Electric Connection - Microsensor MPM430 Operation Manual

3.2 Installation
3.2.1 Attention before installation
a) Please be sure the measuring pressure will not exceed the
transmitter measurement range;
b) Please be sure the measuring media is compatible with the
construction material;
c) Please be sure the measuring media will not jam the liquid
leading hole.
3.2.2 Installation Method
Usually the transmitter should be mounted vertically up to the horizontal
direction. In order to install and maintain conveniently, it is recommended
to install a cut-off value between the transmitter and the measuring point.
3.2.3 The pressure port can be customized for users according to
special request.

4 Electric Connection

4.1 The transmitter could be connected with the external circuit through
socket, cable or connection box.
Wire Color
Black
Red
Figure 1
Table 1
Plug Elctric connection
Pin 1
Pin 2
3
+V
0V/+OUT
