Summary of Contents for AGA Falcon 900 Deluxe Dual Fuel
- Page 1 USER GUIDE & INSTALLATION INSTRUCTIONS 900 Deluxe Dual Fuel...
- Page 2 SLOW BAKED LEG OF LAMB METHOD 1. Preheat the oven to 220 ¡C (for a conventional oven), 200 ¡C (for a fan oven) or gas mark 7. 2. Pull the small sprigs off the rosemary branches and set aside with the garlic. 2.
- Page 3 900 Dual Fuel Deluxe 210 GEO T DL User’s Manual & Installation and Servicing Instructions U104551-02B...
-
Page 4: Be Safe
Be safe Warning Accessible parts will become hot in use. To avoid burns and scalds children should be kept away. You need clean fresh air – so does your cooker. Burner flames produce exhaust gases, heat and moisture. Make sure that the kitchen is well ventilated: keep natural ventilation holes open or install a powered cooker hood that vents outside. -
Page 5: Table Of Contents
Contents Be safe Hotplate Burners Wok Centre Ring The Glide Out ™ Grill The Ovens Multi-function oven functions Falcon Multi-function Oven cooking guide Oven Cooking chart - Conventional and full Fan oven functions Cleaning your cooker Moving your cooker Troubleshooting General Safety Instructions Installation Conversion to LP Gas... -
Page 6: Hotplate Burners
Hotplate Burners The drawing below each knob indicates which burner that knob controls. There is a spark ignition system that works when the knob is pressed in. Each burner also has a special safety device that stops the flow of gas if the flame Pans and kettles with concave bases or down goes out. -
Page 7: Wok Centre Ring
Wok Centre Ring Wok Cooking A Wok may be used for 5 traditional methods of oriental cooking: Stir Frying Shallow Frying Deep Frying The wok ring is designed fit the centre burner. It Steaming will not fit any of the other burner pan supports Braising Stir frying has become the most familiar and popular method of oriental cooking. -
Page 8: The Glide Out™ Grill
The Glide Out™ Grill : Accessible parts may be hot when the To heat the right aution grill is in use. Young children should be kept hand half turn it anti away. clockwise. Before using the grill for the first time turn make sure that all packing materials have been removed and then to dispel manufacturing odours, turn on the grill... - Page 9 Grill Cooking Chart MEAT Time (minutes) Back Bacon Rashers Chicken Satay Fillet Steak (170g) Sirloin Steak (170g) Hamburger (113g) Lamb Chop Lamb Kidneys Lamb’s Liver Pork Chops Pork Sausage (57g) Pork Kebabs FISH Time (minutes) Cod Fillet Halibut Steaks 10-11 Herring Fillets in Oatmeal Lemon Sole Fillets Salmon Steaks...
-
Page 10: The Ovens
The Ovens During use the appliance becomes hot. Care should be taken to avoid touching the heating elements inside the oven. Before using for the first time, to dispel manufacturing odours turn the ovens to 200°C and run for an hour. To clear the smell make sure the room is well ventilated to the outside air, by opening windows or turning on a cooker hood for example. -
Page 11: Multi-Function Oven Functions
Multi-function oven functions Fanned grilling in the oven The Multi-function oven has many varied This function operates the fan whilst the uses. We suggest you keep a careful eye on top element is on. It produces a more even, less your cooking until you are familiar with each fierce heat than a conventional grill. - Page 12 Browning element Cooking high moisture content foods can create This function uses the element in the a ‘steam burst’ , when the top of the oven only. It is a useful function oven door is opened. When for the browning or finishing of pasta dishes, opening the oven stand vegetables in sauce and lasagne, the item to be well back and allow any...
- Page 13 The Main Oven shelves To refit the shelf, hold it so it is slightly up at the front and rest the back of the shelf on the side There are 2 standard oven selves and 1 drop wires. Push the shelf to the back of the oven shelf.
-
Page 14: Falcon Multi-Function Oven Cooking Guide
Falcon Multi-function Oven cooking guide Remember - not all functions will be suitable for all food types. The oven control settings and cooking times given are intended to be used only as a guide. Individual tastes may require the temperature to be altered to provide a preferred result. Food is cooked at lower temperature in a fan oven than in a conventional oven. -
Page 15: Oven Cooking Chart - Conventional And Full Fan Oven Functions
Oven Cooking chart - Conventional and full Fan oven functions Convection Oven Fan Oven Shelf Food Temperature Temperature Approximate Cooking Time Position FISH 190°C 180°C Fillets 15-20mins. 190°C 180°C Whole 10mins.per 500g + 10mins. 190°C 180°C Steaks according to thickness. ROAST MEATS Beef with bone 160°C... -
Page 16: Cleaning Your Cooker
Cleaning your cooker Check burner ports are not blocked. If blockage occurs, remove stubborn particles using a Before thorough cleaning, isolate from the piece of fuse wire. electricity supply. Remember to switch on the Glide-Out™Grill electricity supply before use. Before you remove any of the grill parts for Never use paint solvents, washing soda, cleaning make sure that they are cool. - Page 17 For safety, push the side rails into the grill cleaning material. This will also restore the chamber. polished finish. The side rails can be removed to make cleaning Main Oven the grill chamber easier by unhooking them The shelf supports on the oven sides can be from the grill chamber sides.
-
Page 18: Moving Your Cooker
Moving your cooker Don’t use steel wool (or any other materials that will scratch the surface). Don’t use oven Switch off the electricity supply. cleaning pads. The cooker is heavy, two people may be The Tall Oven required to move it. To clean the oven sides slide out the shelves, There are two levelling rollers at the back and unhook the supports from the oven sides and... -
Page 19: Troubleshooting
Troubleshooting Steam is coming from the oven example, if it is deeper at the back, then the When cooking foods with a high water back of the cooker should be raised up or the content (e.g. oven chips) there may be some front lowered). -
Page 20: General Safety Instructions
General Safety Instructions All parts of the cooker become hot with In the UK: use and will retain heat even after you have The hotplate must be installed by a Gas Safe stopped cooking. registered engineer. Take care when touching cooker, to minimize In the Republic of Ireland: the possibility of burns, always be certain that The installation must be carried out by a... - Page 21 Do not use water on grease fires. Never pick up Only certain types of glass, glass-ceramic, a flaming pan. Turn the controls off. Smother earthenware or other glazed containers are a flaming pan on a surface unit by covering suitable for hotplate cooking; others may break the pan completely with a well fitting lid or because of the sudden change in temperature.
-
Page 22: Installation
Installation The relevant Building / IEE regulations. In the Republic of Ireland: The installation must be carried out by a Competent Dear Installer Person and installed in accordance with the current Before you start your installation, please edition of IS 813 “Domestic Gas Installations”, the complete the details BELOW. - Page 23 Positioning the Cooker You will need the following equipment to complete the cooker installation satisfactorily The diagrams show the minimum recommended distance from the cooker to nearby surfaces. The cooker should not be placed on a base. STABILITY BRACKET If the cooker is to be supplied with gas through a flexible hose, a stability bracket or chain must be fitted.
- Page 24 Unpacking the Cooker Do not take any packaging off the cooker until it is directly in front of the place it is to be installed (unless it Make sure you lower BOTH REAR ROLLERS. There are will not fit through a door in its outer packaging). two adjusting nuts, one for each roller, at both the front bottom corners of the cooker.
- Page 25 at the front bottom corners of the cooker. To set the front feet turn the bases to raise or lower. Gas Connection Fitting a stability bracket A stability bracket or chain (not supplied by with the cooker) should be fitted when the cooker is connected to a flexible gas supply.
- Page 26 Electrical Connection Grill This appliance must be installed by a qualified Open the grill compartment door. Turn on the grill electrician to comply with the relevant regulations and control and check that the grill heats up. also the local electricity supply company requirements. Oven check WARNING: THIS APPLIANCE MUST BE EARTHED Turn on the ovens and check that they start to heat up.
-
Page 27: Conversion To Lp Gas
Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. Conversion to LP Gas Lift up the front of the hotplate top and prop Warning! it up. The burner bases are now accessible – remove the old injectors. - Page 28 Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. Refit the control panel. Reassembly LP Gas Centre Burner If you are converting to LP Gas the large ring in the conversion kit MUST be fitted as shown below.
- Page 29 Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. Stick on label Outer Burners Stick the appropriate label on to the data Screw in the hexagon headed venturis but to badge to indicate the type of gas the appliance make fitting the other burners easier do not uses.
-
Page 30: Servicing
Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. Servicing To Remove an Outer Side Panel Disconnect the appliance from the electricity supply. When servicing or replacing gas carrying components Remove the control panel as detailed in Section 2 disconnect from gas before commencing operation Remove the retaining screw on the upper front and check appliance is gas sound after completion. - Page 31 Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. To Replace a Grill Controller Fit the replacement electrode to the burner bezel. Ensure that the spring and clip are properly Disconnect the appliance from the electricity supply. located.
- Page 32 Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. 15. To Remove the Oven Outer Door Panel 18. To Adjust the Oven Door Catch Keeper Open the oven door. Open the oven door and slacken the locknut at the keeper base.
- Page 33 Servicing - warning Disconnect from electricity and gas before servicing. check appliance is safe when you have finished. 25. To Remove a Grill Element Fit the replacement and re-assemble parts in reverse order. Check that the oven operates Disconnect the appliance from the electricity supply. satisfactorily.
- Page 34 Circuit Diagram P095199 P028728 The connections shown in the circuit diagram are for single-phase. The ratings are for 230V 50Hz. Code Description Code Description Colour Code Grill control Right-hand fan oven thermostat Blue Grill element left-hand side Right-hand fan oven control Brown Grill element right-hand side Right-hand fan oven element...
-
Page 35: Technical Data
Technical Data This cooker is category II2H3+ It is supplied set for group H natural gas. A conversion kit from NG to LP gas is included. INSTALLER: Please leave these instructions with the User. DATA BADGE LOCATION: Cooker back, serial number repeater badge below oven door opening. Country of Destination: GB/IE Electric Gas (Rp... - Page 39 ¥ Has not been repaired by persons or organisations other than those authorised to act on behalf of AGA Date of Purchase Rangemaster. Exceptions: Installer's Name & Address ¥...
- Page 40 For over 45 years Divertimenti, Falcon’s sister company, has been the ultimate destination for food lovers and serious chefs alike. With its vast array of cookware, tableware and kitchenware, Divertimenti caters to all your culinary needs. With over 4500 items on the Divertimenti website www.divertimenti.co.uk Falcon Appliances...
