Performance; System Preparation - Compcooler COMP-BPIC-7430-FC-MCV Operation Manual

Water (flow) Direction

Performance :

Combined Vest and Backpack
● Cooling time:
○ 2-4 hours with 3.0L frozen bladder
○ 1-3 hours with ice cubes
● Circulation: 500ml/min
● Temperature range: 2° - 10°C (36 - 50°F )
● Operation ambient: 0 - 60°C (32 - 140°F )
Rechargeable battery, 7.4V 2.2A
● Battery life: 8 hours
● Charging time: 3-5 hours
Rechargeable battery, 7.4V 5A
● Battery life: 20 hours
● Charging time: 4-5 hours
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
Liquid Cooling Vest
Bladder
Pump
ICE Circulation Cooling Performance
25 35 40 45 50 55
Ambient Temperature (°C)
3L Bladder 2L Bladder 1.5L Bladder
Battery Operation Time
1400
1200
1000
800
600
400
200
25 35 40 45 50 55
Ambient Temperature (°C)
7.4V 5A 7.4V 2.2A
System Prepartion:
Battery
Charge the battery using the included charging cord. LED
lights on the batter housing indicate charging progress. A red
light indicates the battery is still charging. A green light
indicates the battery is fully charged. Reference Figure C.
Pressing "Remaining Battery Capacity" on the battery
indicates, by percentage, how full the battery is. 3 Led lights
indicate 80-100% capacity, 2 lights indicate 60-80% capacity
and 1 light indicate ≤ 50% capacity. Reference illustration at
right.
Typical charge time to 'full' is 4 hours. A fully charged battery
will operate up to 8 hours.
Bladder
Unzip the backpack and remove the bladder from
the system by depressing the quick-connect fittings
that attach the bladder to the pump.
Remove the plastic roll-top slider at the top of the
bladder and fill it with water. Take care not to
exceed the fill line. The remaining air pocket in the
bladder is required for the system to work properly.
Lay the bladder flat in a freezer and allow the water
to completely freeze for optimum performance.
Note: Ice cubes can also be used if there is not
enough time to wait for a frozen bladder. In this
case, add ice cubes to the bladder and top off with
water, taking care not to exceed the fill line. While
60
ice cubes will provide adequate performance, the
cooling time will be reduced.
Note: if bladder is not laid flat, or if it was over-filled with water,
the quick-connect fittings may freeze and not allow circulation.
If such an instance occurs, simply pour tepid water on the
quick-connect fittings until the water in these fittings is melted.
60
