madbeanpedals Florist24 Manual

Florist24 Florist24
F
MODULATION
X Type:
Build Level: Intermediate
Based On: Little Angel Chorus
The 2024 version of the Florist has no circuit changes and minor layout tweaks.
The Florist is a PT-2399 based chorus capable of a wide range of chorus, vibrato and lots of
modulated weirdness beyond that. It's based around the Little Angel chorus which has been a
DIY staple for many years. My goal was to expand the design with additional features to make it a
"multi-trick" pony.
The added features include width and feedback controls, a different audio-through section and
running the PT2399 at a slightly higher voltage. These additions make for a well-rounded effect but
without the complexity or expense of utilizing a BBD/Clock to create the chorus effect.
Much credit goes to Rick Holt for the original Little Angel design!
• SPD: Chorus/Vibrato rate from slow to fast.
• DEPTH: Chorus/Vibrato depth from min to max.
• WIDTH: Displaces the LFO waveform by making the peaks and valleys uneven (similar to
altering the duty cycle). It also creates a bit of "throb" at the highest setting.
• BLOOM: Acts as feedback for the delayed output signal. It can create some pseudo-flange
sounds in conjunction with the WIDTH and DEPTH control, as well.
• BLEND: CCW - no effect mixing, 1/2 up - chorus, CW - vibrato.
• VOL: Total effect output.
Further Study:
https://www.diystompboxes.com/smfforum/index.php?topic=86297.0
Terms of Use: You are free to use purchased Florist24 circuit boards for both DIY and small commercial operations. You may not offer Florist24 PCBs for
resale or as part of a "kit" in a commercial fashion. Peer to peer re-sale is fine, though.
Technical assistance for is available via the
available to respond via email in a timely and continuous manner, and (2) posting technical problems and solutions in the forum creates a record from which other
members may benefit.
All copyrights and registered trademarks are property of their original owners. Any mention of trademarked or intellectual properties in this documents is purely for
comparative purposes.
Overview
Controls
madbeanpedals forum. Please go there rather than emailing me for personal assistance. This is because (1) I'm not always
Last Updated:
August 17, 2024 11:19 AM
© 2024 madbeanpedals
