ICON LIVE CONSOLE User Manual page 9

2. 12x Vocal & Instrument presets

Individual control button for 8x Vocal & 4x Instrument DSP presets as well as a
Bypass button are equipped;
Vocal DSP
presets
Instrument DSP
presets


3. 13x Key control buttons for Vocal Tune

There are 12 Individual control buttons for controlling "Key" + 1 button to control
Voice Tune as well as a Bypass button.


12 Key buttons : C/C#/D/D#/E/F/F#/G/G#/A/A#/B





Voice Tune control buttons : Major/Natural Minor/Harmonic Minor/Melodic


10
11
12
4. 12x Semi Tone control buttons for Pitch Shift

12 Individual control buttons (1-12) for controlling "Semi Tone" as well as a
Bypass button are included.
5. Bluetooth On/Off button

Press this button to activate the Bluetooth function for connecting with your
mobile device for Background Music (BGM) input. A blue light will continuously
flash when activated and remain lit after it has successfully paired with your
mobile device.
6. +48V Phantom power On/Off button

Press to activate the +48V phantom power supply to your Ch.1 condenser
microphone input.



Reverb Delay

Hall

Room A

Room B

Echo A

Echo B

Chorus Reverb

Stereo Chorus

Multi Delay

Analog Delay

Spring Reverb

Plate
Minor. When pressed, the central 'circle' button
will illuminate as follows;
Major: not lit
Natural Minor:
Harmonic Minor:
Melodic Minor:
Green
Blue
Red
9
