Maintenance:

The preferred cleaning method for the vest is to use a damp cloth for stain removal. In
the latter case, remove the mechanical components by disconnect screw-in fitting within
integral backpack including the pump, battery, bladder and On/Off switch before placing
the vest in a washing machine. Machine washing with cold water on a gentle or delicate
cycle is also acceptable.
Hang drying is the only acceptable drying method.

Storage

Integral Circulation System; Disconnect the bladder from the vest and empty the
water.
Vest; Connect the empty bladder to the vest and position it upside down. Press the
On/Off switch to restart circulation and the pump will push the water from the cooling
channels in the vest to the bladder. Remove bladder again and empty the remaining
water. User may empty the cooling channel by connecting with Comcooler's Pneumatic
Drain Device.
Hang-dry the bladder and vest in a cool, dry place for a minimum of 10 hours before
long-term storage.
Battery Storage
• Keep in a clean, dry, and ventilated room at 0-35°C (32°F-95°F)
• Keep away from any heat source
• Do not touch corroded contacts or elements
• Charge stored batteries every 6 months
• Keep batteries out of children's reach
Do not use batteries if any damage or abnormalities are observed
Restarting the system;
after long term storage, charge the battery and fill the bladder
with clean water. Assemble the system as described under System Operation (page 6)
and run the unit for a minimum of 10 minutes to reactive pump.
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY

Optional Components

1. Pumps:
a. On/Off type; 450-500ml/min, reference Figure A.
b. Flow Control type; 200-250ml/min, 300-350ml/min, 400-450ml/min, reference
Figure B.
c. Temp Control type: temp control range 36°F-86°F (2°C – 30°C), reference Figure C.
www.compcooler.shop
Figure A
Figure B
Figure C
