System Description:

The Compcooler ICE Chest Cooling System combines a tubing-lined vest with a
liquid cooling system housed in an ice chest to form a tethered thermal regulation
device. Although this cooling system is highly transportable, it is designed for use
in stationary applications whereby the ice chest is located away from the User's
person but connected with tubing.
The vest is a highly engineered breathable
mesh garment that weighs a mere 0.5KG
(1.1 lbs.), dry weight. It consists of a soft
mesh outer fabric and inner liner which is
easy to don and comfortable to wear
against the body. A zipper and adjustable
tabs provide a snug fit for maximum
thermal transfer. The liquid cooling system
is a separate ice chest that weighs 1.5KG
(3.3 lbs.), dry weight. It contains a 3.0-liter
removable ice container, circulation pump,
power source, and power switch. When
operating, it's audible output is 45dBA.
Cooling energy is provided by freezing the water in the ice container. This is easily
accomplished by removing the 3.0L container from the ice chest, filling it with water
and then placing the container in a freezer. Once frozen, the container is easily
replaced in the ice chest and connected to the cooling system's pump using
quick-connect fittings. Power is derived from either a 7.4V battery pack, a 12VDC
adapter (to run off vehicle power) or 110-220VAC adapter. Users turn the switch
"On" and the pump circulates cold water in a continuous loop between the ice
chest and vest. Three settings for regulating coolant flow lets the User minimize or
maximize their ice energy. Low flow produces less cooling and conserves ice.
High flow produces more cooling for a shorter period. Users can expect a cooling
duration anywhere from 3 to 4 hours depending on ambient temperatures and
workload.
Motorcycle Solo Cooling System is designed for use of one person cooling, user
may connect an extra vest and one Y extension tubing to convert the solo system
into tandem system.
Additional ice containers and battery packs can be purchased for prolonged
cooling. A Temp control pump for regulating the cooling temperature is also
available as an option to the standard On/Off pump.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
Optional Components
COMP-MICS-7460-NF (On/Off Operation)
Item Description
1 Liquid cooling vest
Ice chest, 6.0L
2
3
3.0L ice contanier
4 Soft pack with straps; houses the ice chest
5
Water pump, simple ON/OFF operation
6 Extension tubing, 3ft
7 12V to 7.4V DC power adapter and harness
8 Manual
Rechargeable battery 7.4V 2200mAh and charger
COMP-MICS-7460-FC (Flow Control Operation)
Item Description
1 Liquid cooling vest
2 Ice chest, 6.0L
3
3.0L ice contanier
4 Soft pack with straps; houses the ice chest
5 Water pump, simple Flow Control operation
6 Extension tubing, 3ft
7 12V to 7.4V DC power adapter and harness
8 Manual
Rechargeable battery 7.4V 2200mAh and charger
COMP-MICS-7460-TC (Temp Control Operation)
Item Description
1 Liquid cooling vest
2 Ice chest, 6.0L
3
3.0L ice contanier
4
Soft pack with straps; houses the ice chest
5 Water pump, simple Temp Control operation
6 Extension tubing, 3ft
7 12V to 7.4V DC power adapter and harness
8
Manual
Rechargeable battery 7.4V 2200mAh and charger
www.compcooler.shop
Quantity
1
1
1
1
1
1
1
1
Optional
Quantity
1
1
1
1
1
1
1
1
Optional
Quantity
1
1
1
1
1
1
1
1
Optional
