SportsPlay Equipment 301-121 CRAWL THRU Perm Quick Start Manual

PLEASE RETAIN THIS INSTRUCTION SHEET IN YOUR FILES.
INFORMATION. ALL EQUIPMENT SHOULD BE INSTALLED IN ACCORDANCE WITH THESE INSTRUCTIONS.
IT IS IMPORTANT TO USE AND MAINTAIN ALL PUBLIC PLAYGROUND EQUIPMENT PROPERLY.
WHICH IS IMPROPERLY MAINTAINED CAN CAUSE SERIOUS INJURY.
REPAIR AND/OR REPLACEMENT OF DAMAGED PARTS IS NECESSARY FOR SAFE OPERATION OF EQUIPMENT AND SAFETY
OF USERS. RESILIENT SURFACING SHOULD BE USED UNDER ALL PLAYGROUND EQUIPMENT.
PUBLICATIONS, AVAILABLE AT NO CHARGE, FROM THE CONSUMER PRODUCT SAFETY COMMISSION, INCLUDE "A
HANDBOOK FOR PUBLIC PLAYGROUND SAFETY."
538-2772
PACKING LIST
1 CTN -1 Hardware
-4 313-501
-4 103-009
1 BDL -2 303-201
1 CTN -1 603-906
1 BDL -2 303-608
2 CTN
Sportsplay Equipment, Inc
301-121 CRAWL THRU (Perm)
* IMPORTANT *
YOU CAN RECEIVE YOUR FREE COPY BY CALLING TOLL FREE 1-800-
Bag
Angle
Ring
Rail
Aluminum Bd
Supports
2 BDL 4 TOTAL PCS
., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
IT CONTAINS IMPORTANT REPLACEMENT PARTS
PERIODICAL INSPECTIONS, MAINTENANCE,
HARDWARE BAG
4 - 116-545 5/16" x 2½" Button Hd Bolt
8 - 116-535 5/16" x 1½" Button Hd Bolt
4 - 116-530 5/16" x 1" Button Hd Bolt
8 - 126-504 5/16" x 1" Carriage Bolt
4 - 355-905 Plastic Plug
4 - 105-015 Alum. Pipe Plug
8 - 605-506 Clip
8 - 316-501 5/16" Flat Washer
16 - 326-501 5/16" Lock Washer
8 - 226-501 5/16" Lock Nut
16 - 216-512 5/16" Button Hd Nut
2 - 416-530 3/16" Socket Key
1 - 805-532 Warning Label
1 - 805-534
SportsPlay
1 - Maintenance Checklist
WT 64# CLASS 70
1
Page
Rev 04/06/04
PLAYGROUND EQUIPMENT
APPROPRIATE
Label
