- Page 1 HULALA ITEM NO.CBRB1052 NOTE: This brochure contains IMPORTANT safty info. Please read and keep for future reference. 01/21...
- Page 2 MAINTAINANCE AND WARNING 1.Keep furniture away from heat sources. 2.Do not clean furniture with harsh cleaner or polishes.Do not use detergents,solvents,abrasives,spray packs or leather cleaner. Use non-color mild soa with warm water to clean spills(Mix 1:10 soap to water). 3.Do not place furniture under direct sunlight,material will possibly fade over time.
- Page 3 2PERSONENS 03/21...
-
Page 4: Parts List
PARTS LIST 1 04/21... -
Page 5: Hardware List
HARDWARE LIST φ15*11mm φ8*30mm M3.5*14mm M6*35mm φ6*35mm M7*40mm φ5*17mm φ21*0.1mm φ8*30mm M4*35mm HARDWARE SPARE LIST φ15*11mm M7*40mm φ8*30mm M3.5*14mm M6*35mm φ6*35mm φ8*30mm φ21*0.1mm M4*35mm 05/21... - Page 6 ASSEMBLY INSTRUCTIONS STEP-1 1.Prepare for part A. Align the holes in part A, insert wooden dowel #4 by hand, tighten with screwdriver #18 tighten #1 。 .picture shows.Use bolt #5 to attach rebound device #12 to top panel A ， tighten bolts with screwdriver #18. φ8*30mm M3.5*14mm φ6*35mm...
- Page 7 ASSEMBLY INSTRUCTIONS STEP-2 1.Connect the part A with part C&D. align the hole in the part C&D,insert the bolt #1 and wooden dowel #4 in part A into part C&D. insert cam bolt #2 into the corresponding hole of side panel C&D,and tighten the nuts #2 with a screwdriver #18.
- Page 8 ASSEMBLY INSTRUCTIONS STEP-3 1.Connect the part A with part E. align the hole in the part E,insert the bolt #1 and wooden dowel #4 in part A into part E. insert cam bolt #2 into the corresponding hole of side panel E,and tighten the nuts #2 with a screwdriver #18.
- Page 9 ASSEMBLY INSTRUCTIONS STEP-4 1.slide in the part F into the groove in part C,E and E,D . make sure they are also in groove in part A. The grooves must be The grooves must be align completely. align completely. 09/21...
- Page 10 ASSEMBLY INSTRUCTIONS STEP-5 Insert the wooden dowel #4 into the part C&D&E as the picture show.Connect the part B the pre-assembled unit in step 4. Then align the holes in part B,Insert screw #3 and push it down so that it connects to parts C&D&E.
- Page 11 ASSEMBLY INSTRUCTIONS STEP-6 1.install leg N on of part M , ensure the corresponding holes are aligned and fix with screw #6, then tighten the screw with an Allen key #18. M6*35mm 11/21...
- Page 12 ASSEMBLY INSTRUCTIONS STEP-7 Attention: Before the next step, adjust the feet of the locker to keep it level. 12/21...
- Page 13 ASSEMBLY INSTRUCTIONS STEP-8 1.Insert hardware #9 into part F as shown, screw in screw #5 using screwdriver #18 and tighten fully. M3.5*14mm 13/21...
- Page 14 ASSEMBLY INSTRUCTIONS STEP-9 1.Use screw #5 to attach the hinges #8 to door panel (I&J) ， tighten screws #5 with screwdriver #19 .Use bolt #5 to attach rebound device #12 to door panel （ I&J ） ， tighten bolts with screwdriver #18.
- Page 15 ASSEMBLY INSTRUCTIONS STEP-10 1.Use screw #5 to attach left door (I) and right door (J) to pre-assemble unit at step 8,tighten screw #5 with screwdriver #18 M3.5*14mm 15/21...
- Page 16 ASSEMBLY INSTRUCTIONS Concealed hinges are three-way adjustable: Horizontal by screw adjustment! Concealed hinges are three-way adjustable: In-and-out by loosening the hinge arm mounting screw or via cam adjustment! Concealed hinges are three-way adjustable: Vertical via slots in the mounting plate or via cam adjustment! Hinge adjustment method 16/21...
- Page 17 ASSEMBLY INSTRUCTIONS STEP-11 1.Insert shelf pin #10 into pre-assemble unit at step 10 .attach adjustable shelf H to pin #10. Shelf holder can be adjusted up or down φ5*17mm 17/21...
- Page 18 ASSEMBLY INSTRUCTIONS STEP-12 1.Use screw #5 to attach part #14 to side panel (D&C),tighten screw #5 with screwdriver #18. M3.5*14mm 18/21...
- Page 19 ASSEMBLY INSTRUCTIONS STEP-13 φ8*30mm M4*35mm 1.Install the anti-collapse device. 2.Mark the position on the wall, that corresponds to the location of part #15 on the side panel (C&D); Drill and insert the expandable screw #15 by hammer. 3.Assemble the part #14 to the wall. Align the hole in the part #14 with the expandable screw #15, use screw #13 to attach it and tighten by screwdriver #18.
- Page 20 ASSEMBLY INSTRUCTIONS STEP-14 Let the plastic belt #16 pass through the both part #14 and pull tightly. 20/21...
-
Page 21: Warranty
WARRANTY 1.We strive to offer high-quality products,and we also try our best to satisfy each and every customer that orders from us with product or service as needed. 2.We provide 30 days warranty starting from the time you receive the item.Each customer must provide a record of their order such as the order number,or item receipt for any items that are out of the warranty period you may also still receive.
