- Page 1 Aquabeam ANUAL Please read these user manual carefully before use www.lightsky.com.cn www.lightsky.de FLY DRAGON LIGHTING EQUIPMENT CO., LTD...
-
Page 2: Table Of Contents
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD www.lightsky.de Contents 1. Safety information....................2 2.Technical information....................3 3.Attachment and body size ..................7 4.Installation and connecting..................8 5. Control panel......................9 6. Menu setting......................10 7.Channel function.....................12 Circuit connecting diagram ..................17 9.Cleaning and maintenances..................18 10.Troubleshooting..........................18 Duty exonerative and copyright protection ............19... -
Page 3: Safety Information
www.lightsky.com.cn www.lightsky.de SAFETY INFORMATION • Installation Make sure all parts for fixing the projector are in a good state of repair. Make sure the point of anchorage is stable before positioning the projector. The safety chain must be properly hooked onto the fitting and secured to the framework, so that, if the primary support system fails,the fitting falls as little as possible. -
Page 4: Technical Information
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD TECHNICAL INFORMATION ● ● Resolution Power supplies available - PAN = 2.11° AC100-240V/50-60Hz - PAN FINE = 0.008° ● Power - TILT = 0.94° 628W - TILT FINE = 0.004° ● Features ● Lamp(330W) Remote control lamp’s switch function, - Brand:SIRIUS HRI 330W XL OSRAM display light and lamp’s using time,... - Page 5 www.lightsky.com.cn www.lightsky.de Static wheel(1 white + 12 gobo) (please refer to the actual material) White Color Wheel:(please refer to the actual material) Magenta Cyan Yellow Dimmer Dark blue Jacinth CTO1 CTO2 Aquamarine Blue Dark green Pink Green Purply LIGHT SKY...
- Page 6 FLY DRAGON LIGHTING EQUIPMENT CO.,LTD PROFESSIONAL SHOW LIGHTING...
- Page 7 www.lightsky.com.cn www.lightsky.de illumination and intensity distribution curve comparison chart Distance IP3000 IP2000 480000 192000 440000 176000 400000 160000 360000 144000 128000 320000 280000 112000 96000 240000 80000 200000 64000 160000 IP3000 120000 48000 32000 80000 IP2000 16000 40000 -0.3 -0.2 -0.1 Diameter(m) LIGHT SKY...
-
Page 8: Attachment And Body Size
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD ATTACHMENT AND BODY SIZE USER MANUAL BRACKET LAMP (fitted into projector) SAFETY CORD WARRANTY CARD DMX CABLE Attachment contents- Fig. 1 Body Size---Fig 2 PROFESSIONAL SHOW LIGHTING... -
Page 9: Installation And Connecting
www.lightsky.com.cn www.lightsky.de INSTALLATION AND CONNECTING Installing the projector- Fig. 3 The projector can be installe d on the floor resting on special rubber feet, on a truss or on the ceiling or wall. WARNING:with the exception of when the projector is positioned on the floor, the safety cable must be fitted. This must be securely fixed to the support structure of the projector and then connected to the fixing point at the centre of the base. -
Page 10: Control Panel
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD Connecting to the control signal line (DMX) - Fig. 5 ◎ Please use the round 3 or 5-pin XLR plugs &sockets offered by menu facture to connect the first projector's output to the second projector' input and connect the second projector's output to the third projector's input. -
Page 11: Menu Setting
www.lightsky.com.cn www.lightsky.de MENU SETTING(V1.0) SETTING PERSON DMX Address Address:001-512 Auto lamp on Channel mode Simple(20CH) Pan/Tilt PT swap Standard(24CH) Exit Pan lnvert INFO Fixture time Power on time:****H Tilt lnvert Lamp on time:****H Exit Fixture LAMP-TEM:***C temperatures PVG-TEM:***C (英文) English Display Display Language... - Page 12 FLY DRAGON LIGHTING EQUIPMENT CO.,LTD MANUAL Lamp ON/OFF PROGRAM Exit Reset System reset Exit Error list SERVICE 1.Cyan 000-255 ±5.00 STA GOBO 2.Magenta 000-255 ±5.00 Dimmer 3.Yellow 000-255 ±5.00 Colour 4.NC ±5.00 Prism 5.Colour 000-255 ±5.00 Frost 6.NC 000-255 Adjust ±5.00...
-
Page 13: Channel Function
www.lightsky.com.cn www.lightsky.de CHANNEL FUNCTION CHANNEL CHANNEL FUNCTION 20CH 24CH Cyan Magenta Yellow Colour Shutter Dimmer Dimmer fine Static gobo Prism Prism rotation Frost Focus Pan fine Tilt Tilt fine Function Reset Lamp LIGHT SKY... - Page 14 FLY DRAGON LIGHTING EQUIPMENT CO.,LTD Function 20CH 24CH DMX Value Percent Cyan Cyan(0-white,255-full cyan) 0-255 0-100 Magenta Magenta(0-white,255-full magenta) 0-255 0-100 Yellow Yellow(0-white,255-full yellow) 0-255 0-100 COLOUR White 6-11 White+Red 12-17 18-23 Red+ Jacinth 24-29 10-11 Jacinth 30-35 12-13 Jacinth...
- Page 15 www.lightsky.com.cn www.lightsky.de 20CH 24CH DMX Value Function Percent Stopper/Strobe Light off Strobe,slow → fast 4-103 2-40 104-107 41-42 Light on 108-207 43-81 Pulsation Strobe,slow → fast 208-212 82-79 Light on 213-225 80-88 Random Strobe at low frequency 226-238 89-93 Random Strobe at medium frequency 239-251 94-98 Random Strobe at high frequency...
- Page 16 FLY DRAGON LIGHTING EQUIPMENT CO.,LTD 20CH 24CH DMX Value Percent Function Prism insertion No prism Linear prism 6-128 3-50 Circular prism 129-255 51-100 Prism rotation Prism indexing: 0° to 90° range 0-21 Prism indexing: 90° to 180° range 21-42 8-16 Prism indexing: 180°...
- Page 17 www.lightsky.com.cn www.lightsky.de 20CH 24CH DMX Value Percent Function Function Unused range 0-11 Unused range 12-24 Normal pan / tilt speed 25-37 10-14 Conventional dimmer curve 38-50 15-19 Fast switch, light is invalid 51-56 20-21 Fast switch, light is effective 57-62 22-24 Unused range 63-255...
-
Page 18: Circuit Connecting Diagram
Circuit connecting diagram +28V +28V 470B-7M V1.3 20150205 470B-5M V1.2 20150205 Switched power supply Drive board Drive board Input +28V +28V SL08-XS +28V +28V V1.0 AC100-240V 470B-XY 20150128 50/60Hz V1.11 20150316 Display board X Y board... -
Page 19: Cleaning And Maintenances
www.lightsky.com.cn www.lightsky.de CLEANING AND MAINTENANCES ●In order to ensure the projector could work normally.It should be kept clean always .It is recommended that the fans and ventilation in let should be cleaned every 15 days.The lens and dichroic colour filters should also be reg -ularly cleaned to maintain an optimum light output.Do not use any type of solvent on dichroic colour filters.It will damage the projector. -
Page 20: Duty Exonerative And Copyright Protection
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD ■The light shadow is fogging: ◎Please check the data on the DMX 512 controller is suitable for the electric focus. ◎Please check the machenical parts is jamging.After cleaning,please add some temperature -durable juice. ■The light works interruptly: ◎Please check if the fan works normally or mote clogging. -
Page 21: Company Information
FLY DRAGON LIGHTING EQUIPMENT CO.,LTD Bocatec Sales & Rent GmbH & CO. KG Bäckerstr. 5 21244 Buchholz in der Nordheide Telefon: +49 (0) 4181 92 8 93 0 E-Mail: info@bocatec.de...
