- Page 1 4098-9687 Stand Alone Duct Detector Installation Instructions 574-777 Rev. B firealarmresources.com...
- Page 2 Blank Page firealarmresources.com...
- Page 3 NOTICE THIS DEVICE IS A STAND ALONE DUCT DETECTOR. IT IS DESIGNED TO SAMPLE THE AIR FLOW PASSING BY IT IN THE AIR DUCT TO DETERMINE WHETHER IT CONTAINS UNACCEPTABLE LEVELS OF SMOKE. THE EFFECTIVENESS OF A STAND ALONE DUCT DETECTOR IS HIGHLY DEPENDENT UPON: •...
- Page 4 Blank Page firealarmresources.com...
-
Page 5: Table Of Contents
Suffix “C” or “CA” following an 8-digit Product ID number denotes ULC-listed product. 2000 Simplex Time Recorder Company, Westminster MA 01441-0001 U.S.A. 2000 Simplex International Time Equipment Co., Ltd., Mississauga, Ontario L4V 1H3 Canada. All specifications and other information shown were current as of publication, and are subject to change without notice. - Page 6 BLANK PAGE Blank Page firealarmresources.com...
-
Page 7: General Description
General Description Introduction The 4098-9687 Stand Alone Duct Detector (see Figure 1 on page 2) is designed to sample air and detect smoke in air ducts. The 4098-9687 duct detector uses the 4098-9601 photoelectric smoke detector. The 4098-9687 Stand Alone Duct Detector provides fail-safe operation, the loss of power or detector removal activates the Duct Detector Housing alarm relay contacts. - Page 8 General Description, Continued HOUSING BASE BASE GASKET COVER GASKET CAP PLUG SHIP GROUP 748-518 SEE NOTE STATUS LED 4098-9601 SMOKE DETECTOR #8 CAPTIVE PANHEAD SCREW QTY: 4 DETECTOR MAGNETIC TEST LOCATION 3/4" CONDUIT ENTRY # 12-18 AWG WIRE RECOMMENDED SMOKE PORT/AIR FLOW TEST HOLES DETECTOR BASE PCB ASSEMBLY...
-
Page 9: Electrical Specifications
Electrical Specifications 4098-9687 Stand Alone Duct The 4098-9687 Stand Alone Duct Detector can be powered from 24 VDC, 24 VAC, or Detector Housing 120 VAC power sources. Separate terminal block connections are available for the 24 VDC/VAC or the 120 VAC power sources. When the 120 VAC connection is used, no connections should be made to the 24 VDC/VAC inputs. - Page 10 Duct Control Station is 500 feet. All relay contacts rated 5 amp at 24 VDC/VAC; or 120 VAC resistive non-power-limited. 4098-9842 DUCT CONTROL STATION Figure 2. Wiring the 4098-9687 Stand Alone Duct Detector for 24 VDC or 24 VAC Operation Continued on next page firealarmresources.com...
- Page 11 Control Station is 500 feet. All relay contacts rated 5 amp at 24 VDC/VAC; or 120 VAC resistive nonpower-limited. 4098-9842 DUCT CONTROL STATION Loop ground wire around green ground screw. Figure 3. Wiring the 4098-9687 Stand Alone Duct Detector for 120 VAC Operation firealarmresources.com...
-
Page 12: 4098-9842 Duct Control Station
Ensure all smoke or aerosol has been purged from the smoke detector in the 4098-9687 Stand Alone Duct Detector. At the 4098-9842 Duct Control Station, rotate the Key Switch to the “TEST/RESET” position for two seconds. Return the Key Switch to the “NORMAL”... - Page 13 4098-9842 Duct Control Station, Continued Table 1. Duct Control Station Status List Indicator Mode Power-On Alarm LED Sounder Control Relay Normal Deactivated Alarm All On Missing Detector Activated Head Trouble Power Fail All Off firealarmresources.com...
-
Page 14: Installation
Installation Pre-Installation Routines The 4098-9687 Stand Alone Duct Detector should be installed in a location of relatively nonturbulent air flow and within the intended operating velocity range of 300-4000 feet-per-minute (91 to 1220 M/min.). Simplex recommends measurements of air flow and examination of engineering specifications that define expected duct air velocities under all conditions. - Page 15 Installation, Continued Rules to Follow (continued) DETECTOR EXHAUST DAMPER RETURN EXHAUST DO NOT LOCATE DETECTOR HERE RETURN AIR DAMPER FRESH SUPPLY INTAKE DO NOT LOCATE FILTER DETECTOR (O.K.) DETECTOR HERE BANK Figure 7. Duct Detector Placement - Location of Dampers Locate air duct detectors on the return or supply duct of the equipment’s air handling system.
-
Page 16: Stand Alone Duct Detector Installation
Installation, Continued Stand Alone Duct Detector Tape the template (Figure 14) on the duct surface as shown in Figure 8. Installation Note: Do not position the template with edges angled with respect to air flow direction (Figure 8). Drill two 1 5/16-inch (33.32 mm) holes (marked “A” in Figure 14) as located by the template. - Page 17 Installation, Continued Stand Alone Duct Detector Installation (continued) SEE NOTE 1 EXHAUST TUBE INLET TUBE RETAINER BRACKET INLET TUBE HOLES FACE UPSTREAM OF AIR FLOW INLET RUBBER TUBE PLUG SEE NOTE 2 Notes: The tab on the inlet tube retainer bracket indicates the inlet hole side of the pipe. The inlet tube must be installed through the hole in the housing corner next to the smoke port/air flow test holes.
-
Page 18: Wiring Procedures
Installation, Continued Note: If a support hole is being used, be sure to insert the inlet tube through Stand Alone Duct Detector the hole on the far side of the duct. Installation (continued) Fasten the tube retainer using two #8 machine screws. Notes: A. -
Page 19: Accessory Installation
Installation, Continued Accessory Installation The 4098-9842 Duct Control Station is intended for installation to a standard double-gang outlet box having a depth of at least two inches. See Figure 11 for basic mounting details. Make wiring connections in accordance with the wiring diagrams (Figures 2 and 3) prior to attaching accessory to the box. -
Page 20: Detector Replacement
Installation, Continued To properly remove and replace the detector to the base (see Figure 1): Detector Replacement Remove power from the Stand Alone Duct Detector. Loosen the four screws that secure the clear plastic cover to the housing base. Insert a small blade screwdriver into the lock release slot in the base. Rotate the detector counterclockwise to remove it from the base. -
Page 21: Magnetic Test For Photoelectric Detectors
The 4098-9601 photoelectric detector may be tested by placing a magnet at the Photoelectric Detectors location indicated by a “TEST” mark embossed on the cover for four (4) seconds (see Figure 12). Use the Simplex Magnet Tester (Part No. 553-810), Table 3, and the following information to test detectors. TEST MARK... -
Page 22: Preferred Method Of Testing Smoke Detectors/Sensors
Installation, Continued • Magnetic Test for NON-FUNCTIONAL - If the detector is less sensitive than the minimum Photoelectric Detectors, allowable sensitivity, the visible LED does not flash normally. When in (continued) MAG TEST, the visible LED slowly flashes four times, once every two seconds. -
Page 23: Air Differential Pressure Test
Installation, Continued Air Differential Pressure Test With the air handling unit turned on and all filters and dampers in place, measure the air differential pressure using a Dwyer Instrument Co. (Michigan City, Ind.) No. 20026 0 to 2” H O (or equivalent) differential pressure gauge. Take measurements from inside of the detector/sensor housing before the cover is installed. -
Page 24: Template
POSITION 1 AND 2 HOLES MARKED "A" ARE FOR SAMPLING AND EXHAUST TUBES. HOLES ARE 1 5/16" INCH (33.32mm) Cut and tape Template to the Duct Surface. Refer to the Duct Housing Installation Section (Pages 8-12). NOT ALLOWED POSITION 1 POSITION 3 DETECTOR DETECTOR... - Page 25 Blank page firealarmresources.com...
- Page 26 Blank page firealarmresources.com...
- Page 27 Blank page firealarmresources.com...
- Page 28 Simplex Time Recorder Co., • Simplex Plaza • Westminster, Massachusetts 01441-0001 U.S.A. Rev. B 574-777 Simplex International Time Equipment, Co., LTD. • Mississauga, Ontario, Canada firealarmresources.com...
