- Page 1 TECHNICAL GUIDE PACKAGED PRODUCTS V363 SFE FILTRATION KIT WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
-
Page 2: Technical Guide
Operating pressure: 1.5 - 6 bar CI-F-363SFE-0011 > C&I Filtration kit Premium - Water temperature: 5 - 38°C • SIATA V363 SFE • Ambient temperature: 5 - 50°C (NBP premium full) Premium version: packaging dimensions: 120 x 80 x 50 cm/ •... - Page 3 BILL OF MATERIAL OF THE PREMIUM KITS BOX PREMIUM KIT BOX COMPOSITION Compensator 1 Compensator 2 By-pass Pressure gauge & fittings Piping to installto the tank ITEM N° DESCRIPTION Inlet outlet & bypass assy Top of the tank piping Bottom of the piping Backwash drain Rinse drain Valve &...
-
Page 4: Support Frame
BILL OF MATERIAL OF PREMIUM KITS SUPPORT FRAME ITEM N° DESCRIPTION DN 50 pipe collar kit Vertical frame profile Horizontal frame profile Plug Floor support L plate Spring nut Washer Screw WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS... - Page 5 BILL OF MATERIAL OF THE BUDGET KITS ITEM N° DESCRIPTION Valve V363 Sea water Controller Bracket Fitting DN 50 PVC to glue Fitting nut Manual valve DN 50 Pressure gauge front mount 6 - 0 bar Screw to fix the timer M4 Screw to fix lower part of the timer to the bracket SFE timer model SFE-BK210/05 Ø...
- Page 6 DIMENSIONS OF THE PREMIUM KITS PREASSEMBLED PARTS WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
- Page 7 DIMENSIONS OF THE BUDGET KITS PREASSEMBLED PARTS WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
- Page 8 ASSEMBLY ON THREADED STRUCTURAL TANKS DIMENSIONS A* mm B mm C mm D mm E mm Structural tank 21x60 Structural tank 24x69 Structural tank 30x72 Structural tank 36x72 *“A” quotes will vary depending on tank tolerances on height, we advise to measure this distance directly on site and glue this pipe as last one. WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
- Page 9 ASSEMBLY ON FLANGED TANKS DIMENSIONS A* mm B mm C mm D mm E mm Structural tank 42x78 Structural tank 48x82 *“A” quotes will vary depending on tank tolerances on height, we advise to measure this distance directly on site and glue this pipe as last one. The kit piping is DN 50.
- Page 10 HYDRAULIC CONNECTIONS OF THE CONTROLLER WATER OR COMPRESSED AIR CAN BE USED TO PRESSURIZE THE VALVE Warning! Pressurizing fluids to control the valve must comply with the following specifications: Compressed air: must be filtered from oils and • impurity, whilst being at ambient humidity otherwise seals of the distributor system can be damaged;...
- Page 11 FLOW DIAGRAMS OF THE VALVE SERVICE BACKWASH INLET INLET OUTLET OUTLET FAST RINSE INLET OUTLET WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
- Page 12 DIFFERENTIAL PRESSURE SWITCH’S HYDRAULIC CONNECTIONS The “High” pressure port (center mounted) is piped to the inlet side of the filter. The “Low” pressure port (top center mounted) is piped to the outlet side of the filter. You MUST use a second wrench on the Low Pressure port when tightening tube fittings.
-
Page 13: Electrical Connections
ELECTRICAL CONNECTIONS 1. SFE WIRING DIAGRAM AC adapter input (low voltage) 2. CONNECTION OF THE DIFFERENTIAL PRESSURE SWITCH WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS... - Page 14 3. INTERLOCK CONNECTION OF 2 OR MORE SFE The regeneration signal can be used as inhibit input for others SFE to connect more units in parallel. This will prevent to have more than one SFE in regeneration/backwash at the same time. To interlock more SFE controllers, connect terminal strip positions #10, #9, #6, #4 of the SFE to the equivalent position on the 2...
- Page 15 4. CASCADE REGENERATION OF PARALLEL UNITS USING END CYCLE SIGNAL AND REMOTE START INPUT On filters, it is useful to cascade backwashes from the 1 to the last filter. In order to make it work, connect the SFE as shown in the drawing on the left and as summarized in the below table.
- Page 16 PROGRAMMING The following is a quick programming guide for time clock filters with backwash on programmed day interval. For other type of programming refer to the SFE controller manual which can be downloaded at: https://www.pentairaquaeurope.com/sites/default/files/collaterals/manual_sfecontroller_multilingual.pdf 1. PROGRAMMING LEVEL 1 PARAMETER NAME / DISPLAY VALUE RANGE / DESCRIPTION...
- Page 17 2. PROGRAMMING LEVEL 2 PARAMETER NAME / DISPLAY VALUE RANGE / DESCRIPTION PARAMETER TO SET COMMENT Press for 5 seconds to enter master programming Set the start time clock or remote signal with Set Backwash start mode arrows and confirm with Set backwash time with arrows and confirm Backwash duration...
-
Page 18: Tips And Suggestions
TIPS AND SUGGESTIONS To avoid valve vibration during the operation, interrupt the conduction drain as shown in the pictures. For an optimum valve operation, the drain flow needs to be regulated by using the manual valves installed in the drain, according to the flow rate and the inlet pressure. - Page 19 NOTES WATER PURIFICATION TANKS AND SYSTEMS - PACKAGED PRODUCTS - C&I SYSTEM SOLUTIONS...
