HALF POWER MODE
lf for any reason, you don't need to use the full potential of the unit, HALF POWER
MODE can be switched on.
When OFF, the heater will work at FULL POWER(3200W) and reheating is fast.
When ON, the heater will work at HALF POWER (1600W) but reheating will also be
slower.
1. Press the MENU button until HALF POWER MODE is shown on the display.
2. 2. Use the DOWN and UP buttons to switch the half power mode ON or OFF.
3. Once the correct mode is shown on the display, press the ENTER button to confirm.
GENERAL OPERATING INSTRUCTIONS
the unit has a HOT and powerful output ! Keep a minimum distance of 1m .
1. Put the fogger on a flat and very stable surface. Make sure that nobody can put their
hands just in front of the output. The fog is very hot and can cause serious burning!!!
2. Make sure the fog liquid tank is not empty. Always use good quality fog liquid to fill up
the tank. Close the tank immediately to prevent dirt to enter the reservoir!
3. Make sure to plug the fogger in a mains wall socket with earth connection.
4. Switch the fogger on and wait for about 3 to 4 minutes.(warm up time).
NEVER use the machine with an empty reservoir. This can damage the pump !
DMX-OPERATION:
Important: The electrical installation should be carried out by qualified personal
only, according to the regulations for electrical and mechanical safety in your
country.
Electrical installation:
1. The DMX-protocol is a widely used high speed signal to control intelligent light and
other equipment. You need to "daisy chain" your DMX controller and all the connected
units with a good quality balanced cable.
2. Both XLR-3pin and XLR-5pin connectors are used, however XLR-3pin is more popular
because these cables are compatible with balanced audio cables.
Pin layout XLR-3pin: Pin1=GND~Pin2=Negative signal (-)~Pin3 = Positive signal (+)
Pin layout XLR-5pin: Pin1=GND~Pin2=Negative signal (-)~Pin3=Positive signal (+) ~
Pins4+5 not used.
3. To prevent strange behavior of the light effects, due to
interference, you must use a90Ω to 120Ω terminator at the end
of the chain. Never use Y-splitter cables, this simply won't work!
4. Make sure that all units are connected to the mains.
5. Each unit in the chain needs to have its proper starting address so it knows which
commands from the controller it has to decode. In the next section you will learn how to
set the DMX addresses.
