- Page 1 MPM4511A Operation Manual V1.1...
-
Page 2: Specifications
1 Introduction MPM4511A pressure transmitter has the pressure chamber which is made of single complete stainless steel piece, and all-metal sealing construction.The transmitter uses silicon micro-fusion technology and has specially designed construction, with overall digital calibration and temperature compensation. - Page 3 ±2%FS (outside temperature compensation range) Compensation temperature: -10℃～80℃ Operating temperature: Single output: -40℃～125℃ Dual output: -40℃～85℃ Storage temperature：-40℃～125℃ Medium compatibility: Various media compatible with 17-4PH and 304 stainless steel 3 Outline Construction Unit: mm B41(M12×1 4-pin, metal M12 thread) B42(M12×1 5-pin, plastic M12 thread)
-
Page 4: Electrical Connection
B5(Packard) B2(Cable) 4 Electrical Connection B41（M12×1 B41 （ M12×1 5-pin） (Cable) 4-pin） (Packard Plug ) Definition Single output Dual Output Single output Dual output Single output Current Voltage Voltage Voltage Current Voltage Current Voltage Current Voltage 2-wire 3-wire 3-Wire 3-Wire 2-wire 3-wire 3-wire... -
Page 5: Installation Instructions
Black Black （+OUT （+OUT 1） 1） (+OUT1) (+OUT1) +OUT Black Black White White （+OUT （+OUT (+OUT2) (+OUT2) 2） 2） Null White Green Green Null Null 5 Installation instructions 1) The measured pressure should not exceed the measurement range of transmitter, and the measured medium should be compatible with structural material. - Page 6 datasheet. Customized products are available according to customers’ requirements. The maximum torque during the installation and uninstallation of the transmitter is about 20N•m ~ 25N•m. 6 Shipment Included in the delivery 6.1 Unpacking Check whether the package box is in good condition and set it down according to the “Upward”...
- Page 7 and the shuttle transportation fees should be borne by users.
