Summary of Contents for S&P TRC500
- Page 1 INSTALLATION, OPERATION & MAINTENANCE MANUAL ENERGY RECOVERY VENTILATOR TRC500 WWW.SOLERPALAU-USA.COM...
- Page 2 Our commitment in providing only the very highest standards of customer service is key to our company strategy. TRC500 info ......3-4 Installation ......5-14 Soler & Palau Ventilation Group is the world’s leading fan manufacturer. It celebrated its 50th anniversary Start-up .........
-
Page 3: Trc500 Info
TRC500 TRC500 INFO INDOOR UNIT SPECIFICATIONS Ventilation Type: Shipping Dimensions: Static Plate, Heat and Humidity Transfer 48" L x 41" W x 18" H (in carton) 55" L x 42" W x 22" H (on pallet) Typical Airflow Range: 200-540 CFM... - Page 4 TRC500 TRC500 INFO 1.800.961.7370 WWW.SOLERPALAU-USA.COM INSTALLATION, OPERATION AND MAINTENANCE MANUAL...
-
Page 5: Installation
YOUR INSTALLATION The TRC500 is designed for installation indoors. Select a location that is central to the inside duct runs, and close to both the exhaust duct (to the outside) and the fresh air duct (from the outside). The unit can be installed in any orientation but the contractor is responsible for safe installation of the unit. - Page 6 Position the duct adapters over (4) 8” x12” duct flanges come standard with the the openings. Install them with supplied self- TRC500 unit. They are shipped loose in the box drilling screws. and can be installed with screws provided. Holes Keep insulated duct runs as short and direct are provided on the inlet and outlet side of the unit.
- Page 7 Ports on unit. Position duct flanges over openings. system’s air handler. This minimizes the amount of Install with supplied screws. air that the air handler can pull through the TRC500 when outside air ventilation is not desired. Or fabricate equivalent, by forming a flange on the first duct section and screw it to the TRC500.
- Page 8 TRC500 INSTALLATION PLANNING WARNING YOUR INSTALLATION RISK OF FIRE, ELECTRIC SHOCK, OR INJURY. OBSERVE ALL CODES AND THE FOLLOWING: 1. Before servicing or cleaning the unit, switch If this unit is exhausting air from a space in power off at disconnect switch or service pan-...
- Page 9 TRC500 INSTALLATION TRC500 P1 WIRING SCHEMATICS SINGLE PHASE UNIT - STANDARD 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM...
- Page 10 To avoid motor bearing damage and noisy and/ selected for the loads and substrates involved. Secure or unbalanced blowers, keep drywall spray, the TRC500 so that it cannot fall or tip in the event of construction dust, etc., out of unit. accident, structural failure or earthquake.
- Page 11 These ERVs may be ordered with factory-installed features including Electronically Commutated Motors. Consult the supplemental Installation and Operation Manual(s) for these features if supplied. NOTE: Standard TRC500 with single phase original Le TRC500 avec moteurs d’équipement d’origine equipment motors are suitable for use with solid monophasés sont adaptés pour une utilisation avec...
- Page 12 2 to determine motor power and possibly lead to injury! voltage installed in your TRC500. Follow these steps: WARNING 1. Confirm the voltage of the power supply matches the unit.
- Page 13 In extreme TRC500. The ERV’s 24VAC Power Supply can also cases, the transformer itself is designed to fail safely. be used to power the externally-installed controls system: up to 8VA of power is available.
- Page 14 TRC500 INSTALLATION CONTROL WIRING NOTE: The simplified schematics below show CAUTION SCHEMATICS only the relevant portions of the low-voltage Be careful if the external control system provides control circuit in the ERV unit and representational 24VAC power at its control output: make sure external control approaches.
-
Page 15: Start-Up
(-) to the Fresh Air (FA) port. • To read SCFM of Room Air (RA) install the “high” AIRFLOW DIAGRAM TRC500 pressure side (+) of your measuring device to the PRESSURE PORTS (4) Room Air (RA) port and the “low” pressure side (-) to the Exhaust Air (EA) port. - Page 16 Pleated_Filter_PD_AUG17 14x20x2 MERV 8 (IOM) TRC500 START-UP MEASURING AIR FLOW FILTER SPECIFICATIONS • (2) 14” x 20” x 2” (nominal) pleated filters. Actual size: 13.5” x 19.5” x 1.75” • Unit shipped with MERV-8 Filters. Minimum recommended effectiveness: MERV-6 INITIAL PRESSURE DROP OF MERV 8 FILTERS SUPPLIED WITH THIS UNIT.
-
Page 17: Maintenance
TRC500 MAINTENANCE SERVICE PARTS TRC500 www.renewaire.com (800) 627- 4499 support@renewaire.com 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM... - Page 18 INSPECT AND CHANGE THE FILTERS REGULARLY. Inspect and/or replace filters every two or three months when the TRC500 is in regular use, or as needed. Filters must be used or the energy exchange core will become blocked by dust and the unit will not do its job.
- Page 19 TRC500 NOTES 1.800.961.7370 INSTALLATION, OPERATION AND MAINTENANCE MANUAL WWW.SOLERPALAU-USA.COM...
- Page 20 (800) 961-7370 FAX: (800) 961-7379 6393 POWERS AVE JACKSONVILLE, FLORIDA 32217 USA WWW.SOLERPALAU-USA.COM CANADA (416) 744-1217 FAX: (416) 744-0887 5600 AMBLER DRIVE MISSISSAUGA, ON L4W 2K9 - CANADA WWW.SOLERPALAUCANADA.COM 132102_003 (10/18)
