MAINTENANCE
ERV
NOTE: The filters
supplied in the unit
are usually able to
keep the energy
exchange core clear for
several months. Finer filters
can be used but must be
cleaned more often. If
using finer filters, their
increased resistance to flow
must be allowed for in the
system design.
20 SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL
TRC1200

MAINTENANCE REQUIREMENTS

DANGER OF ELECTRICAL SHOCK WHEN SERVICING AN INSTALLED UNIT.
ALWAYS DISCONNECT POWER SOURCE BEFORE SERVICING! More than one disconnect switch
may be required.
Proper wiring size selection and wiring installation are the responsibility of the electrical contractor.
TO CLEAN THE ENERGY EXCHANGE ELEMENT
Vacuum the face of the energy exchange element yearly. Dust collects only on the entering face
of the energy exchange element, right where the filter sits. The interior of the energy exchange
element stays clean even if the element faces are dust covered. The core airflow paths are designed
to transport the air in a laminar motion. The core flutes move the air in a laminar airflow such that
particulate deposition is maintained at virtually nill.
1. Remove the filters.
2. Vacuum the exposed faces of the energy exchange core with a soft brush.
3. Vacuum out dust from the rest of the unit case.
4. Install new filters.
DO NOT WASH THE ENERGY EXCHANGE CORE.
Keep it away from water or fire to avoid damaging it. Always handle the core carefully.
Filters must be used or the energy exchange core will become blocked by dust and reduce unit efficacy.
In extreme cases components may be damaged.
INSPECT AND CHANGE THE FILTERS REGULARLY
Inspect and/or replace filters every two or three months when the unit is in regular use, or as needed.
1. To access the filters unlatch the access doors. The access doors may be removed.
2. Pull the dirty filters out and replace with new filters.
WARNING
CAUTION
®
