Top Panel

7
5
6
1. 14x24-bit DSP samplers/jingles

14 buttons are equipped to instantly trigger samples and jingles. The USB (micro)
port is equipped to import your own audio files by connecting to your PC*.



14 default samples are preloaded at the factory and they are as follows;
Horrify
OMG
Birdy
LOL
Helpness
Slap
Laugh
What
Air Horn
Shocking
Curosity
Innocent
Beat Up
Fun


*See 'Assigning samples to sample pads' (pg. 12) to assign your own sample sounds.
8
1 2
8 9

a horrifying sound effect sample

a 'Oh My God!' sample

a bird flying over sound effect sample

a 'Laugh Out' Loud effect sample

a 'helplessness' sound effect sample

a face slapping sample

a group laughing effect sample

a "What??" sample

a series of air horn sounds, sound effect sample

a "shocking" sound effect sample

a "curiosity" sound effect sample

a "innocent" sound effect sample

a "beaten up" sound effect sample

a croed laughing effect sample
3 4
13
10
11
12
