SportsPlay Equipment 301-134 JR. DOME (Perm.) Manual

PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY.
instruction sheet in your files.
information.
instructions.
properly. Playground equipment, which is improperly maintained, can cause serious
injury. Periodical inspections, maintenance, repair and/or replacement of damaged
parts is necessary for safe operation of equipment.
available at no charge, from the Consumer Product Safety Commission, include "A
Handbook for Public Playground Safety".
1-301-504-7908.
Dome footprint is
6'6" wide
See page 4 for installation key
1 CTN 1 Hardware
1 5 503-647
1 CTN 20 303-226
1 CTN 15 303-227
2 CTN 15 303-228
5 CTN
SportsPlay Equipment, Inc., 5642 Natural Bridge, St. Louis, MO 63120 (314) 389-4140
301-134 JR. DOME (Perm.)
All equipment must be installed in accordance with these
It is important to use and maintain all public playground equipment
PACKING LIST
Bag
Dome Anchors
Braces (Almond 2'-2-1/2")
Braces (Grey 2'-3")
Braces (Lt. Blue 1'-11-1/2")
5 TOTAL PCS
IMPORTANT
It contains important replacement parts
You can receive your free copy by calling
26 116-545
62 316-501
31 216-501
26 326-501
1 416-350
1 805-532
1 805-534
30 905-847
1 Maintenance Checklist
WT 97#
www.sportsplayinc.com
Please retain this
Appropriate publications,
Dome use/fall zone is an
HARDWARE BAG
5/16" x 2½" Button HD Bolts
5/16" Flat Washers
5/16" Hex Nuts
5/16" Lock Washers
Socket Key
Warning Label
SportsPlay Label
Bolt Cap
CLASS 70
1
Page
Rev 4/19/10
18'6" circle
