  • Page 1 Smart-Ex 03 User Manual DZ1/DZ2 Intrinsically Safe 5G Smartphone...

  • Page 4: Table Of Contents

    Content 1. Application ....................................5 1.1 Smart-Ex 03 DZ1 ................................5 1.2 Smart-Ex 03 DZ2 ................................5 2. Safety precautions ................................5 3. Safety Guidelines ................................6 4. Accessories ...................................8 5. Device layout ..................................8 6. Inserting the SIM card and the battery pack ...................8 7. Charging the Smartphone............................10 8.

  • Page 5: Application

    1. Application 1.1 Smart-Ex 03 DZ1 The Smart-Ex 03 DZ1 is an intrinsically safe water-, dust- and impact resistant smartphone for industrial application in areas with an increased risk of explosion in Zone 1, Zone 2, Zone 21 and Zone 22.

  • Page 6: Safety Guidelines

    3. Safety Guidelines Please read and understand the following safety guidelines before you use the phone. Keep them in mind when operating the phone. Also, conform to any legal requirements regarding the use of cellular phones. Icon Description Electrical interference may obstruct the use of your phone. Observe restrictions in hospitals and near medical equipment.
  • Page 7 In accordance with IEC 62368-1:2018 Clause F.5, below logo is placed on the phone where the surface temperature limit for ordinary persons is exceeded (+48°C) and the following explana- tion applies: Hot parts! Temperature >+48°C, but <+58°C, may occur at the location where the logo is placed on the phone in very rare high-power consuming use cases.

  • Page 8: Accessories

    4. Accessories Recognized accessories are listed on the relevant product page at www.pep- perl-fuchs.com. Note: The USB interface and Audio Plug do not have to be closed by the respec- tive dust and dirt cover. 5. Device layout (see illustration on page 2) 1.
  • Page 9 Step 2 Insert the nano-SIM card with the gold-colored contacts facing downwards by pushing it upward in the designated slot. Step 3 Insert the battery into the battery slot in the prescribed order as shown in the illustration below and screw down the two cover screws in a clockwise direction. Please use the screwdriver Torx T8 and ensure not to overtighten the screws.

  • Page 10: Charging The Smartphone

    Step 4 It is recommended to fully charge the battery before using the smartphone for the first time. To charge the smartphone, open the USB-C cover and rotate it 180° to fix it in place. After that the USB-C cable can easier be connected. Ã...

  • Page 11: Safety Precautions For Battery Packs

    8. Safety precautions for battery packs Damaged batteries and chargers should be removed from use and sent to Pepperl+Fuchs for inspection. When sending batteries/battery packs or devices containing batteries/battery packs; the sender must comply with the transport regulations for dangerous goods.

  • Page 12: Repair

    Dispose of the battery pack in accordance with local regulations and not with ■ normal household waste. High-quality lithium-ion batteries are used in your Smart-Ex 03 DZ1, Smart-Ex ■ 03 DZ2. These batteries have numerous advantages in everyday use, such as a low weight and high capacity in a nevertheless compact construction.

  • Page 13: Cleaning, Maintenance And Storage

    Recommended temperature for long-term storage is +20°C ± 3°C. ■ 11. Disposal Old electrical devices by Pepperl+Fuchs will be directed to disposal at our expense and disposed of free of charge in accordance with European Directive 2012/19/EU. Please follow local regulations for the disposal of electronic products.

  • Page 14: Warranty And Liability

    12. Warranty and liability The warranty of this product follows the General Conditions of Delivery and Pay- ment of Pepperl+Fuchs SE, which are available at www.pepperl-fuchs.com, or alternatively they can be requested directly from the manufacturer. This warranty can be extended by the optional Service Level Agreement.
  • Page 16 Pepperl+Fuchs SE prior written consent. The contents of this document are presented as they currently exist. Pepperl+Fuchs SE does not provide any express or tacit guarantee for the correctness or completeness of the contents of this document, including, but not restricted to, the tacit guarantee of market suitability or fitness for a specific purpose unless applicable laws or court decisions make liability mandatory.
