Range (Yearly, Monthly, Weekly, Daily, Hourly, Grand) (b), Recipe (c), or by All Recipes. Data can be shown in Liters or Gallons (d).

  • Page 93: Diagnostics

    07. ADDITIONAL OPERATIONS 07.2 DIAGNOSTICS The diagnostics screen contains miscellaneous functions for more diagnostics of the RF2. Press the "DIAGNOSTICS" button on the main drop-down menu to navigate the diagnostics screen. 07.2.1 AUDIT LOG ACTIONS The operator interface audits specific events such as user logged in, etc.

  • Page 94: Hardware Browser

    07. ADDITIONAL OPERATIONS 07.2.2 HARDWARE BROWSER Some of the ethernet-enabled devices that the RF2 uses have built-in web pages that allow for further diagnosis. The Exor operator interface that the RF2 uses has a browser that lets the user view those pages. The home screen of the device browser shows the RF2s PLC web page.

  • Page 95: Auxiliary Input Status

    07. ADDITIONAL OPERATIONS 07.2.3 AUXILIARY INPUT STATUS To check the functionality of inputs from auxiliary devices or some of the sensors that are connected to the RF2, use the "Auxiliary Input Status" screen to view the input states. 07.2.4 RESTART HMI Press the "Restart HMI"...

  • Page 96: Audit Log

    07. ADDITIONAL OPERATIONS 07.2.5 AUDIT LOG On the top-right of the Alarms screen, the "LOG" button (k) will open a screen and show the events that the system has captured. Examples of events found in the audit log are: User Login/Out •...

  • Page 97: Corvina

    07. ADDITIONAL OPERATIONS 07.3 CORVINA 07.3.1 CONFIGURE A WI-FI CONNECTION Login to "admin" user. Select "Menu" > "Setup" > "Exor Internal Menu" (a). Select > Show system settings (b) from pop-up menu. www.carlisleft.com 91 / 106 77-3152-2 R1.0 (07/2024)
  • Page 98 07. ADDITIONAL OPERATIONS Select "Network" (c). Then select "Wireless Networking" (d). Select "Edit" button (e). 77-3152-2 R1.0 (07/2024) 92 / 106 www.carlisleft.com...
  • Page 99 07. ADDITIONAL OPERATIONS Enter Network Name (f) or click on browse (g) to access a network browser. Enter the wifi password (h). Click "SAVE" button (i). 10. Press the "OK" button (j) when a message pop-up window appears with "Operation Successful." 11.

  • Page 100: Configure An Ethernet Connection

    07. ADDITIONAL OPERATIONS 07.3.2 CONFIGURE AN ETHERNET CONNECTION Login to "admin" user. Select "Menu" > "Setup" > "Exor Internal Menu" (a). Select > Show system settings (b) from pop-up menu. 77-3152-2 R1.0 (07/2024) 94 / 106 www.carlisleft.com...
  • Page 101 07. ADDITIONAL OPERATIONS Select "Network" (c). Then select "Network Interfaces" (d). Select "Edit" button (e). www.carlisleft.com 95 / 106 77-3152-2 R1.0 (07/2024)

  • Page 102: Configure Corvina

    07. ADDITIONAL OPERATIONS Find the ethernet adapter which is connected to your ethernet network. DHCP (f) is used by default. If an appropriate DHCP address has been assigned, no further changes are necessary. Otherwise, turn off DHCP and manually enter the network address information in the appropriate fields.
  • Page 103 07. ADDITIONAL OPERATIONS Enable these three (3) services: Cloud/VPN Service (b) • Router/NAT/Port Forwarding (c) • • VNC Service (d) Select "Edit" button (e). In "Cloud/VPN," verify the following settings: Server (f): us.corvinacloud.com Username (g): RF2-machineserialnumber/organization Example shown: RF2-1234/CFTLiquid Password (h): paint123$ The State will update to show "Connected to Cloud with IP"...

  • Page 104: Ntp Setup

    07. ADDITIONAL OPERATIONS 07.3.4 NTP SETUP The Network Time Protocol (NTP) is used to synchronize computer clocks over data networks with variable latency. When Corvina is used, it is recommended to use NTP to make sure the system time is always up-to-date as incorrect system time can lead to authentication issues.

  • Page 105: Disable Cloud Access

    07. ADDITIONAL OPERATIONS 07.3.5 DISABLE CLOUD ACCESS Although the cloud access feature of the RF2 is the best procedure that lets the equipment be diagnosed, troubleshot, and updated, some users may not want to use this type of service. Access to the RF2 via Exor's Corvina Cloud service can be disabled in two ways: 1.

  • Page 106: Backup/Restore

    07. ADDITIONAL OPERATIONS 07.4 BACKUP/RESTORE All stored settings, to include recipe data, global setup data, fluid system configuration, sequences, etc., can be backed up to a USB stick or restored from USB or other media. Additionally, this data is automatically backed up to an SD card daily, with each daily archive being stored for one year before being deleted.

  • Page 107: Backup Data

    07. ADDITIONAL OPERATIONS 07.4.1 BACKUP DATA 1. To backup to USB, first connect a USB flash drive to the USB port (a) provided on the left side of the control enclosure. The system will indicate that a device is found (b). 2.

  • Page 108: Restore Data

    07. ADDITIONAL OPERATIONS 07.4.2 RESTORE DATA 1. To restore from USB, first connect a USB flash drive to the USB port provided on the left side of the control enclosure. The system will indicate that a device is found (a). 2.

  • Page 109: Manual Revisions

    08. MANUAL REVISIONS MANUAL CHANGE SUMMARY Date Description Version 06/28/2024 1st Draft. Split manual into five, put into new format, and restarted at Rev 1.0 R1.0 www.carlisleft.com 103 / 106 77-3152-2 R1.0 (07/2024)
  • Page 110 08. MANUAL REVISIONS This page intentionally left blank. 77-3152-2 R1.0 (07/2024) 104 / 106 www.carlisleft.com...

  • Page 111: Warranty

    This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of parts or accessories from sources other than Carlisle Fluid Technologies will void all warranties. Failure to follow reasonable maintenance guidance provided can invalidate the warranty.
  • Page 112 Carlisle Fluid Technologies is a global leader in innovative finishing technologies. Carlisle Fluid Technologies reserves the right to modify equipment specifications without prior notice. BGK™, Binks®, DeVilbiss®, Hosco®, MS®, and Ransburg® are registered trademarks of Carlisle Fluid Technologies, LLC. ©2024 Carlisle Fluid Technologies, LLC. All rights reserved.
