Installation Instructions
Original Instructions
ASEM 6300B Wall Mount Box PC
Catalog Numbers 6300B-PBCx and 6300B-PBDx
Topic
Summary of Changes
UL/cUL Mark Compliance
European Union Directive Compliance
Approximate Dimensions
Required Tools and Hardware
Installation Requirements
I/O Port and Slot Locations
Mount the Wall Mount PC
Connect the Peripheral Cables
Grounding and Bonding
Install the Ground Wire
Connect the Power
LED Status Indicators
Additional Resources

Summary of Changes

This publication contains the following new or updated information. This list includes substantive updates only and is not intended to reflect all changes.
Topic
Added enhancement of I/O ports and slots to "I/O Port and Slot Locations" section
ATTENTION: This equipment is intended for use in a Pollution Degree 2 industrial environment, in overvoltage Category II applications (as defined in
IEC 60664-1), at altitudes up to 2000 m (6561 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according to IEC/EN 61326-1. Without appropriate precautions, there can be
potential difficulties with electromagnetic compatibility in other environments due to conducted as well as radiated disturbance.
This equipment is considered open equipment, which means it must be mounted in an enclosure where the equipment can be operated from the front
panel.
The enclosure in which this equipment is installed must be accessed only with a key or tool, and only by trained and authorized personnel.
In addition to this publication, see the following:
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1, for more installation requirements
UL 50, CSA C22.2 No. 94.1, and IEC 60529, as applicable, for explanations of the degrees of protection provided by enclosures

UL/cUL Mark Compliance

Equipment with the UL/cUL mark complies with the requirements of UL 61010-1, UL 61010-2-201, CSA C22.2 No. 61010-1, and CSA C22.2 No. 61010-2-201. 
A copy of the certificate of compliance is available at rok.auto/certifications.

European Union Directive Compliance

This computer meets the European Union Directive requirements when installed within the European Union or EEA regions and have the CE marking. A copy of the
declaration of the conformity is available at rok.auto/certifications.
ATTENTION: This equipment is intended to operate in an industrial or control room environment, which uses some form of power isolation from the
public low-voltage mains. Some computer configurations cannot comply with the EN 61000-3-2 Harmonic Emissions standard as specified by the EMC
Directive of the European Union. Obtain permission from the local power authority before you connect any computer configuration that draws more
than 75 W of AC power directly from the public mains. All I/O cables must be used only indoors.
Page
1
1
1
2
2
2
3
3
3
3
3
4
5
5
Page
3
