SOFT: Rounded response curve
• Gradual onset of compression (fade-in up to the set ratio)
• Similar to an "over-easy" type knee
• More transparent
• The green LED illuminates when engaged

THRUST

5.1.2 ®
The 2500+ includes API's patented
THRUST
the ® filter before the RMS detector that decreases the compressor's reaction to low frequency
content. The result is a noticeable increase of punch and low frequencies, but a uniformly compressed
signal. It's the "little more punch" switch!
The patented
Compressor, ATI Paragon and Paragon II consoles, as well as the Pro6 Input Strip. This circuit places
a filter in front of the RMS detector with a slope of 10dB per decade (-3dB/8va), which is the inverse
of the pink noise energy curve. In acoustics, the pink noise curve is used to equalize energy vs.
frequency over the audio spectrum, as sound requires more low frequency energy than high frequency
energy to sound correct to your ear. In Hi-fi equipment, a "LOUDNESS" contour is used to equalize
the music at lower levels so it sounds correct. Even with this curve, there is still a substantial amount
of low frequency information compared to high frequency information in the audio signal path. When
that signal is fed into the RMS detector, the detector will process the signal into a DC control voltage
2500+ Bus Compressor
THRUST
THRUST
The ® circuit can be engaged using the
THRUST
® : Cycle to select the
• LOUD: Inserts the LOUD
Red LED
o
• MED (Medium): Inserts the MED
Yellow LED
o
• NORM (Normal): No
Green LED
o
THRUST
® circuit has been used for many years in the famed API 2500+ Stereo
® circuit that can be switched in or out as needed. This places
THRUST
THRUST
® function
THRUST
® filter before the RMS detector
THRUST
THRUST
® filter before the RMS detector (flat)
13
® switch.
® filter before the RMS detector
