Optional Components

1. Pumps:
a. On/Off type; 450-500ml/min，reference Figure A.
b. Flow Control type; 200-250ml/min, 300-350ml/min, 400-450ml/min, reference Figure B.
c. Temp Control type: temp control range 36°F-86°F (2°C – 30°C), reference Figure C.
d. Flow Control Intrinsically Safe Unit，reference Figure D.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
Figure A
Figure B
Figure C
OUTLET
INLET
Figure D
2. Batteries:
a. 7.4V 2.2A battery. Reference Figure E.
b. 7.4V 5.0A battery. Reference Figure F.
JOMFU
PVUMFU
3. Bladder Options:
JOMFU
a. 3.0L (Standard). Reference Figure G.
PVUMFU
b. 2.5L (Hydration). Reference Figure H.
c. 5.0L (Max). Reference Figure I.
Figure G
www.compcooler.shop
Figure E Figure F
Figure H
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY |
Figure I
��
