System Description - Compcooler COMP-WPCS-7415-FC-MCV Operation Manual

System Description:

The Compcooler Waistpack Ice Cooling System combines a tubing-lined vest
with a liquid cooling system housed in a detachable waistpack to form a
self-contained and convenient thermal regulation device.
The vest is a highly engineered breathable
mesh garment that weighs a mere 0.5KG
(1.1 lbs.), dry weight. It consists of a soft
mesh outer fabric and inner liner which is
easy to don and comfortable to wear against
the body. A zipper and adjustable tabs
provide a snug fit for maximum thermal
transfer. The liquid cooling system is a
detachable backpack that weighs 1.5KG
(3.3 lbs.), dry weight. It contains a 3.0-liter
removable water bladder, circulation pump,
rechargeable battery, and On/Off switch.
When operating, it's audible output is
45dBA.
Cooling energy is provided by freezing the water in the bladder. This is easily
accomplished by removing the bladder from the system using quick-connect
fittings, and then placing the bladder in a freezer. Once frozen, the bladder is
easily re-attached to the system using the quick-connect fittings. With a
charged battery pack, Users turn the switch on and the pump circulates cold
water in a continuous loop between the bladder and vest. With the included
1.5-liter bladder, Users can expect a cooling duration anywhere from 1 to 2
hours depending on ambient temperatures and workload. Additional bladders
and battery packs can be purchased for prolonged cooling.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
Optional Components
COMP-WPCS-7415-NF-MCV (On/Off Operation)
Item Description
1 Liquid cooling vest
Waistpack Circulation System:
2
• Water pump, simple ON/OFF operation
3 • Battery 7.4V 2200mAh
4
• 3.0L Bladder
5 Battery charger 110-220V
6 Manual
COMP-WPCS-7415-FC-MCV (On/Off Operation)
Item Description
1 Liquid cooling vest
Waistpack Circulation System:
2
• Water pump, flow control operation
3
• Battery 7.4V 2200mAh
4
• 3.0L Bladder
5 Battery charger 110-220V
6 Manual
COMP-WPCS-7415-TC-MCV (Temp Control Operation)
Item Description
1 Liquid cooling vest
Waistpack Circulation System:
2
• Water pump, temperature control operation
3
• Battery 7.4V 2200mAh
4
• 3.0L Bladder
5 Battery charger 110-220V
6 Manual
www.compcooler.shop
Quantity
1
1
1
1
1
1
Quantity
1
1
1
1
1
1
Quantity
1
1
1
1
1
1
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY |
�
