System Operation

4. Don the vest; Once donned, zip the vest and adjust the tabs to create a snug fit.
For optimal cooling performance, wear the vest against bare skin.
5. Connect vest to ice chest; connect the tubes on the vest to the tubes on the ice
chest using the quick-connect fittings. An audible 'click' of the quick-connect fittings
ensures a proper connection.
6. Start cooling; press power switch located on the left breast to start and set up the
flow rates of cold water circulation.
H Level: 400-450ml/minute
M Level: 300-350ml/minute
L Level: 200-250ml/minute
Red lights on the pad indicate the flow status of pump unit.

Maintenance:

The preferred cleaning method for the vest is to use a damp cloth for stain removal.
Machine washing with cold water on a gentle or delicate cycle is also acceptable using a
laundry bag. Hang drying is the only acceptable drying method.
Do not use bleach, an iron or place the vest in a machine dryer.
The ice chest and 3.0L container can be cleaned with a mild soap, like dish detergent.

Storage

Ice chest and 3.0L container; Empty all water and wipe dry. If possible, leave lids open
during storage.
Vest; Connect the vest to the pump on the ice chest. Press the On/Off switch to
restart circulation and the pump will push the water from the cooling channels in the
vest to the ice chest. Remove vest and empty the remaining water. User may empty
the cooling channel by connecting with Comcooler's Pneumatic Drain Device.
Hang-dry the bladder and vest in a cool, dry place for a minimum of 10 hours before
long-term storage.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
ON/OFF
Battery Storage
• Keep in a clean, dry, and ventilated room at 0-35°C (32°F-95°F)
• Keep away from any heat source
• Do not touch corroded contacts or elements
• Charge stored batteries every 6 months
• Keep batteries out of children's reach
Do not use batteries if any damage or abnormalities are observed
Restarting the system; after long term storage, charge the battery and fill the
bladder with clean water. Assemble the system as described under System Operation
(page 6) and run the unit for a minimum of 10 minutes to reactive pump.

Optional Components

1. Pumps:
a. On/Off type; 450-500ml/min. Reference Figure A.
b. Flow Control type; 200-250ml/min, 300-350ml/min, 400-450ml/min. Reference
Figure B.
c. Temp C ontrol type: temp control range 36°F-86°F (2°C – 30°C). Reference Figure
C.
www.compcooler.shop
Figure B
Figure C
