Batch Feeder Diagram - Hasselblad Batch Feeder User Manual

Batch Feeder Diagram

A
C
D
E
Figure 1: Hasselblad Flextight 848 Scanner with Batch Feeder
A Hasselblad Flextight 848, 949 or X5 Scanner.
B Batch Feeder
C Dust cover:
to protect the originals and scanner entrance from dust.
D Magazine:
showing original holder position 1.
E
Magazine:
showing original holder position 10.
F
Power Indicator (Green)
switched on.
G Motor Drive Indicator (Yellow)
lights up when the scanner is repositioning the optics, drum
H Scan Indicator (Red)
ning, then an error has occurred - please contact your Flextight
dealer for assistance.
4
B
F
G
H
-
