Em5b 4 USING ECH2O UTILITY
4.2.5

Instantaneous Measurements (Scan)

ECH2O Utility gives you the ability to take real-time sensor mea-
surements with your Em5b logger. This is most useful as a trou-
bleshooting feature to test if a sensor is reading properly. You can
also see how sensors react to environmental changes.
To take this type of reading click the "Scan" button in the toolbar,
or go to Actions Scan Logger Ports. The Em5b takes readings on
each of the ports, then displays a screen similar to the one below.
Figure 1: Em5b Port Scan
All five ports are displayed, along with the measurement for each
port on the units appropriate for the sensor. You can change mea-
surement units in the Preferences Menu (see "Measurement Units"
in Chapter 5). Click the sensor name to see the reading as raw data.
The five ports are displayed, along with the measurement for each
port in the current selected unit. If nothing is plugged in to a port,
