Summary of Contents for S&P TRC1200
- Page 1 ® TRC1200 E N E R G Y R E C O V E R Y V E N T I L A T O R Ins ta llation, Op era tion & M ain ten ance M a nua l S&P USA Ventilation Systems, LLC...
- Page 2 TRC1200 ABOUT S&P USA VENTILATION SYSTEMS TABLE OF CONTENTS TRC1200 info ...... 3-4 S&P USA Ventilation Systems (S&P USA) operations are based in Jacksonville, Florida. This geographically strategic location allows the shipment of products throughout the US and Canada. The Installation ......
- Page 3 TRC1200 Ventilation Type: Unit Dimensions & Weight: Static plate, heat and humidity transfer 45 1/8" L x 33 1/2" W x 53 5/8" H 337 lbs. Typical Airflow Range: 375-1,575 CFM Max. Shipping Dimensions & Weight (on AHRI 1060 Certified Core: One L62-G5 and...
-
Page 4: Installation
INSTALLATION TRC1200 SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®... -
Page 5: Planning Your Installation
FROM DAMPER BLADE WHEN FULLY OPENED TO BE 2". SMACNA RULES The TRC1200 is designed for installation indoors. Select a location that is central to the inside duct runs, APPLY. and close to both the exhaust duct (to the outside) and the Supply Air duct (from the outside). The unit VIEW can be installed in any orientation but the contractor is responsible for safe installation of the unit. - Page 6 INSTALLATION TRC1200 APPLICATIONS See figure F2 for examples of some common installation approaches. www.renewaire.com (800) 627- 4499 support@renewaire.com www.renewaire.com (800) 627- 4499 support@renewaire.com FIGURE F2 COMMON INSTALLATION APPROACHES www.renewaire.com (800) 627- 4499 support@renewaire.com DUCTS TO THE OUTSIDE The exhaust outlet and Supply Air inlet on the outside of the building should be at least ten feet apart to avoid cross-contamination.
- Page 7 AIRFLOW RATES The airflow rate for both the Supply Air and the Exhaust Air should be roughly equal (or balanced”) for best performance of the TRC1200 Unit. See unit specification sheet for CFM/ESP curves. DUCT TRANSITIONS Ducts should enter and exit the unit through smooth, gradual transitions.
-
Page 8: Sound Attenuation
Follow SMACNA guidelines. RADIATED NOISE The TRC1200 is insulated with high-density fiberglass. This provides significant attenuation of radiated sound. The inlet ducts can be significant sources of radiated sound as well. The OA and RA ducts (inlet ducts) should be insulated for sound control. - Page 9 TRC1200 FIELD CONVERSION OF OPENINGS The TRC1200 is designed to allow field conversion of the unit openings. This means the motorized impeller subassemblies can be moved to an adjacent wall of the unit if that opening is preferred. The outlet openings can also be moved to an adjacent wall.
- Page 10 INSTALLATION TRC1200 TO FIELD CONVERT OUTLET OPENING 1. Remove the patch pan (F) from the desired opening. 2. Using the exposed sheet metal cutout, cut the insulation from the desired opening. 3. Seal the edges of the cut insulation to prevent erosion of the insulation edges and having debris in the airstream.
-
Page 11: Installation Instruction
Single phase ECM motors are NOT suitable for use with solid state speed control. They already have speed control built into the motor electronics. WARNING Secure the TRC1200 with straps or clamps so that it cannot fall or tip in the event of accident, structural failure or earthquake. CAUTION The TRC1200 weighs 340 lbs. -
Page 12: Wiring Schematics
INSTALLATION TRC1200 WIRING SCHEMATICS Schematics shown are representative of standard units. See Unit Schematic label for detailed information. TRC1200 P1 SINGLE PHASE UNIT SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®... - Page 13 INSTALLATION TRC1200 TRC1200 P3 THREE PHASE UNIT SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 14 This ERV is provided with a Class II 24VAC power supply system that operates the unit’s contactor(s) for TRC1200. The ERV’s 24VAC Power Supply can also be used to power the externally-installed controls system: up to 8VA of power is available.
- Page 15 INSTALLATION TRC1200 OBSERVE THESE LIMITS TO WIRE LENGTH AND GAUGE in order to ensure reliable operation of the control system. Wire Gauge Circuit Length 100' 150' 250' 400' 700' 1000' “Circuit Length” is distance from ERV to control device. CONTROL WIRING SCHEMATICS...
- Page 16 INSTALLATION TRC1200 NOTE: Be sure to AN EXTERNAL CONTROL DEVICE USING Connect Blue & First Yellow Leads remove cap from UNIT'S 24VAC POWER SUPPLY pressure port before UNIT INTERNAL CONTROL WIRING (SIMPLIFIED) inserting tubing. External Control is BLUE powered by 24VAC...
-
Page 17: Measuring Airflow
Do not relocate Pressure Ports (4) pressure ports. Pressure Ports (4) FIGURE F3 AIRFLOW DIAGRAM TRC1200 NOTE: Pressure drop DIFFERENTIAL STATIC ACROSS CORE DSP VS. CFM of clean 2” MERV-8 0.15 0.20 0.25 0.30... -
Page 18: Filter Specifications
OPERATION TRC1200 Pleated_Filter_PD_NOV15.xlsx 14+16x20x2 MERV 8 (IOM) FILTER SPECIFICATIONS • (2) 14" x 20" x 2" and (2) 16" x 20" x 2" (nominal) pleated filters. Actual size: 13.5" x 19.5" x 1.75" and 15.5" x 19.5" x 1.75". • Optionally (4) 15" x 20" x 2" (nominal) pleated filters can be used. -
Page 19: Maintenance
MAINTENANCE TRC1200 SERVICE PARTS www.renewaire.com (800) 627- 4499 support@renewaire.com TRC1200 SERVICE PARTS SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®... -
Page 20: Maintenance Requirements
MAINTENANCE TRC1200 MAINTENANCE REQUIREMENTS WARNING DANGER OF ELECTRICAL SHOCK WHEN SERVICING AN INSTALLED UNIT. ALWAYS DISCONNECT POWER SOURCE BEFORE SERVICING! More than one disconnect switch may be required. Proper wiring size selection and wiring installation are the responsibility of the electrical contractor. -
Page 21: Motor Maintenance
MAINTENANCE TRC1200 MOTOR MAINTENANCE The motor needs no lubrication. If necessary vacuum clean the blower wheels at the same time you clean the face of the energy exchange element (annually). WARNING RISK OF INJURY OR DAMAGE. Motor has an automatic reset thermal protector. Disconnect power before servicing or resetting motor thermal protector. - Page 22 MAINTENANCE TRC1200 MAINTENANCE LOG ENTER DATES OF SERVICE OA FILTER RA FILTER INSPECTION/ CLEAN CLEAN INITIALS CHANGE CHANGE CLEANING CORE BLOWERS SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 23 MAINTENANCE TRC1200 MISCELLANEOUS SERVICE NOTES INITIALS DATE SERVICE SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL ®...
- Page 24 S&P USA VENTILATION SYSTEMS Enab ling the World t o Bre athe B et ter Air ® S&P USA VENTIL ATION SYSTEMS, LLC S&P CANADA VENTILATION PRODUCTS, INC. 6393 Powers Avenue 6710 Maritz Drive, Unit 7 Jacksonville, FL 32217 Mississauga, ON L5W 0A1, Canada SolerPalau-USA.com SolerPalauCanada.com 800.961.7370...
