Summary of Contents for ROUSH 422301
- Page 1 2021+ Bronco R Series Ditch Lights Kit Installation Instructions P/N: 422301 ROUSHPERFORMANCE.COM | 800.59.ROUSH...
- Page 2 Before installing your ROUSH Performance Product(s), read through the entire installation procedure and check to make sure all items are present. Contact ROUSH Customer Service at 1-800-59-ROUSH, weekdays from 9:00 AM to 5:00 PM EST, with any questions regarding fit, missing parts or instructions that are unclear to you.
-
Page 3: Table Of Contents
SWITCH INSTALLATION (ONLY FOR VEHICLES WITHOUT UPFITTER AUX SWITCHES)..............9 INSTALLING OF WIRING HARNESS (ONLY FOR VEHICLES WITHOUT UPFITTER AUX SWITCHES) ...........10 INSTALLING OF WIRING HARNESS (ONLY FOR VEHICLES WITH UPFITTER AUX SWITCHES) ..........11 BRONCO DITCH LIGHTS ALIGNMENT ............................15 1521-BRLIM-AA 082823 800.59.ROUSH... -
Page 4: Packing List For 2021+ Bronco Ditch Lights Kit
SS3 Pro SAE/DOT White Driving Light - Pair (Qty. 2) DD6278P Wire Harness w/Switch, relay, fuse and connectors DD4045 ROUSH SPECIFIC HARNESS HARDWARE KIT XP0093 Worklight SS3 Cover Standard Black with ROUSH R Logo XP0092 DD6260P Work Light Mounting Bracket Kit 1521-BRLIM-AA 082823 800.59.ROUSH... -
Page 5: Equipment And Supplies Required
*Note: Check your vehicle’s glove box to see if your Bronco is equipped with tools kit (Pictures shown below), you may find tools needed for this installation. If you are missing any items, please call us toll free at 1-800-59-ROUSH. 1521-BRLIM-AA 082823... -
Page 6: Limit Of Liability Statement
The information contained in this publication was accurate and in effect at the time the publication was approved for printing and is subject to change without notice or liability. ROUSH Performance Products (RPP) reserves the right to revise the information presented herein or to discontinue the production of parts described at any time. -
Page 7: Installation Of Work Light Mounting Bracket
*Note: The bolt *Note: Passenger side should be longer than the above the antenna is size T30, and the bolt closer driver side, please verify the length before the next to the side mirror is size T25. step. 800.59.ROUSH 1521-BRLIM-AA 082823... - Page 8 *Note: For the lamp position, the connecter is on the bottom side of the lamp. The “D” logo should be in the upright 7. Repeat the same process on the driver’s side. Note the position of the wire harness by the windshield 800.59.ROUSH 1521-BRLIM-AA 082823...
- Page 9 CONTINUE TO PAGE 11. 11. Repeat the same process on the other side. 12. Reinstall the radio antenna by twisting it in clockwise direction, and make sure the letter “D” circled shown is upright on Both light pods. 800.59.ROUSH 1521-BRLIM-AA 082823...
-
Page 10: Switch Installation (Only For Vehicles Without Upfitter Aux Switches)
2. Fish wire and switch thru hole and into interior. Be *Note: Zip tie as needed so the wire is not in the way sure to have enough wire going into the interior to of moving parts. reach the desired switch location. 800.59.ROUSH 1521-BRLIM-AA 082823... -
Page 11: Installing Of Wiring Harness (Only For Vehicles Without Upfitter Aux Switches)
800.59.ROUSH 1521-BRLIM-AA 082823... -
Page 12: Installing Of Wiring Harness (Only For Vehicles With Upfitter Aux Switches)
Base and Outer Banks versions, and standard on Black Diamond, Wild Trak, Badlands, and First Edition trims. Check your Bronco to see if you have upfitter switches. *Note: For more information about your Bronco please go to Bronco Owner’s Manual. 800.59.ROUSH 1521-BRLIM-AA 082823... - Page 13 4. Referring to the wiring diagram on the below, locate the yellow wire (1st switch wire). *Note: If the yellow wire is connected to other accessory, please use another switch wire. *Note: You can find aux switches information from your Bronco Owner’s Manual. 800.59.ROUSH 1521-BRLIM-AA 082823...
- Page 14 7. Add zip ties as shown below to make the engine upfitter YELLOW wire. bay organized. 6. Connect the black ground wire and fasten it with 8mm socket to the existing ground on the driver’s side rear cowl area. 800.59.ROUSH 1521-BRLIM-AA 082823...
- Page 15 10. When completed, close red protective cover negative battery terminal. 9. Open red protective cover over battery positive terminal and install red positive wire to bus bar terminal using one of the fasteners on the bus bar. 800.59.ROUSH 1521-BRLIM-AA 082823...
-
Page 16: Bronco Ditch Lights Alignment
*Note: Either position is correct, it will depend on vehicle application such as off-road Passenger Side Driver Side 5. The Bronco Ditch Lights Kit installation is complete. 800.59.ROUSH 1521-BRLIM-AA 082823...
