HANDICARE 4000 SM
Hi, it's me.
I'm stuck on the lift.
Can you help me?
Don't worry,
I'll be there
in a minute
Parti del OTA
Pièces de OTA
OTA teile
OTA onderdelen
Partes del OTA
OTA parts
*AA29344*
A A 2 9 3 4 4
I N S T R U C T I O N
INSTRUCCIÓN
INSTRUCTIE
ANLEITUNG
INSTRUCTION
ISTRUZIONE
ES
I T
NL
FR
US
DE
EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the 4000 SM and is the answer not in the manual?

Questions and answers

Summary of Contents for Handicare 4000 SM

  • Page 1 *AA29344* A A 2 9 3 4 4 HANDICARE 4000 SM I N S T R U C T I O N INSTRUCCIÓN INSTRUCTIE ANLEITUNG INSTRUCTION ISTRUZIONE Hi, it’s me. I’m stuck on the lift. Can you help me? Don’t worry, I’ll be there...
  • Page 2: Tools Required

    KIT: AA29344 TOOLS REQUIRED Pz 2 2 mm 3 mm Torx T20 42 mm INSTRUCTION 11P00266 Electro Static Discharge 1 OTA INSTRUCTION...
  • Page 3 EXPLANATION Only a technician certified for this lift should service this lift (for more detailled information about the required competence see the installation manual). The latest instructions for the lift and instructions for options are available for download at www.handicarepartners.com. [1] Check that all the components of the concerning kit are present.
  • Page 4 4 mm 3 OTA INSTRUCTION...
  • Page 5 EXPLANATION [2]Remove the upholstery. [3]Unscrew the top cover of the armrest{A}. Remove the top cover{B}. Remove the bottom cover{C}. [4]Remove the bottom cover of the seat base. [4]Fit the microphoneholder{A}. Install the microphone{B}. Fit the cap{C}. [5]Guide the OTA loom through the armrest hinge{A}. Connect the OTA loom with the adaptor loom{B}. Layout the loom in armrest to get correct length(C).
  • Page 6 5 OTA INSTRUCTION...
  • Page 7 EXPLANATION [6]Guide the OTA loom through the chair and seatbase: follow the path of existing wiring. Fasten the loom with the clips{B}. [7]Guide the loom through the chair axle. [8]Connect the adaptor loom with the push/microphone button{A}. Position the push button in armrest cover{B}. [9]Install the top cover of the armrest{A}.
  • Page 8 CLICK! 3 mm 7 OTA INSTRUCTION...
  • Page 9 EXPLANATION [11]Reinstall the upholstery. [12]Loosen the rivets(6x){A} and screws(2x){B} and remove the front cover{C}. [13]Disconnect the two wires of the battery. [14]Disconnect the battery wires from the mainboard. [15]Disconnect the battery wires from the on/-off switch. [11]Herinstalleer de bekleding. [12]Maak de pluggen (6x){A} en schroeven (2x){B} los en verwijder de voorkap{C}. [13]Maak de twee draden van de accu los.
  • Page 10 Push button Antenna Orange LED 2 Orange LED 1 Power Microphone/speaker SIM card 9 OTA INSTRUCTION...
  • Page 11 EXPLANATION [16]Connect the new battery loom{A} and put the wiring nicely behind the batteries{B}. Note: do not connect the loom to the OTA print yet. [17]Install the SIM card{A}. Press the print against the battery holder{B}. [18]Connect the OTA loom the print{A}. Connect the OTA switch loom to the print{B}. [16]Sluit de nieuwe accukabel aan{A} en leg de bedrading netjes achter de accu’s{B}.
  • Page 12 42 mm 11 OTA INSTRUCTION...
  • Page 13 EXPLANATION [19]Connect the wire of the antenne to the OTA print {A}. Fit the antenne on the back cover of the power pack {B}. [20]Guide the OTA loom{print part} behind the seat stem{A}. Connect the OTA loom parts{B}. Tuck the excess cable+connectors behind the seat stem{C}.
  • Page 14: Push Button

    CLICK! SIM card Microphone/speaker Power Antenna Push button Orange LED 1 Orange LED 2 13 OTA INSTRUCTION...
  • Page 15 EXPLANATION [23]Fit thespeaker+holder in the 42 mm-hole on the front cover. [24]Connect the speaker loom. [25]Connect the new battery loom to the mainboard at the indicated positions{A}. Connect the new battery loom to the on/-off switch{B}. Connect the new battery loom to the OTA print{C}. The green LED on the OTA print will blink once.
  • Page 16: Program With App

    3 mm 3 26 Hi, it’s me. Can you hear me? Numbers: tel. 1: ..tel. 2: ..tel. 3: ..tel. 4: ..tel. 5: ..Perfect, I understand you loud and clear Numbers: tel. 1: ..tel. 2: ..tel.
  • Page 17 EXPLANATION [26]Reinstall the front cover{A} and secure with the rivets(6x){B} and screws(2x){C}. [27]Using the APP on the phone, install the three telephone numbers to be called in case of emergency. And also the press-in time, before the OTA is activated, can be adjusted with the APP. [28]Check if the OTA is working well.
  • Page 20 Only a certified technician should install this kit. The latest instructions of the lift and instructions for options are available for download at www.handicarepartners.com. Partes del OTA Handicare 4000 SM Este manual contiene: Este kit solo lo debe instalar un técnico cualificado. Las últimas instrucciones del salvaescaleras y las instrucciones para las diversas opciones están disponibles para su descarga en www.handicarepartners.com.
