- Page 1 Download manual LDSPH LDSPH PLUS 206.1175.0...
-
Page 2: Main Board
MAINBOARD MODULE +5 +5 GND C D E RESERVED A: Fusibile generale (6A T) B: Fusibile strumento (3.15A T) L(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 50/60 Hz 1(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 5A 50/60 Hz Relay 2 Uscita “pH RELAY 2” . Per “ON/OFF” o “PWM” . 2(Fase) - E(Terra) - N(Neutro): 85÷264VAC - 5A 50/60 Hz Relay 1 Uscita “pH RELAY”. - Page 3 A: General fuse (6A T) B: Tool fuse (3.15A T) L(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 50/60 Hz 1(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 5A 50/60 Hz Relay 2 Output “pH RELAY 2” . For “ON/OFF” or “PWM” . 2(Phase) - E(Earth) - N(Neutral): 85÷264VAC - 5A 50/60 Hz Relay 1 Output “pH RELAY”.
- Page 4 A: Fusible general (6 A T) B: Fusible general (3,15 A T) L(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 50/60 Hz 1(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 5 A 50/60 Hz Relé 2 Salida «pH RELAY 2». Para «ON/OFF» o «PWM». 2(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA - 5 A 50/60 Hz Relé 1 Salida «pH RELAY». Para «ON/OFF» o «PWM». 3(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA Salida alarma 4(Fase) - E(Tierra) - N(Neutro): 85÷264 VCA Salida «SELF CLEAN»...
- Page 5 A: Bezpiecznik ogólny (6A T) B: Bezpiecznik przyrządu (3,15A T) L(Faza) - E(Uziemienie) - N(Neutralny): 85÷264VAC - 50/60 Hz 1(Faza) - E(Uziemienie) - N(Neutralny): 85÷264VAC - 5A 50/60 Hz Przekaźnik 2 Wyjście “pH RELAY 2” . Dla “ON/OFF” lub “PWM” . 2(Faza) - E(Ziemia) - N(Neutralny): 85÷264VAC - 5A 50/60 Hz Przekaźnik 1 Wyjście “pH RELAY ”.
- Page 6 DISPLAY Connesso LAN - Connesso ERMES UNIT Disconnesso Connesso LAN - Non connesso ERMES Pendrive USB connessa VALUES Trasmissione ERMES In corso Modem Connesso OUTPUT STATUS WIFI Connesso 26.00 øC LAN connected - ERMES connected LAN verbunden - ERMES verbunden Conectado LAN - Conectado ERMES Disconnected Getrennt...
-
Page 7: Calibration Parameters
pH SETPOINT Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters pH pulse pH relay Mode: ON/OFF Mode: ON/OFF Mode: Mode: Mode: Prop. Mode: Prop. Mode: Fixed PWM Mode: Fixed PWM Mode: Proportional PWM Mode: Proportional PWM Mode: Prop. + WM STANDARD VERSION Mode: LINE... -
Page 8: Calibration Menu
pH CALIBRATION Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters Output Manager Calibration Menu pH probe Temp probe Exit Calibration Menu Fast Calibration Full Calibration Exit Calibration pH Reading Cal. at 5.20 07.00 Exit BUFFER SOLUTION REFERENCE... -
Page 9: Temperature Calibration
TEMPERATURE CALIBRATION Passcode 0 0 0 0 Main Menu Set-Point Calibration Parameters Output Manager Calibration Menu pH probe Temp probe Exit Temperature Calibration Reading Cal. at 23.8 øC 25 øC Calib. Point THERMOMETER REFERENCE... - Page 10 Video Tutorial Calibrazione Video Tutorial Setpoint Calibration Tutorial video Setpoint Tutorial video Video-Tutorial Kalibrierung Video-Tutorial Sollwert Vídeo Tutorial Calibración Vídeo Tutorial Setpoint Vidéo tutoriel calibrage Vidéo tutoriel Setpoint Wideo Tutorial Kalibracja Wideo Tutorial Nastawa Tutorial em vídeo Calibração Tutorial em vídeo Ponto de ajuste Lo sfondo del display, se RGB, cambia colore in base alla situazione dello strumento: VERDE: funzionamento normale | BIANCO: Standby | ROSSO: Allarme (verificare su status) | GIALLO: Attenzione (es.: funzione ritardo attivazione uscite attiva) Please note about background color display (RGB Version only): GREEN: normal working mode | WHITE : Standby | RED: Alarm (che info...
- Page 12 206.1175.0 V10923...
