Product Information

2.1

VESDA-E IDNet Detector Components

The VESDA-E IDNet detector is physically the same product as respective conventional detector with the
same dimensions. It contains the same components as respective conventional detector with the addition of a
built in VESDA-E IDNet module. All components of the VESDA-E IDNet detector are shown in Figure 2-1
below.
Refer to the relevant conventional product guide for further information regarding maintenance scheduling and
availability of spare parts.
C
F
B
Note: Filter is hidden for better view.
https://simplex-fire.com
Simplex VESDA-E VEU IDNet Detectors Product Guide
D
A2
E
A1
Figure 2-1: VESDA-E IDNet Detector Components
Legend
A1 Fascia for 4098-VEU-
A00 (LED's only)
A2 Fascia for 4098-VEU-
A10 (with 3.5"
touchscreen display)
B Filter
C Chamber Assembly
D Aspirator
E Sampling Module
F Base
G IDNet Interface Card
G
