Description
The Compcooler Motorcycle Rider Chiller
Cooling
System
(MRCS)
combines
tubing-lined vest with a compact chiller unit to
form a tethered thermal regulation device.
MRCS uses a 12V vehicle battery-powered
mini refrigeration chiller unit housed in a
hand-carry pack to cool the liquid. A pump in
the chiller unit circulates the cold liquid into a
tubing-lined garment. The User's body heat is
absorbed by the liquid and returned back to
the chiller unit to be cooled again. This process
continues in a closed loop as long as the
system is powered 'ON'.
MRCS is powered by a 12-16V vehicle battery or rechargeable battery and delivers
150-200W of cooling capacity. Temperature control is -9°C to 30°C (16°F to 86°F) with an
accuracy of +1/1°C (2°F). The system is programmable and will automatically operate at
the user's preferred temperature set point. The set point can be adjusted using a supplied
remote controller.
Components List
Item
Part number
1
COMP-MRCU-12200
2
COMP-LCG-MCV-OL/BK
3
COMP-ET-2M
4
Components Description
1.
Mesh Liquid Cooling Vest
Part no. COMP-LCG-MCV-OL/BK
2.
Control Pad
3.
Extension Tubing
4.
Power Cord
5.
Chiller Unit
� |
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY
a
Description
Quantity
Micro Refrigeration Chiller Unit
Handcarry Pack
Mesh Liquid Cooling Vest
Extension Tubing
Operation Manual
1
2
3
Optional Components
Item
1
2
3
Dimensions, Chiller Unit
1
Chiller Unit Callouts
1
1. Mini Rotary Compressor
1
2. Condenser
3. Reservoir
1
4. Filler cap
1
5. Water pump
6. Fans
7. Liquid inlet
8. Liquid outlet
4
5
9. Drive board
10. Control board
11. Power connection
12. Control pad
13. Air inlet
14. Exhaust
Part number
COMP-LCG-FBG-BK
Cooling Garment
COMP-LCG-VVDH
V-Neck Detachable Hoodie Vest
COMP-RB-1220
104mm(4.09")
207.5mm(8.17")
14
2
6
9
13
COMPCOOLER,PERSONAL THERMAL TECHNOLOGY |
www.compcooler.shop
Description
Full body
,
Rechargeable Battery
10
4
1
13
3
8
7
12
5
11
�
