The future of single fader DAW controllers has just arrived.
Welcome to the revolution!
Presenting the new standard in single motorized fader MIDI DAW
control surfaces - featuring a 16-panel, programmable digital touch
screen, with multiple simultaneous DAW control, highly advanced
software, easy plug-in control and intuitive, beautiful design.
