Emec LDPHCL Quick Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Download manual
R2
LDPHCL
LDPHCL PLUS
206.1165.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the LDPHCL and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Emec LDPHCL

Summary of Contents for Emec LDPHCL

  • Page 1 Download manual LDPHCL LDPHCL PLUS 206.1165.0...

  • Page 2: Main Board

    MAINBOARD Cl mA C D E *example mainboard A: Fusibile generale (6A T) B: Fusibile strumento (3.15A T) L(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 50/60 Hz 1(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 5A 50/60 Hz Relay 1 Uscita “CH1 PH RELAY”. Per “ON/OFF” o “PWM”. 2(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 5A 50/60 Hz Relay 2 Uscita “CH2 CL2 RELAY”.
  • Page 3 A: General fuse (6A T) B: Instrument fuse (3.15A T) L(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 50/60 Hz 1(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 5A 50/60 Hz Relay 1 Output “CH1 PH RELAY”. For “ON/OFF” or “PWM”. 2(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 5A 50/60 Hz Relay 2 Output “CH2 CL2 RELAY”. For “ON/OFF” or “PWM”. 3(Phase) - E(Earth) - N(Neutral): Output 85÷264VAC alarm 4(Phase) - E(Earth) - N(Neutral) : 85÷264VAC flocculant output (always ”on”...
  • Page 4 A: Fusible general (6 A T) B: Fusible instrumento (3,15 A T) L(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 50/60 Hz 1(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 5 A 50/60 Hz Salida Relé 1 Salida «CH1 PH RELAY». Para «ON/OFF» o «PWM». 2(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 5 A 50/60 Hz Salida Relé 2 Salida «CH2 CL2 RELAY». Para «ON/OFF» o «PWM». 3(Fase) - E(Tierra) - N(Neutro): Salida 85÷264 VCA alarma 4(Fase) - E(Tierra) - N(Neutro): Salida 85÷264 VCA floculante (siempre «on»...
  • Page 5 A: Bezpiecznik główny (6A T) B: Bezpiecznik narzędzia (3.15A T) L(Faza) - E(Ziemia) - N(Neutralny): 85÷264VAC - 50/60 Hz 1(Faza) - E(Ziemia) - N(Neutralny): 85÷264VAC - 5A 50/60 Hz Przekaźnik 1 Wyjście “CH1 PH RELAY”. Dla “ON/OFF” lub “PWM”. 2(Faza) - E(Ziemia) - N(Neutralny): 85÷264VAC - 5A 50/60 Hz Przekaźnik 2 Wyjście “CH2 CL2 RELAY”. Dla “ON/OFF” lub “PWM”. 3(Faza) - E(Ziemia) - N(Neutralny): Wyjście 85÷264VAC alarm 4(Faza) - E(Ziemia) - N(Neutralny) : Wyjście 85÷264VAC flokulant (zawsze “on”...
  • Page 6 DISPLAY Connesso LAN - Connesso ERMES UNIT mg/l Cl Disconnesso Connesso LAN - Non connesso ERMES 7.09 4.16 Pendrive USB connessa VALUES Trasmissione ERMES In corso Modem Connesso OUTPUTS STATUS WIFI Connesso 60.09 øC Sonda non connessa LAN connected - ERMES connected LAN verbunden - ERMES verbunden Conectado LAN - Conectado ERMES Disconnected...
  • Page 7 S VC L EC L 4 m A / WM EC L 5 EC L 6 EC L 7 EC L 1 2 V+ V- IN GND GND IN S C Lx -RS +RS GND +VDC...

  • Page 8: Calibration Parameters

    SET-POINT pH-Cl Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters Set-Point Menu Set-Point Menu Set Ch1 pH pulse 1 Set Ch1 pH relay Set Ch1 pH pulse 1 Set Ch1 Cl2 pulse 2 Set Ch1 Cl2 relay STANDARD VERSION PLUS VERSION Mode: ON/OFF...
  • Page 9 CALIBRATION pH-Cl Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters Output Manager Calibration Menu Calibration Menu Calibration pH Calibration pH Calibration Cl2 Calibration Cl2 Temp probe Temp probe Select probe Calibration Menu Calibration Menu Fast Calibration Fast Calibration Full Calibration Full Calibration Exit...

  • Page 10: Temperature Calibration

    TEMPERATURE CALIBRATION Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters Output Manager Calibration Menu Calibration Cl2 Temp probe Select probe Temperature Calibration +25C Reading Cal. at 00.0 øC 25 øC Calib. Point THERMOMETER REFERENCE...
  • Page 11 Video Tutorial Calibrazione Video Tutorial Setpoint Calibration Tutorial Video Setpoint Tutorial Video Video-Tutorial Kalibrierung Video-Tutorial Sollwert Vídeo Tutorial Calibración Vídeo Tutorial Setpoint Vidéo Tutoriel Calibrage Vidéo Tutoriel Setpoint Wideo Tutorial Kalibracja Wideo Tutorial Nastawa Tutorial em vídeo Calibração Tutorial em vídeo Ponto de ajuste Lo sfondo del display, se RGB, cambia colore in base alla situazione dello strumento: VERDE: funzionamento normale | BIANCO: Standby | ROSSO: Allarme (verificare su status) | GIALLO: Attenzione (es.: funzione ritardo attivazione uscite attiva) Please note about background color display (RGB Version only): GREEN: normal working mode | WHITE : Standby | RED: Alarm (che info...
  • Page 12 206.1165.0 V10923...

This manual is also suitable for:

Ldphcl plus
