SERVICE MANUAL
EN
Binks Trophy Series Touch-up Spray Gun is the
premier spray gun for use in pressure feed touch-up
and light production spray applications and sets a
new standard in durability, ergonomics, and
atomization. The lightweight ergonomic design offers
unsurpassed comfort and control. The latest advanced
atomization technology has been incorporated for
achieving consistent, fine finishes when spraying a
wide range of industrial coating applications.
Binks Trophy Series Touch-up Spray Guns can be
used with pumps, pressure pots, pressure cups, or
siphon cups.
Binks Trophy Series Touch-up Spray Guns are
offered in two different atomization technologies:
HVLP and LVMP.
The Trophy HVLP Series of Spray
Guns can be used to operate
at high transfer efficiencies in
compliance with "California South
Coast Air Quality Management
District" regulations as a High
Volume, Low Pressure spray gun.
It is the customer's responsibility to have all operators and service personnel read and understand this manual.
READ ALL INSTRUCTIONS BEFORE OPERATING THIS PRODUCT.
77-3042-R6 (3/2022)
"TROPHY" SERIES TOUCH-UP SPRAY GUNS
PRESSURE AND SIPHON FEED HVLP & LVMP
(1465-XXXX-XXXX)
IMPORTANT! DO NOT DESTROY
SPECIFICATIONS
Maximum Air Pressure
Maximum Fluid Pressure
Gun Body
Fluid Path
Fluid Inlet Size
Air Inlet Size
Gun Weight
Wetted Parts
1 / 16
100 psi / 6.9 bar (P-1)
100 psi / 6.9 bar (P-2)
Anodized Aluminum
Stainless Steel
3/8" NPS / BSP(m)
1/4" NPS / BSP(m)
13 oz. / 374 grams
Stainless Steel & PTFE
www.carlisleft.com
Advertisement
Table of Contents
Related Manuals for Carlisle Fluid Technologies Binks Trophy 1465 Series
Summary of Contents for Carlisle Fluid Technologies Binks Trophy 1465 Series
- Page 1 SERVICE MANUAL “TROPHY” SERIES TOUCH-UP SPRAY GUNS PRESSURE AND SIPHON FEED HVLP & LVMP (1465-XXXX-XXXX) Binks Trophy Series Touch-up Spray Gun is the premier spray gun for use in pressure feed touch-up and light production spray applications and sets a new standard in durability, ergonomics, and atomization.
- Page 2 In this part sheet, the words WARNING, CAUTION and NOTE are used to emphasize important safety information as follows: WARNING CAUTION NOTE Hazards or unsafe practices which could Hazards or unsafe practices which could Important installation, operation or result in severe personal injury, death or result in minor personal injury, product maintenance information.
- Page 3 BINKS “TROPHY” SERIES TOUCH-UP SPRAY GUN CAUTION The fluid inlet is not meant to be removed or replaced. SELECTION GUIDE FOR BINKS “TROPHY” SERIES TOUCH-UP SPRAY GUNS COMPLETE GUN COMPLETE GUN FLUID NOZZLE SPRAY FLUID NOZZLE SPRAY TYPE OF FLUID TO BE SPRAYED ASSEMBLY PART TYPE OF FLUID TO BE SPRAYED ASSEMBLY PART...
- Page 4 CHART 1: BINKS “TROPHY” SERIES TOUCH-UP SPRAY GUN PARTS LIST PART PART ITEM ITEM DESCRIPTION DESCRIPTION QTY. QTY. NUMBER NUMBER AIR CAP RETAINING RING 54-6223-K ❏ SPRING/PAD ASSEMBLY 54-6211 ASSEMBLY 54-6111 KNOB – NEEDLE ADJUSTING SEE CHARTS AIR CAP BELOW 54-6130-K ❏...
- Page 5 TYPES OF INSTALLATION Air pressure for atomization is regulated at the extractor. The flow Oil & Water Extractor of the fluid is adjusted by the fluid valve control knob on gun, viscosity of paint and air pressure. Cup Regulator PRESSURE CUP HOOKUP (Figure 1) FIG 1 Fluid Pressure Cup...
-
Page 6: Installation Instructions
INSTALLATION INSTRUCTIONS 6. Adjust inlet air pressure if required. 7. Turn fluid adjusting knob counter clockwise until first For maximum transfer efficiency, do not use more pressure thread shows. than is necessary to atomize the material being applied. 8. Test spray. If the finish is too dry, reduce airflow by reducing air inlet pressure. -
Page 7: Removal And Installation Procedures
REMOVAL AND INSTALLATION PROCEDURES NEEDLE AND VALVE DISASSEMBLY AND ASSEMBLY FIG.1 DISASSEMBLY ASSEMBLY FIG.2 FIG.10 FIG.3 FIG.11 FIG.4 FIG.12 FIG.13 FIG.5 FIG.14 150 – 170 in-lbs FIG.6 FIG.15 (16.9 – 19.2 Nm) FIG.16 FIG.7 FIG.17 FIG.8 FIG.9 77-3042-R6 (3/2022) 7 / 16 www.carlisleft.com... - Page 8 MAINTENANCE – FLUID NOZZLE AND BAFFLE REMOVAL AND INSTALLATION FIG.1 FIG.2 FIG.3 1/4" FIG.4 FIG.5 FIG.6 170–180 in-lbs. (19 – 20 Nm) 1/4" FIG.7 FIG.8 www.carlisleft.com 8 / 16 77-3042-R6 (3/2022)
- Page 9 MAINTENANCE – NEEDLE PACKING REMOVAL AND INSTALLATION FIG.1 3/8" FIG.2 FIG.3 3/8" FIG.4 FIG.5 FIG.6 MAINTENANCE – SIDEPORT REMOVAL AND INSTALLATION FIG.1 FIG.2 FIG.3 14 mm FIG.4 FIG.6 14 mm FIG.5 77-3042-R6 (3/2022) 9 / 16 www.carlisleft.com...
-
Page 10: Troubleshooting
TROUBLESHOOTING CONDITION CAUSE CORRECTION Heavy top or Horn holes plugged. Clean. Ream with non-metallic point. bottom pattern Obstruction on top or bottom of fluid tip. Clean. Cap and/or tip seat dirty. Clean. Heavy right or left Left or right side horn holes plugged. Clean. - Page 11 TROUBLESHOOTING CONDITION CAUSE CORRECTION Starved spray pattern Inadequate material flow. Back fluid adjusting screw out to first thread, or change to larger tip size. Low atomization air pressure. Increase air pressure and rebalance gun. Excessive overspray Too much atomization air pressure. Reduce pressure.
- Page 12 ACCESSORIES HAF-507 192212 Professional Spray Gun HAV-500 OR HAV-501 6-429 Binks Whirlwind™ Cleaning Kit Adjusting Valve Gunners In-Line Air Filter (HAV-501 SHOWN) Mate Lube (sold in multiples of 12) (Twenty 2 oz. bottles) Compatible with all paint materials; con- tains no silicone or petroleum distillates to contaminate paint.
- Page 13 77-3042-R6 (3/2022) 13 / 16 www.carlisleft.com...
- Page 14 www.carlisleft.com 14 / 16 77-3042-R6 (3/2022)
- Page 15 77-3042-R6 (3/2022) 15 / 16 www.carlisleft.com...
-
Page 16: Warranty Policy
This product is covered by Carlisle Fluid Technologies’ materials and workmanship limited warranty. The use of any parts or accessories, from a source other than Carlisle Fluid Technologies, will void all warranties. Failure to reasonably follow any maintenance guidance provided may invalidate any warranty.
