System Description:

The Compcooler Univest ICE Water Cooling
System (UICS) combines a tubing-lined vest
with an integral liquid cooling system into
one self-contained and convenient thermal
regulation device.
The vest is a highly engineered waterproof
and breathable garment that weighs a mere
1KG (2.2 lbs.), dry weight. It consists of a
lightweight and durable Nylon outer fabric
and a soft mesh inner liner which is easy to
don and comfortable to wear against the
body. The integral liquid cooling system is an
attached backpack which contains a 3.0-liter
removable water bladder, circulation pump,
rechargeable battery, and ON/Off switch.
When operating, it's audible output is
45dBA.
Cooling energy is provided by freezing water in the bladder. This is easily
accomplished by removing the bladder from the system using quick-connect
fittings, and then placing the bladder in a freezer. Once frozen, the bladder is
easily re-attached to the system, and with a charged battery pack, Users turn
the switch 'On' and the pump circulates cold water in a continuous loop
between the bladder and vest. 3 settings for regulating coolant flow lets the
User minimize or maximize their ice energy. Low flow produces less cooling
and conserves ice. High flow produces more cooling for a shorter period.
Depending on ambient temperatures and workload, Users can expect a cooling
duration anywhere from 2 to 4 hours with a fully frozen 3.0L bladder or 1 to 3
minutes by using ice cubes in the bladder. The battery can last up to 10 hours.
Additional bladders and battery packs can be purchased for prolonged cooling.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY

Components List

COMP-BPIC-7430NF (On/Off Operation)
Item Description
1 Univest
Integral Circulation System:
2
• Water pump, simple ON/OFF operation
3
• Battery 7.4V 2200mAh
4
3.0L Bladder
•
5 Battery charger 110-220V
6 Manual
COMP-UICS-7430FC (Flow Control Operation)
Item Description
1 Univest
Integral Circulation System:
2
Water pump, flow control operation
•
3
• Battery 7.4V 2200mAh
4 3.0L Bladder
•
5 Battery charger 110-220V
6 Manual
COMP-UICS-7430TC (Temp Control Operation)
Item Description
1 Univest
Integral Circulation System:
2
• Water pump, temperature control operation
3
• Battery 7.4V 2200mAh
4
• 3.0L Bladder
5 Battery charger 110-220V
6 Manual
www.compcooler.shop
Quantity
1
1
1
1
1
Quantity
1
1
1
1
1
1
Quantity
1
1
1
1
1
1
